TR 650 TERRA 2013 TR 650 STRADA 2013 Workshop Manual Ed. 09-2012 Rev 00...
Page 2
Page Description HUSQVARNA MOTORCYCLES S.R.L. - Varese disclaims all liabilities for any errors or omissions in this manual and reserves the right to make changes to reflect on-going product development. Illustrations in the manual may differ from actual components. No reproduction in full or in part without written authorisation.
FOREWORD, TABLE OF CONTENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Workshop Manual TR 650 TERRA 2013 TR 650 STRADA 2013 Copyright by HUSQVARNA MOTORCYCLES S.R.L. BMW Group Technical Service Via Nino Bixio, 8 21024 (Varese) - Italy tel.
TR 650 TERRA 2013 - TR 650 STRADA 2013 Foreword This publication is designed for use by HUSQVARNA Service Centres to assist authorised personnel in the maintenance and repair of the models covered in this manual. The technical information provided in this manual is a critical comple- ment to operator training and operators should become thoroughly familiar with it.
FOREWORD, TABLE OF CONTENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Table of Contents Title Section Foreword, table of contents ................. a Important notices ....................b General information .....................A Maintenance ......................B Troubleshooting ....................C Settings and adjustments ................... D General procedures .....................E...
IMPORTANT NOTICES TR 650 TERRA 2013 - TR 650 STRADA 2013 GENERAL SAFETY WARNINGS Read these general recommendations carefully before using the vehicle. Carbon monoxide Only run the engine in an open or very well ventilated area. If you do work in an enclosed area, make sure you use a fume extraction system.
IMPORTANT NOTICES TR 650 TERRA 2013 - TR 650 STRADA 2013 Battery Recharge the battery in well ventilated areas since the battery produces toxic, highly inflammable gases when being recharged; do not smoke or use naked flames or sparks. The liquid in the battery is highly corrosive. If it comes into contact with the skin, rinse thoroughly with running water.
IMPORTANT NOTICES TR 650 TERRA 2013 - TR 650 STRADA 2013 RECOMMENDED SHOP PRACTICES Before disassembling components or before performing repair operations, clean the motorbike removing possible mud, dust, or foreign bodies. Put the vehicle in a well lit area;...
GENERAL INFORMATION TR 650 TERRA 2013 - TR 650 STRADA 2013 Engine Single cylinder, 4 stroke engine with four valves Cooling ................liquid and electric fan Bore ..................3,937 in (100 mm) Stroke ..................3,268 in (83 mm) Displacement ..............39,787 in (652 cm Compression ratio ..................12,3:1...
GENERAL INFORMATION TR 650 TERRA 2013 - TR 650 STRADA 2013 Final ratios 1st gear....................15.722 2nd gear ....................10.005 3rd gear ....................7.506 4th gear .....................5.974 5th gear .....................2.898 Chassis Single frame, in round, rectangular and ellipsoidal steel pipes; rear steel chassis Front suspension Upside down type hydraulic fork......ø...
GENERAL INFORMATION TR 650 TERRA 2013 - TR 650 STRADA 2013 Dimensions, weight, capacity Wheelbase ..........................55,055 in (1500 mm) Total length (STRADA) ......................88,504 in (2248 mm) Total length (TERRA)......................89,252 in (2267 mm) Overall width ...........................34,843 in (885 mm) Max.
MAINTENANCE TR 650 TERRA 2013 - TR 650 STRADA 2013 Section Workshop Manual Ed. 09-2012...
Page 18
MAINTENANCE TR 650 TERRA 2013 - TR 650 STRADA 2013 TR 650 STRADA SCHEDULED MAINTENANCE CHART TR 650 TERRA (TO BE CARRIED OUT AT THE HUSQVARNA DEALER) ENGINE SERVICE SERVICE SERVICE SERVICE SERVICE COUPON COUPON COUPON COUPON COUPON AFTER EVERY...
Page 19
MAINTENANCE TR 650 TERRA 2013 - TR 650 STRADA 2013 TR 650 STRADA SCHEDULED MAINTENANCE CHART TR 650 TERRA (TO BE CARRIED OUT AT THE HUSQVARNA DEALER) CHASSIS SERVICE SERVICE SERVICE SERVICE SERVICE COUPON COUPON COUPON COUPON COUPON AFTER THE...
TROUBLESHOOTING TR 650 TERRA 2013 - TR 650 STRADA 2013 Section Manuale d'officina Ed. 09-2012...
Page 22
TROUBLESHOOTING TR 650 TERRA 2013 - TR 650 STRADA 2013 ENGINE Trouble Possible causes Remedy Ignition switch not in ON position Switch ignition switch to position ON Engine-stop-switch on OFF position Switch to position ON Starter motor does not operate or does not...
Page 23
TROUBLESHOOTING TR 650 TERRA 2013 - TR 650 STRADA 2013 Trouble Possible causes Remedy Check fuel pressure sensor, fuel pump and Fuel pressure too low fuel supply Leak air Check / replace intake socket Engine runs irregularly at higher speed...
