Pico 260; 260 Cel; 260 Cel Pws - EWM PICO 230 Operating Instructions Manual

3.2

PICO 260; 260 CEL; 260 CEL PWS

PICO range
Setting range:
TIG
electrode
MMA operating time
40%
50%
60%
100%
TIG operating time
50%
60%
100%
Load alternation
MMA open circuit voltage
MMA open circuit voltage with VRD
option
TIG open circuit voltage
Mains voltage (tolerances)
Frequency
Mains fuse (safety fuse, slow-blow)
Mains connection lead
Max. connected power
Recommended generator rating
cosϕ at Imax / efficiency
Insulation class / protection
classification
Ambient temperature
Machine cooling / torch cooling
Workpiece lead
Dimensions L/W/H
Weight
Constructed to standards
Item No.: 099-002032-EWM01
260; 260 CEL; 260CEL PWS
10 A / 10.4 V to 260 A / 20.4 V
10 A / 20.4 V to 260 A / 30.4 V
20°C
-
260 A
250 A
190 A
20°C
-
260 A
200 A
10min (60% DC ∧ 6 min welding, 4min break)
3x400 V (+ 20 % to – 25 % )
3x415 V (+ 15 % to – 25 % )
H07RN-F4G1.5
-10 °-C to +40 °C
490 x 186 x 350 mm;
490 x 186 x 445 mm (260CEL PWS)
23.5 kg (260CEL PWS)
EN 60974 / IEC 60974 / VDE 0544
EN 50199 / VDE 0544 Part 206
Technical data
PICO 260; 260 CEL; 260 CEL PWS
40°C
260 A
-
220 A
170 A
40°C
260 A
240 A
190 A
99 V
12 V
12 V
50/60 Hz
16 A
11.8 kVA
16.0 kVA
0,99 / 88%
H / IP 23
Fan / Gas
35 qmm
16.5 kg;
/
11
