Figure 4. Electrical terminal connectors.
Once the connection is made, ensure that there are no loose wires and that all
wires are firmly secured. Also check the wire stuffing box.
Never connect a phase to neutral or ground wires. Check that the
installation voltage corresponds to the appliance power requirements.
In the following subsections, three types of possible connections for MyChef ovens
are shown.
Figure 5: Wire input.
133