Page 24
TROUBLESHOOTING TR 650 TERRA 2013 - TR 650 STRADA 2013 Trouble Possible causes Remedy Not enough coolant in cooling system, cool- Refill coolant, check system under pressure ing system leaking, air in cooling system Cooling fan motor defective Replace cooling fan motor...
Page 25
TROUBLESHOOTING TR 650 TERRA 2013 - TR 650 STRADA 2013 Trouble Possible causes Remedy Pressure regulating piston blocked (bypass Check/replace pressure regulating piston valve stuck in closed position) High engine oil pressure Oil circuit blocked Clean oil ducts Manuale d'officina Ed. 09-2012...
Page 26
TROUBLESHOOTING TR 650 TERRA 2013 - TR 650 STRADA 2013 Trouble Possible causes Remedy Noise is heard when the engine is started: Sprag clutch, sprag clutch housing or free- Replace Sprag clutch, sprag clutch housing wheel gear worn or freewheel gear...
Page 27
TROUBLESHOOTING TR 650 TERRA 2013 - TR 650 STRADA 2013 Trouble Possible causes Remedy Fatigue of clutch springs Replace clutch springs Clutch slips Clutch plates worn or warped Replace clutch plates Engine oil not according to specifications Exchange engine oil...
Page 28
TROUBLESHOOTING TR 650 TERRA 2013 - TR 650 STRADA 2013 CHASSIS Trouble Cause Remedy Insufficient tyre pressure Inflate Bearing adjuster ring nut or steering stem Adjust nut overtightened Handlebar turns hard Bent steering stem Replace bottom yoke Worn or seized steering bearings...
Page 29
TROUBLESHOOTING TR 650 TERRA 2013 - TR 650 STRADA 2013 ELECTRICAL SYSTEM (see also Section M) Trouble Cause Remedy Dirty air filter Clean Spark plug fouls easily Worn piston rings Replace Worn piston or cylinder liner Replace Spark plug electrode gap too close...
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Section Workshop Manual Ed. 09-2012...
Page 32
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Sommario Saddle removal.....................D.3 Removal of central upper cover..............D.4 Side panel removal ..................D.4 Throttle cable adjustment ................D.5 Throttle control....................D.5 Throttle position adjustment .................D.5 Front brake control ..................D.5 Position adjustment ..................D.5 Front brake lever adjustment and fluid level check ........D.6...
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Saddle removal To remove the saddle proceed as follows: Insert the key in the lock (1) positioned in the rear part of the motorcycle; turn the key clockwise to release the saddle (2), and then lift it and pull it out towards the rear, releasing it from the front fastener.
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Removal of central upper cover Unscrew the four screws (1) that fasten the cover (2) and remove it. H11662 Side panel removal Remove the saddle as described in the relevant paragraph.
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Throttle cable adjustment To check the correct adjustment of the throttle control cable, operate as follows: remove the reservoir and the filter box as outlined in the relevant sections;...
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Front brake lever adjustment and fluid level check The level of the fluid in the master cylinder reservoir must never be below the minimum level visible through the inspection sight glass (1) on the side of the master cylinder (2) body.
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Clutch control lever distance adjustment The lever (1) can be adjusted (3 settings available) to suit the rider's hand size To regulate the position of the lever (1) push it outwards and then select the required position by means of the adjuster screw (2).
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Rear brake pedal free play adjustment Before staring the braking action, rear brake pedal (1) shall have a free play (B) of 5-10 mm (0,196 ÷ 0,39 in.). Should this not happen, operate as follows: Loosen the nut (2);...
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Oil level check The oil level must be checked with the vehicle in vertical position on a flat sur- face. - Start the motorcycle and heat the engine until the cooling fan starts; wait for another 3 minutes and switch off the engine.
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Replacement of cartridge filter - Unscrew the screws (5) and remove the sprocket casing (6). - Unscrew the screws (7) and remove the oil filter cover (8). - Replace the filter (9) with a new one, then refit the cover (8) making sure that the O-ring (10) is not damaged and positioned correctly on the cover.
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Filling - Remove the cap (1) with the dipstick. - Pour 1.5 litres of oil into the chassis tank. - Run the engine for 30 seconds and then switch it off.
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Coolant replacement Drainage - Place the motorcycle on its side stand. - Remove the cap (1) of the expansion tank (2). - Place a 2 litre container under the water pump and unscrew the screw (3).
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Air filter check Note: Clean the filter area before removing the cover. - Unscrew the screws (1) and remove the cover (2) together with the filter (3); - remove the filter (3) and check that it is not clogged/dirty; replace if neces- sary;...
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Chain tension adjustment Chain should be checked, adjusted and lubricated as per the Maintenance Chart to ensure safety and prevent excessive wear. If the chain becomes badly worn or is adjusted incorrectly (i.e., it is too loose or too tight), it could jump out of the sprocket or break.
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Suspension The vehicle leaves the factory with standard settings for the front and rear sus- pension that meet most requirements. Before making any change and afterwards, if the adjustment is not satisfactory, always start from the standard suspension setting and increase or decrease the adjusting clicks, one at a time.
