Series Number; Temperature Sensors - Distform MyChef 4 GN 2/3 Installation, Use And Maintenance Manual

Navigate between the various setup menu settings by pressing the
and turning the knob.

7.14.0 Series number

Displays the electronic control panel series number.
The series number is the combination of the value that appears in the temperature
display and the time display. In the image, the series number would be 879587.
7.14.1

Temperature sensors

Allows you to see and change the P01 to P09 temperature sensors.
Sensor Sensor description
P01 Temperature probe point 1.
P02 Temperature probe point 2. (Only on multi-point probes).
P03 Temperature probe point 3. (Only on multi-point probes).
P04 Not used.
P05 Not used.
P06 Not used.
P07 Not used.
P08 Chamber probe.
P09 Internal temperature sensor for the electronic system.
If the temperature of a sensor is greater than 350ºC or lower than -50ºC,
the probe is not properly connected.
Figure 37: Control panel series number.
Table 12: Temperature sensors.
155
button
