SERVICE MANUAL
US
Permobil C500
Power wheelchair

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C500 and is the answer not in the manual?

Questions and answers

Related Manuals for Permobil C500

Summary of Contents for Permobil C500

  • Page 1 SERVICE MANUAL Permobil C500 Power wheelchair...
  • Page 3 Head Office of the Permobil group Permobil AB Box 120, 861 23 Timrå, Sweden Tel: +46 60 59 59 00. Fax: +46 60 57 52 50 E-mail: info@permobil.se Produced and published by Permobil AB, Sweden Edition no.4, 2009-06 Order no.: 205210-US-0...

  • Page 4: Table Of Contents

    Contents Contents Introduction ...................... 5 Identification plates ..................6 Covers ....................... 7 Batteries ......................8 Front wheels ....................10 Rear wheels ....................12 Support wheels ....................14 Wheel forks ....................16 Rear wheel suspension ................. 17 Shock absorbers .................... 18 Slewing brackets ...................

  • Page 5: Introduction

    Permobil to ensure that the correct information is provided. Technical Support In the event of technical problems, you should contact your dealer, or Permobil Inc. USA at 800-736-0925. Spare parts Spare parts must be ordered through your dealer.

  • Page 6: Identification Plates

    Identification plates Identification plates Chassis Chassis identification number. Pilot+ controller Pilot+ controller identification number. Control panel Pilot+ Control panel Pilot+ identification number.

  • Page 7: Covers

    Covers Covers Removing the seat elevator cover 1. Raise the seat to the highest position. If the chassis is equiped with fixed seat post, see page 34. If the seat elevator does not work normally because the batteries are discharged or the actuator is defective, the seat can be raised/lowered manually, see page 30.

  • Page 8: Batteries

    Batteries Batteries WARNING Be careful when using metal objects when working with batteries. A short-circuit can easily cause an explosion. Always use safety gloves and safety goggles. Removal 1. Place the wheelchair on a level surface. 2. Switch off the main power switch on the control panel.
  • Page 9 Batteries Batteries Fitting 1. Lift new batteries into the chassis using the battery belt. Leave the battery belt on the batteries. Place the battery with the battery terminals facing backwards, see fig. WARNING Be careful when using metal objects when working with batteries.

  • Page 10: Front Wheels

    Front wheels Front wheels Removal 1. Turn off the main power switch on the control panel. 2. Lift the wheelchair chassis and support it on blocks so that the wheel is off the ground. 3. Remove the hubcap (1), bolt (2) and the three washers (3 and 4);...

  • Page 11: Filling With Air

    Front wheels Front wheels Replacement of inner tube 1. Turn off the main power switch on the control panel. 2. Put the wheelchair up on blocks so that the wheel is free and then let the air out of it. 3.

  • Page 12: Rear Wheels

    Rear wheels Rear wheels Removal 1. Turn off the main power switch on the control panel. 2. Lift the wheelchair chassis and support it on blocks so that the wheel is off the ground. 3. Remove the hucap (1). 4. Remove the screw (2) and the washer (3). 5.
  • Page 13 If the wheel bolt is removed for tire service, replace it with a Filling with air new, unused part from Permobil and tighten the bolt to the recommended torque. Also, inspect the drive axle and wheel Check at regular intervals that the wheelchair's tires rim for any damage.

  • Page 14: Support Wheels

    Support wheels Support Wheels The support wheels should always be fitted in the lower position, see fig. Removing the support wheels 1. Turn off the main power switch on the control panel. 2. Remove the bolt, see fig. WARNING Removing the support wheels entails an increased risk of the wheelchair tipping over.
  • Page 15 Support wheels Support Wheels Removing the support wheel unit 1. Turn off the main power switch on the control panel. 2. Remove the front wheel on the side in question, see page 10. 3. Remove the three bolts that holds the support wheel unit and the drive unit.

  • Page 16: Wheel Forks

    Wheel Forks Wheel Forks Removal 1. Switch off the main power switch on the control panel. 2. Lift up and chock up the wheelchair chassis so that the wheel in question is free of the ground. 3. Remove the cap from the top of the link arm. See fig.

  • Page 17: Rear Wheel Suspension

    Rear wheel suspension Rear wheel suspension Removal 1. Switch off the main power switch on the control panel. 2. Lift up and chock up the wheelchair chassis so that the rear wheel suspension is free of the ground. 3. Remove the rear wheel suspension. It is fitted with three bolts with two washers and one nut each, see fig.

