Daikin 2MXS40H2V1B Service Manual page 241

SiBE121123_A
4.1.3 Jumper and Switch Settings
<Floor Standing Type: FVXS Series>
∗ Keep the other switches as factory setting.
<Floor / Ceiling Suspended Dual Type>
For the location of the jumper and the switch, refer to the following pages.
Caution Replace the PCB if you accidentally cut a wrong jumper.
Jumpers are necessary for electronic circuit. Improper operation may occur if you cut any of
them.
Trial Operation and Field Settings
Jumper
(on indoor unit PCB)
JB Fan speed setting
when compressor
stops for thermostat
OFF. (effective only
at cooling operation)
JC Power failure
recovery function
Switch
(on indoor unit PCB)
SW2-4 Upward airflow limit
setting
Switch
(on indoor unit PCB)
SW2 Installation style
changeover
FTXG25/35/50JV1BW(S)(A): page 29
CTXS15/35K2V1B, FTXS20/25K2V1B: page 31
FTXS35/42/50K2V1B, FTXS20/25/35/42/50J2V1B, ATXS20/25/35/42/50G2V1B: page 33
FTX20/25/35JV1B, FTX20/25/35J2V1B, ATX20/25/35JV1B, ATX20/25/35J2V1B: page 35
FVXG25/35/50K2V1B: page 37
FVXS25/35/50FV1B: page 39
FLXS25/35/50BAVMB: page 41
FDXS25/35EAVMB, FDXS25/35/E7VMB, FDXS50CVMB, FDXS50C7VMB: page 43
Function When connected
(factory set)
Fan speed setting;
Remote controller
setting
Auto-restart
Function OFF
(factory set)
Exposed or half
embedded
installation
Function FLOOR
(factory set)
When installed as
the floor mounted
type
Field Settings
When cut
Fan speed setting; "0" (The fan
stops.)
The unit does not resume
operation after recovering from a
power failure. Timer settings are
cleared.
ON
Set the switch to ON position
when you install the indoor unit
embedded in the wall to avoid
condensation.
CEILING
When installed as the ceiling
suspended type
230
