Magnum 10KG Managed Switch Installation and User Guide
Fixed Power supply models w/Thermal Fins
MODEL
10KG-H-TF: Magnum 10KG Managed Switch, front-mount, with integral 90-
250V AC/DC Power Supply. May be factory-configured with a variety of fiber and
copper port modules selected designed specifically for the 10KG-series. Configure up
to 24 ports in a mix of Gb and 100Mb. Heavy-duty case with thermal fins for
maximum convection cooling efficiency in a rack-mount setting.
10KGR-H-TF: Same as Model 10KG-H-TF except chassis is a Reverse Mount unit.
(All signal and power cables are in the rear)
10KG-HH-TF: Magnum 10KG Managed Switch, front-mount, with two integral 90-
250V AC/DC Power Supply. May be factory-configured with a variety of fiber and
copper port modules selected designed specifically for the 10KG-series. Configure up
to 24 ports in a mix of Gb and 100Mb. Heavy-duty case with thermal fins for
maximum convection cooling efficiency in a rack-mount setting.
10KGR-HH-TF: Same as Model 10KG-HH-TF except chassis is a Reverse Mount unit.
(All signal and power cables are in the rear)
10KG-L-TF: Same as Model 10KG-H-TF except the integral power supply is
L 24/48VDC.
10KGR-L-TF: Same as Model 10KG-L-TF except chassis is a Reverse Mount unit.
(All signal and power cables are in the rear)
10KG-LL-TF: Same as Model 10KG-HH-TF except the integral power supplies are
L 24/48VDC.
10KGR-LL-TF: Same as Model 10KG-LL-TF except chassis is a Reverse Mount unit.
(All signal and power cables are in the rear)
10KG-HL-TF: Same as Model 10KG-HH-TF except the integral power supplies are
one H 90-250V AC/DC and one L 24/48VDC.
10KGR-HL-TF: Same as Model 10KG-HL-TF except chassis is a Reverse Mount unit.
(All signal and power cables are in the rear)
10KG-AC-TF: Same as Model 10KG-H-TF except the power supply is an auto-sensing
worldwide AC power type (100-240V AC) using a UL-registered recessed-male
IEC 320 plug.
10KGR-AC-TF: Same as Model 10KG-AC-TF except chassis is a Reverse Mount unit.
(All signal and power cables are in the rear)
www GarrettCom com .
DESCRIPTION
.
5
07/12
