5.1.2 Three-phase connection 230V 3L

Figure 8: Three-phase connection 230V 3L.
Color
■
Yellow-green
■
Brown
■
Black
■
Grey
Oven Total Power
4GN 1/1 5.6 kW
6GN 2/3
5.6 kW
6GN 1/1 7.0 kW
10GN 1/1
11.2 kW
Table 6: Power, current, and minimum length for MyChef three-phase 230V 3L.
Figure 9: Three-phase connection 230V 3L.
Table5: Three-phase wire 230V 3L+N.
Maximum current
19A
19A
24A
37A
135
Wire
Tierra
L1
L2
L3
Minimum wire length
2.5 mm
2.5 mm
2.5 mm
2
2
2
6 mm
2
