Installation Procedures
2.8.12.1 Com Headphone and Speaker Audio Out
P4-14
Com Headphone Out
P4-6
Com Speaker Out
P4-13
Com Audio Ground
The Com Headphone Out is a low-level audio output that is intended to drive a headset or audio panel.
This output will provide 280 mW into a 100 Ω load, or 120 mW into a 500 Ω load.
The Com Speaker Out is a high-level audio output that is available to drive a speaker. This output will
provide 12 watts into a 4 Ω load, or 8 watts into an 8 Ω load.
Both the Headphone and Speaker outputs use the same Com Audio Ground. For normal installations, it is
recommended that the Headphone output be used, and the Com Speaker output be left unconnected.
2.8.12.2 Com MIC Audio In
P4-8
Com MIC In High
P4-7
Com MIC In Low
The Com MIC input is designed for a standard carbon or dynamic mic with integrated pre-amp providing
minimum 70 mv rms into 1000 Ω load. The CNX80 provides a bias voltage to the microphone.
2.8.12.3 Push to Talk (PTT)
P4-4
PTT
The PTT is used to enable the Com MIC audio and cause the Com transceiver to transmit on the active
frequency. Refer to section 2.8.9.4 for additional details.
2.8.12.4 Com Flip-Flop Switch
P1-14
Com Flip Flop In
The Com Flip-Flop In can be used to toggle the active and standby Com frequencies. Refer to section
2.8.9.2 for additional details.
2.8.12.5 Com User List Switch
P1-15
UP Discrete In
P1-33
DOWN Discrete In
The Com User List inputs can be used to display the Com User List and select a frequency. Refer to
section 2.8.9.5 for additional details.
2.8.13
VHF N
AV
The CNX80 provides an internal NAV receiver that can be interfaced to an audio panel. An optional
external input is also available to allow the user to toggle the active and standby Nav frequencies.
Refer to Appendix D for interconnect information.
2-36
560-0982-00 Rev D
Apollo CNX80 Installation Manual
