SECURING THE CHILD CAR SEAT USING THE ISOFIX CONNECT
SYSTEM
Using the ISOFIX Connect system, you can fi x the CYBEX SOLUTION
M-FIX to the vehicle, thereby increasing your child's safety. The child still
needs to be secured with the three-point belt of your vehicle.
• Insert the supplied ISOFIX guides (u) with the longer strap upwards into the two
ISOFIX fi xture points (j). In some vehicles, it is better to mount the ISOFIX guides
aids (u) in the opposite direction.
Note! The ISOFIX fi xture points (j) are two metallic clips for each seat and are
positioned between the backrest and the seating surface of the vehicle seat. In case
of doubt, please refer to the driver's manual of your vehicle.
• Use the adjustment lever (v) under the seat cushion (d)
• Pull the two ISOFIX Connect locking arms (o) as far as they will go.
• Now twist the ISOFIX Connect locking arms (o) 180° so that they are facing the
direction of the ISOFIX guides (u).
Note! Before clicking the the ISOFIX Connect locking arms (o) into the ISOFIX
fi xture points (j), check the release buttons (y). If the green safety indicators (b) are
visible, you must fi rst release the ISOFIX Connect locking arms before joining by
pressing and pulling back the release button (y). Repeat the process if necessary
with the second locking arm.
A perceptible click will be heard when the ISOFIX Connect locking arm correctly
locks into place with the ISOFIX fi xture points.
• Push the two locking arms (o) into the ISOFIX guides (u) until these lock into place
in the ISOFIX fi xture points with an audible 'click'.
• Ensure that the seat is secure by trying to pull it out of the ISOFIX guides (u).
• The green safety indicator (b) must now be clearly visible on the two red release
buttons (y).
• You can now use the adjustment lever (v) on the frame (d) of the CYBEX
SOLUTION M-FIX child car seat position.
Note! Note the information in the section "PLACING THE SEAT IN THE VEHICLE".
