Garmin Apollo CNX80 Installation Manual page 21

1.3.9.2 Auxiliary CDI (GPS Only)
CDI L/R deviation........................................±150 mv full scale (200 Ω load max)
TO/OFF/FROM flag....................................±250 mv, TO/FROM (200 Ω load max)
Nav valid flag ..............................................+300 mv for valid indication (200 Ω load max)
VDI up/down ...............................................±150 mv full scale (200 Ω load max)
VDI valid flag ..............................................+300 mv for valid indication (200 Ω load max)
1.3.9.3 Composite Output
1.3.9.3.1 VOR Mode
Band pass frequency.....................................0 Hz to 15 kHz
Variation over frequency range.....................Less than 2 dB
Output signal voltage....................................0.500 VRMS
Output loading .............................................1,000 ohms (max)
1.3.9.3.2 LOC Mode
Band pass frequency.....................................0 Hz to 15 kHz
Variation over frequency range.....................Less than 2 dB
Output signal voltage....................................0.390 VRMS (0.275 VRMS @ 90 Hz, 0.275 VRMS
Output loading .............................................1,000 ohms (max)
ILS energize signal.......................................Sinks up to 400 mA (max)
1.3.9.4 Annunciator Outputs
Annunciators................................................Open collector outputs capable of sinking up to 400
Apollo CNX80 Installation Manual
@ 150 Hz)
mA for turning ON annunciator lamps
560-0982-00 Rev D
General Information
1-11
