17
PRINT PAD INSTALLATION
1.
Place print pad magnetic strip onto the magnetic strip on print plate.
18
SETTING PRINT JET GAP
The print tip must be set to the correct distance between the print tip and the print pad to ensure the first printed layer sticks
properly.
When the Cube is operating, the print tip on the print jet nozzle becomes hot; avoid touching
this area until it has cooled down.
1.
Finger tap "Set Up" on the touchscreen and press "Next" until "Set Gap" appears.
Tap Here
36
Rough side of print pad
is facing up
