CONTROLS

Indicator lamps

5.17
Possible states
The turn signal indicator lamp flashes green simultaneously with the turn
signal – The turn signal is switched on.
The oil pressure warning lamp lights up red – The oil pressure is too low.
The shift warning lights up/flashes red – The set shift speed has been
reached.
The idle speed indicator lamp lights up green – The transmission is shifted
to idle.
The high beam indicator lamp lights up blue – The high beam is switched
on.
EFI warning lamp (MIL) lights up / flashes red – The OBD (on-board diagno-
sis) has detected an emission- or safety-critical error.
The general warning lights up yellow – An operating safety (warning) mes-
sage was detected. This is also shown periodically in the info display.
The immobilizer indicator lamp lights up or flashes red – Status or error
message for immobilizer/alarm system.
401122-01