  • Page 18: Shock Absorbers

    Shock Absorbers Shock Absorbers Removal 1. Switch off the main power switch on the control panel. 2. Remove the front fender on the side in question, see page 7. 3. Lift up and chock up the wheelchair chassis so that the wheel in question is free of the ground. 4.
  • Page 19 Shock Absorbers Adjusting the KS 291 Shock Absorber Adjustment of shock absorber spring User weights Setting - 110 Ibs 5/8 inch (16 mm) 110 -155 Ibs 21/32 inch (17 mm) 155 -200 Ibs 3/4 inch (19 mm) 200 -265 Ibs 13/16 inch (21 mm) 265 -310 Ibs 15/16 inch (24 mm)

  • Page 20: Slewing Brackets

    Slewing brackets Slewing brackets Removal 1. Raise the seat to the highest position. If the chassis is equiped with fixed seat post, see page 34. If the seat elevator does not work normally because the batteries are discharged or the actuator is defective, the seat can be raised/lowered manually, see page 30.
  • Page 21 Slewing brackets Slewing brackets 9. Loosen the rear end of the chassis cover a little by unscrewing the knob that holds the cover. 10. Open the battery cover on the side in quesstion by loosening the knobs that holds the battery cover, and drop the cover down. 11.

  • Page 22: Wheel Lock Release Cable

    Wheel lock release cable Wheel lock release cable Removal 1. Raise the seat to the highest position. If the chassis is equiped with fixed seat post, see page 34. If the seat elevator does not work normally because the batteries are discharged or the actuator is defective, the seat can be raised/lowered manually, see page 30.
  • Page 23 Wheel lock release cable Wheel lock release cable Fitting 1. Fit the cable at the magnetic wheel lock first, then at the release lever. 2. Adjust the cable sleeve length with the adjusting screw (2) so that the cable is sufficiently tensioned so that the wheel lock release sensor (see figure) is actuated just before the cable pulls the release.

  • Page 24: Wheel Lock Release Sensor

    Wheel lock release sensor Wheel lock release sensor Removal 1. Switch off the main power switch on the control panel. 2. Put the circuit breaker in the “OFF” position. It is accessed through a hole in the chassis cover; see page 39. 3.

  • Page 25: Magnetic Wheel Lock

    Magnetic wheel lock Magnetic wheel lock Removal 1. Raise the seat to the highest position. If the chassis is equiped with fixed seat post, see page 34. If the seat elevator does not work normally because the batteries are discharged or the actuator is defective, the seat can be raised/lowered manually, see page 30.
  • Page 26 Magnetic wheel lock Fitting 1. Using the adjusting screws, adjust the magnet wheel lock in accordance with the instructions on the back of the magnetic wheel lock; see fig. Wheel lock adjustment is made using the two adjusting screws. Magnetic wheel lock, wheel lock disk, cover and rubber seal disassembled.
  • Page 27 Magnetic wheel lock 4. Insert a screw to align the parts. Attach the rubber seal with the drainage hole down. Be attentive to the position of the wheel lock release lever; fit the wheel lock so that the wheel lock release lever is aligned with the motor’s cable bracket.

  • Page 28: Drive Motor

    Drive motor Drive motor Removal 1. Raise the seat to the highest position. If the chassis is equiped with fixed seat post, see page 34. If the seat elevator does not work normally because the batteries are discharged or the actuator is defective, the seat can be raised/lowered manually, see page 30.
  • Page 29 Drive motor Drive motor 9. Remove the drive motor. It is attached with three screws; see fig. Fitting Fit the drive motor in the reverse order. Drive motor mounting screws. Drive motor with gear.

  • Page 30: Seat Elevator

    Seat elevator Seat elevator Manual Raising/ Lowering of the Seat elevator If the seat elevator does not work normally because the batteries are discharged or the actuator defective, seat raised/lowered manually. 1. Switch off the main power switch on the control panel.

  • Page 31: Removing The Seat Elevator

    Seat elevator Seat elevator Removal 1. Raise the seat to the highest position. If the seat elevator does not work normally because the batteries are discharged or the actuator is defective, the seat can be raised/lowered manually, see page 30. 2.

  • Page 32: Seat Elevator Cable

    Seat elevator cable & Seat elevator motor Seat elevator cable Removing 1. Remove seat elevator; follow instructions on page 31. 2. Remove the seat elevator sensors. Note the position of the sensors for refitting, see fig. Fitting Fitting is the reverse procedure. Attachment of the sensors to the seat elevator.

  • Page 33: Seat Elevator Drive Belt

    Seat elevator drive belt Seat elevator drive belt Removing 1. Remove the seat elevator, see page 31. 2. Loosen the two bolts holding the shaft to the seat elevator motor. Push the shaft sideways to slacken the drive belt. 3. Remove the belt from the motor shaft, then from the toothed wheel on the seat elevator screw.

  • Page 34: Fixed Seat Post

    Fixed seat post Fixed seat post Adjusting the Seat Height The length of the fixed seat post can be adjusted to five different fixed positions. 1. Switch off the main power switch on the control panel. 2. Loosen the screw that locks the fixed height position of the seat post.

  • Page 35: Removal

    Fixed seat post Fixed seat post Removal 1. Switch off the main power switch on the control panel. 2. Put the circuit breaker in the “OFF” position. It is accessed through a hole in the chassis cover; see page 39. 3.

  • Page 36: Control Panel

    Control panel Control panel Pilot+ Removal Switch off the main power switch on the control panel. Disconnect the control panel cable by pulling the connector at the rear of the control panel straight backwards. To remove the control panel, remove the screws holding the common bracket for the control panel and Seat control panel, see figure.

