Package Contents; Table 1-2 - Package Contents; Table 1-3 - Installation Kit - Garmin Apollo CNX80 Installation Manual

1.7 P C
ACKAGE
As shipped from the Garmin AT factory, the Apollo CNX80 package includes most necessary items for
installation other than supplies normally available at the installation shop, such as wire and cable ties,
circuit breakers, and required input and output equipment. The items included in the package are listed in
Table 1-2, Table 1-3, and Table 1-4. Optional items available are listed in Table 1-5.
Item
138-0329-xxx
140-0056-xxx
424-2014-8xx
424-2016-xxx
428-0059
430-6100-8hh-sss
560-0984-xx
560-0992-xx
561-0281-xx
590-1104
[1] Will be provided on the Product CD and on our website (www.garminat.com) when available.
Item
162-0082
162-0109
162-1008
162-1575
162-1577
310-3071-02
310-3072-00
310-3073-00
204-0037
245-0027
Apollo CNX80 Installation Manual
ONTENTS

Table 1-2 - Package Contents

Qty
1 CNX80 Worldwide Database Card
1 CNX80 Product CD (includes the following)
139-0240-xxx Mission Planning Software
560-0177-xx Mission Planning Software User's Guide
560-0949-xx A33 GPS Antenna Installation Guide
560-0982-xx CNX80 Installation Manual
560-0984-xx CNX80 Pilot's Guide
560-0988-xx CNX80 STC Data [1]
560-0990-xx CNX80 Computer-Based Training
560-5047-xx A34 GPS Antenna Installation Guide
561-0281-xx CNX80 Quick Reference Guide
1 CNX80 Installation Kit (see Table 1-3 for detail)
1 CNX80 Hardware Kit (See Table 1-4 for detail)
1 Compact Card Reader, USB
1 CNX80 WAAS/GPS Nav Com
(hh defines hardware configuration and sss defines software
configuration)
1 CNX80 Pilot's Guide
1 CNX80 Product Tape, VHS
1 CNX80 Quick Reference Guide
1 A33 GPS Antenna
Table 1-3 - Installation Kit Contents (PN 424-2014-800)
Qty
50 22-28 AWG male crimp contact
1 78 Pin Crimp Hi Density D-Sub Plug
3 Coax Plug, right angle mount
1 15 Pin Crimp D-Sub Receptacle
2 37 Pin Crimp D-Sub Receptacle
1 Mounting Tube, CNX80
1 Air Deflector, CNX80
1 Connector plate CNX80
0.5 ft .062 Black Flexible Grommet
60 20-24 AWG female crimp contact
