2.8.13.1 Nav Audio Out
P7-23 NAV Audio Out
P7-20 NAV Audio Ground
The NAV Audio Out is a low-level audio output that is intended to drive a headset or audio panel. This
output will provide 100 mW into a 500 Ω load.
2.8.13.2 VOR Flip-Flop Switch
P1-34 VOR Flip Flop In
The VOR Flip Flop In is used to toggle the active and standby VOR/LOC frequencies. Refer to section
2.8.9.3 for additional details.
2.8.14 M
ESSAGE
The CNX80 provides a message audio output for aural advisory messages. This output also provides an
optional tone to alert the user when a new status message is available. A discrete input is also provided to
allow these audio messages to be inhibited by higher priority systems.
Refer to Appendix D for interconnect information.
2.8.14.1 Message Audio Out
P5-40 Message Audio Out
P5-43 Message Audio Gnd
The Message Audio Out is a low-level audio output that is intended to drive a headset or audio panel. It is
recommended that this input be provided to an auxiliary input in the audio panel that will allow the user to
switch off the message audio if desired. This output will provide 100 mW into a 500 Ω load.
2.8.14.2 Audio Inhibit In
P5-76 Audio Inhibit In
The Audio Inhibit In may be used by higher priority systems to inhibit the CNX80 audio messages. Refer
to section 2.8.9.7 for additional details.
2.8.15

RMI / OBI

The CNX80 RMI/OBI output can be used to drive an RMI (or OBI) navigation indicator. The OBI Select
input is used to select the source (GPS or Nav radio) used to provide the bearing.
Refer to Appendix D for interconnect information.
Apollo CNX80 Installation Manual
A
UDIO
560-0982-00 Rev D
Installation Procedures
2-37
