Moving - Garmin Apollo CNX80 Installation Manual

ID Data Format
A sddmmhh
B sdddmmhh
C ddd
D ddd
E ddddd
G sdddd
I dddd
K ddd[dd]
L dddd
Q sddd
T ---A-----
a eampht
c vDddd
l dddddd
( )
lower case L
Apollo CNX80 Installation Manual
Table B- 6 - Moving Map ASCII Navigation Data
Length Description
9 Present latitude
s =sign: N for north, S for south
dd = degrees
mm = minutes
hh = hundredths of minutes
10 Present longitude
s = sign: E for east, W for west
ddd = degrees
mm = minutes
hh = hundredths of minutes
3 Track (magnetic): ddd = degrees
3 Ground speed: ddd = knots
5 Distance to active waypoint: ddddd = nm x 10
5 Cross track error:
s = sign: R for right, L for left of course
dddd = distance off course, hundredths of nm
4 Desired track (magnetic):
dddd = degrees x 10
3 to 5 Active waypoint identifier:
ddd[dd] = ASCII waypoint identifier
4 Bearing to active waypoint (magnetic):
dddd = degrees x 10
4 Magnetic variation:
s = sign: E for east, W for west
ddd = degrees x 10
9 Warnings: The 4th character will be an "A" when the
navigation data is flagged, otherwise, all characters will be
dashed. All other navigation data will be dashed when it is
flagged.
8
Annunciator Flags:
e = Approach Enabled { '-' (off) || 'O'(on) }
a = Approach Active { '-' (off) || 'O'(on) || 'B' (blink)}
m = Message
p = Parallel Track
h = Hold
t = From/To
7
CDI:
v = Nav Flag { '-' Flagged || 'v' Valid }
D = Needle { 'C' Center || 'L' Left || 'R' Right }
ddd = Deflection Value ASCII (000 – 120)
6 Distance to Destination:
dddddd = nm * 10
560-0982-00 Rev D
Appendix B - Serial Interface Specifications
{ '-' (off) || 'O'(on) || 'B' (blink)}
{ '-' (off) || 'O'(on) }
{ '-' (off) || 'O'(on) || 'B' (blink)}
{'–' (off) || 'T' (To) || 'F' (From)}
B-7
