Machine description
PICO 260; 300 CEL PWS
4.2.2
Rear view
Item
Symbol Description
1
2
3
4
F4
5
F5
16
1
2
3
0
Main switch, machine on/off
Strain relief with mains connection cable
Cooling air outlet
Fuse
Solenoid switch pole reversal fuse
Fuse
Solenoid switch pole reversal fuse
Figure 4-4
4
5
Item No.: 099-002032-EWM01
