Magnum 10KG Managed Switch Installation and User Guide
5.1.6

10K4-MTRJ, four Multimode MTRJ (use in Slots E-H)

The 10K4-MTRJ four-port fiber module provides four 100Mb Multimode
MTRJ Fiber ports.
The 10K4-MTRJ fiber port is a Small Form Factor (SFF) MTRJ Multimode
connector. The MTRJ's small size and ease of connection make it a good choice for
100Mbps "fiber-to-the-desktop" Ethernet connectivity. When installed in a Magnum
10KG Series Switch, it supports fiber optic cable distances up to the IEEE-standard
100Mbps distance limits, i.e., typically 2km at full-duplex and 412m at half-duplex.
The cable end is a "plug-in" connector with both fiber strands terminated in
one housing that cannot be improperly inserted. Each port has a Link/Activity (L/A) LED
indicating proper connectivity (Link) with the remote device when lit and blinking
(Activity), indicating packets being received.
A module similar to Model 10K4-MTRJ is also available with IEEE 1588v2
Timing Synchronization as Model # 10K4T-MTRJ.
