APPENDIX E - A
In certain instances, aircraft on the Approved Model List have a center radio stack located outside of the
acceptable field-of-view defined herein. For these particular installations, additional FAA approval will be
required. Below is a listing of such aircraft that have already been evaluated by the FAA and determined to
be acceptable. No further approval will be required for these aircraft provided the criteria in the
Installation Requirements column are satisfied by the installation.
Aircraft Make and Model
Designation
Raytheon (Beech)
E33, E33A, E33C, F33,
F33A, F33C, G33
35-B33, 35-C33, 35-C33A,
P35, S35, V35A, V35B
36, A36, A36TC, B36TC
D55, D55A, E55, E55A
56TC, A56TC
58, 58A, 58P, 58PA, 58TC,
58TCA
95-55, 95-A55, 95-B55, 95-
B55A, 95-C55, 95-C55A
Apollo CNX80 Installation Manual
A
CCEPTABLE
The CNX80 must be installed in the manufacturer's provided avionics
stack. External CDI/HSI source selection annunciation is required. The
CDI/HSI source select annunciation must be installed in accordance with
2.5.3.2.
The CNX80 must be installed in the manufacturer's provided avionics
stack. External CDI/HSI source selection annunciation is required. The
CDI/HSI source select annunciation must be installed in accordance with
2.5.3.2.
The CNX80 must be installed in the manufacturer's provided avionics
stack. External CDI/HSI source selection annunciation is required. The
CDI/HSI source select annunciation must be installed in accordance with
2.5.3.2.
The CNX80 must be installed high enough in the manufacturer's provided
avionics stack so that there is a clear, unobstructed view of the display.
External CDI/HSI source selection annunciation is required. The CDI/HSI
source select annunciation must be installed in accordance with 2.5.3.2.
The CNX80 must be installed high enough in the manufacturer's provided
avionics stack so that there is a clear, unobstructed view of the display.
External CDI/HSI source selection annunciation is required. The CDI/HSI
source select annunciation must be installed in accordance with 2.5.3.2.
The CNX80 must be installed high enough in the manufacturer's provided
avionics stack so that there is a clear, unobstructed view of the display.
External CDI/HSI source selection annunciation is required. The CDI/HSI
source select annunciation must be installed in accordance with 2.5.3.2.
The CNX80 must be installed high enough in the manufacturer's provided
avionics stack so that there is a clear, unobstructed view of the display.
External CDI/HSI source selection annunciation is required. The CDI/HSI
source select annunciation must be installed in accordance with 2.5.3.2.
560-0982-00 Rev D
Appendix E – Acceptable Aircraft by Evaluation
E

IRCRAFT BY

VALUATION
Installation Requirements
E-1
