SERVICE WORK ON THE CHASSIS

Raising the rear of the motorcycle with lifting gear

10.3
Note
Danger of damage The parked vehicle may roll away or fall over.
–
Always place the vehicle on a firm and even surface.

Removing the rear of motorcycle from the lifting gear

10.4
Note
Danger of damage The parked vehicle may roll away or fall over.
–
Always place the vehicle on a firm and even surface.
–
Secure the motorcycle against falling over.
–
Remove the lift stand from the rear and lean the vehicle on the side stand.
–
Insert the adapter into the lifting gear at the rear.
Adapter (61029055120)
Rear wheel stand (61029055400)
–
Stand the motorcycle upright, align the lifting gear to the link fork and the adapters,
and raise the motorcycle.
B00576-01
164