  • Page 37: Pilot+ Controller

    Pilot+ controller Pilot+ controller Removal 1. Raise the seat to the highest position. If the chassis is equiped with fixed seat post, see page 34. If the seat elevator does not work normally because the batteries are discharged or the actuator is defective, the seat can be raised/lowered manually, see page 30.

  • Page 38: Sls Drive Stage

    SLS Drive Stage SLS Drive Stage Removal 1. Raise the seat to the highest position. If the chassis is equiped with fixed seat post, see page 34. If the seat elevator does not work normally because the batteries are discharged or the actuator is defective, the seat can be raised/lowered manually, see page 30.

  • Page 39: Fuses

    Circuit breaker and fuses Circuit breaker and fuses Resetting the circuit breaker The circuit breaker also serves as a battery isolator but is normally referred to as a circuit breaker. Circuit breaker replacement is normally not required; it is of the automatic type that can be reset when tripped. NOTE A tripped circuit breaker often entails a major electrical fault.

  • Page 40: Sls Fuse

    Circuit breaker and fuses Circuit breaker and fuses Replacing the SLS Fuse The SLS fuse is located in its holder on the top of the left battery. 1. Switch off the main power switch on the control panel. 2. Put the circuit breaker in the “OFF” position. It is accessed through a hole in the chassis cover;...

  • Page 41: Fuse For Seat/Lighting

    Circuit breaker and fuses Circuit breaker and fuses Replacing Fuses for the Seat/Lighting There are two fuses on the SLS Drive stage, F1 (24V unswitched) and F2 (24V switched). These protect two outlets. One output (24V unswitched) supplies power regardless of if the chair is turned on or off.

  • Page 42: Esp Module

    ESP module ESP module (Applies to C500S) Removal 1. Raise the seat to the highest position. If the chassis is equiped with fixed seat post, see page 34. If the seat elevator does not work normally because the batteries are discharged or the actuator is defective, the seat can be raised/lowered manually, see page 30.
  • Page 43 ESP module 5. The ESP module is ready programmed from factory. module reprogrammed, see the technical manual of the ESP module for full details. WARNING The ESP module and the Pilot+ output connection must be correctly programmed when the wheelchair is in use. Otherwise the wheelchair may be very difficult to maneuver, with a high risk of accidents.
  • Page 44 ESP module ESP module (Applies to C500S Lowrider) Removal 1. Raise the seat to the highest position. If the chassis is equiped with fixed seat post, see page 34. If the seat elevator does not work normally because the batteries are discharged or the actuator is defective, the seat can be raised/lowered manually, see page 30.
  • Page 45 ESP module 5. The ESP module is ready programmed from factory. module reprogrammed, see the technical manual of the ESP module for full details. WARNING The ESP module and the Pilot+ output connection must be correctly programmed when the wheelchair is in use. Otherwise the wheelchair may be very difficult to maneuver, with a high risk of accidents.

  • Page 46: Lights

    Lights Lights (Accessories) Removing the front lights 1. Switch off the main power switch on the control panel. 2. Put the circuit breaker in the “OFF” position. It is accessed through a hole in the chassis cover; see page 39. 3.
  • Page 47 Lights Lights (Accessories) Removing the rear lights 1. Switch off the main power switch on the control panel. 2. Put the circuit breaker in the “OFF” position. It is accessed through a hole in the chassis cover; see page 39. 3.

  • Page 48: Control System

    The control system can also be programmed in order to make adjustments needed for a specific user. To get more information about standard parameter files, contact your dealer, or Permobil Inc. USA. The chart below shows the different standard parameter files that are available.

  • Page 49: Trouble Shooting

    The troubleshooting guide below describes a number of events that can arise when you use your wheelchair, as well as providing suggestions for solutions. Note that this guide does not describe all the possible events that can arise, and you should always get in touch with your service contact or Permobil when you are unsure...
  • Page 50 Trouble Shooting Guide Error signals - Battery voltage indicator Every time the wheelchair is started up, a check is performed on parts of the wheelchair’s electronics. If any faults have arisen in these parts, this is shown on the control panel’s battery voltage indicator by one or more blinking lights.
  • Page 51 Trouble Shooting Guide CAUSE SOLUTION Check the battery and the connections between the High battery voltage battery and the control unit. Green Failure in wheel lock circuit Check the connections to the magnetic wheel lock. Green Check the contacts to the output stage. If the fault Fault in electronics persists, change the output stage.

  • Page 52: Cabling Overview

    Cabling overview...

  • Page 53: Cabling Overview

    Cabling overview Cabling overview...

  • Page 54: Distribution Chart

    Distribution chart...
  • Page 55 Distribution chart Distribution chart...
  • Page 56 Notes...

  • Page 57: Index

    Index Index Batteries ..........8 Magnetic wheel lock ......25 Cabling overview ......52 Pilot+ controller ......37 Control panel ........36 Control System ........ 48 Covers ..........7 Rear wheels ........12 Rear wheel suspension ....17 Distribution Chart ......54 Drive motor ........
  • Page 60 Order no.: 205210-US-0...
