Canon imagePROGRAF iPF5000 Series Service Manual page 159

J3001 (Lift motor/head management sensor)
Pin Number Signal name
13 PE_SNS
J3101 (Carriage motor)
Pin Number Signal name
1 CR_HWP
2 CR_HWM
3 CR_W
4 CR_HVM
5 CR_U
6 GND
7 CR_V
8 RGV5
9 N.C.
10 CR_HVP
11 CR_HUM
12 CR_HUP
J3201 (Valve motor,valve open/close detection sensor,top cover sensor,ink tank cover switch)
Pin Number Signal name
1 TANK_COVER_SW
2 GND
3 TOP_COVER_3V
4 GND
5 TOP_COVER_SNS
6 VALVE_DETECT_3V
7 GND
8 VALVE_DETECT_SNS
9 VALVE_MOTOR_AM
10 VALVE_MOTOR_AP
J3202 (Ink tank ROM PCB)
Pin Number Signal name
1 TANK_DAT0
2 TANK_DAT1
3 TANK_3V
4 TANK_DAT2
5 GND
6 TANK_CLK
7 TANK_DAT3
8 TANK_DAT4
9 TANK_3V
10 TANK_DAT5
11 GND
12 TANK_CLK
13 GND
14 INK_SNS0
15 INK_SNS1
16 INK_SNS2
17 GND
18 INK_SNS3
19 INK_SNS4
20 INK_SNS5
J3301 (Ink tank ROM PCB)
Pin Number Signal name
1 TANK_DAT6
2 TANK_DAT7
3 TANK_3V
4 TANK_DAT8
5 GND
6 TANK_CLK
IN/OUT Function
IN Paper detection sensor output signal
T-6-18
IN/OUT Function
IN Carriage motor hole device W-phase + signal
IN Carriage motor hole device W-phase - signal
OUT Carriage motor W-phase drive signal
IN Carriage motor hole device V-phase - signal
OUT Carriage motor U-phase drive signal
- GND
OUT Carriage motor V-phase drive signal
OUT Power supply (+5V)
- N.C
IN Carriage motor hole device V-phase + signal
IN Carriage motor hole device U-phase - signal
IN Carriage motor hole device U-phase + signal
T-6-19
IN/OUT Function
IN Ink tank cover fswitch output signal
- GND
OUT Power supply (+3.3V)
- GND
IN Top cover sensor output signal
OUT Power supply (+3.3V)
- GND
IN Valve open/close sensor output signal
OUT Valve motor drive signal AM
OUT Valve motor drive signal AP
T-6-20
IN/OUT Function
IN/OUT Ink tank data signal 0
IN/OUT Ink tank data signal 1
OUT Power supply (+3.3V)
IN/OUT Ink tank data signal 2
- GND
OUT Ink tank clock signal
IN/OUT Ink tank data signal 3
IN/OUT Ink tank data signal 4
OUT Power supply (+3.3V)
IN/OUT Ink tank data signal 5
- GND
OUT Ink tank clock signal
- GND
IN Ink detection sensor output signal 0
IN Ink detection sensor output signal 1
IN Ink detection sensor output signal 2
- GND
IN Ink detection sensor output signal 3
IN Ink detection sensor output signal 4
IN Ink detection sensor output signal 5
T-6-21
IN/OUT Function
IN/OUT Ink tank data signal 6
IN/OUT Ink tank data signal 7
OUT Power supply (+3.3V)
IN/OUT Ink tank data signal 8
- GND
OUT Ink tank clock signal
Chapter 6
6-7
