5.1.1 Three-phase connection 400V 3L+N

Figure 6: Three-phase connection 400V
■
Yellow-green
■
Blue
■
Brown
■
Black
■
Grey
Oven Total Power
4GN 1/1
6GN 2/3
6GN 1/1
10GN 1/1
Table 4: Power, current, and minimum length for MyChef three-phase 400V 3L+N.
3L+N.
Color
Table 3: Three-phase wire 400V 3L+N.
Maximum current
5.6 kW
5.6 kW
7.0 kW
11.2 kW
Figure 7: Three-phase connection 400V 3L+N
Wire
Ground
Neutral
L1
L2
L3
Minimum wire length
19A
19A
24A
37A
134
2.5 mm
2
2.5 mm
2
2.5 mm
2
6 mm
2