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Rebound shock absorber hydraulic damping adjustment It is possible to adjust the rebound travel of the shock absorber. B) REBOUND - Standard setting: - 11 clicks (adjuster 1) To reset the standard setting, turn lower adjuster (1) clockwise until reaching fully closed position.
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Exhaust system check Perform a visual inspection of the exhaust system first, in order to identify pos- sible gas leaks from the sealing elements (gaskets), and to ensure that the Silent-Blocks are not damaged.
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Idle speed adjustment The idle speed is pre-set by the control unit (1550 rev/min.) and the stepper motor ensures that this value is preserved. No manual adjustment is possible, nor any adjustment through the diagnostic tool.
Page 49
SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 - Loosen the clamp (9) and remove the intake coupling (10) from the cylinder head. When refitting the intake coupling (10) make sure you place the prong (A) on the slot (B) of the intake manifold.
ENGINE SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Section Refer to chapter F4 for all engine tightening torques. Workshop Manual Ed.09-2012...
Page 52
ENGINE SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Sommario VALVE CLEARANCE CHECK ..............F.3 Valve clearance check .................. F.3 Valve clearance measurement ..............F.3 PAD REPLACEMENT ................. F.4 Locking the crankshaft.................. F.4 Chain tensioner disassembly................ F.5 Chain guide disassembly................
ENGINE SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 VALVE CLEARANCE CHECK Remove the coil / spark plug cap, spark plugs and the head cover as described in chapter "F1". Valve clearance check Remove the screw plug (1).
ENGINE SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 PAD REPLACEMENT Bring the to the top dead centre as described in the previous paragraph and lock the crankshaft. H11487 Locking the crankshaft Remove the screw (1) with the sealing ring.
ENGINE SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Chain tensioner disassembly Remove the screw (1) with the sealing ring (2) and chain tensioner (3). H11491 H11490 Chain guide disassembly Remove the screws (1) and chain guide (2).
ENGINE SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Camshaft removal Remove the screws (1) with the washers.(2). Remove the top part of the support (3). - Remove the chain (4) from the gears and fix to a point safe to avoid it from falling into the engine. Remove the camshafts (5) with the chain gears.
ENGINE SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 Chain tensioner installation Insert the chain tensioner (1) and tighten the screw (2) replacing the gaskets (3). H11496 H11497 Chain guide installation Clean the threading and screws.
ENGINE SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 TIMING CHECK Remove the coil / spark plug cap, head cover, spark plugs and chain tensioner and the head cover as described in chapter "F1". Remove the screw (1) with the sealing ring.
ENGINE SETTINGS AND ADJUSTMENTS TR 650 TERRA 2013 - TR 650 STRADA 2013 ENGINE PHASING Proceed as follows to rephase the engine. Remove the head cover as described in chapter "F1". Lock the crankshaft as previously described. Remove the chain tensioner and guide as previously described.
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Section Refer to chapter F4 for all engine tightening torques. Workshop Manual Ed.09-2012 F1.1...
Page 62
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Sommario CLUTCH COVER REMOVAL / INSTALLATION .........F1.3 Gearbox lever removal/installation ............F1.3 Clutch cover removal ................F1.3 Remove the left engine crankcase cover ..........F1.3 Coolant pump cover removal ..............F1.4 Left engine cover removal ..............
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 CLUTCH COVER REMOVAL / INSTALLATION Gearbox lever removal/installation Removal: Loosen the screw (1) then remove the lever (2). Installation: Fit the lever (2) and tighten the screw to torque (1).
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Coolant pump cover removal Remove the pipe (1) from the pump cover (2). Remove the screws (3). Remove the coolant pump cover (2) and its gasket. H11760 Check gasket condition when refitting and replace if necessary.
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Clutch engagement lever removal/refitting Removal: Undo the screws (1) and slide the lever out upwards (2). H11514 Installation: Manually turn the shaft (3) clockwise until reaching the limit.
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Clutch disengagement shaft bearing removal Remove the two needle roller bearing using an appropriate tool (1). H11519 Installation of both clutch disengagement shaft bearings Lightly lubricate both bearings with engine oil.
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Left engine crankcase cover assembly - Clean the sealing faces and fit a new gasket. Turn the water pump impeller until the transmission sprocket mates correctly. Tighten the screws (1) replacing the sealing ring (2). Check that the broaching of the clutch disengagement shaft mates properly with the clutch centre pin.
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Crankshaft sensor and stator removal Unscrew the screws (1). Remove the bracket (2) with the sensor (4). Remove the cable ring (3). H11527 Unscrew the screws (5). Remove the cable ring (6) and stator (7).
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Mounting the ignition cover - Clean the sealing faces and fit a new gasket. Install the cover (2), being careful with the washer (3) (arrow) and bushing (4). Install the screws (1) of the engine casing cover, right side, tightening to torque in a cross pattern.
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Flywheel and starter motor idle gear removal - Remove the right crankcase and fix the engine at the top dead centre, as described in the relevant paragraphs. - Heat the flywheel hub (1) to a temperature of approx. 100°C. Unscrew the nut (2) and washer (3). - Remove the flywheel together with the freewheel (4) using a suitable puller. H11535 H11536 Removal/installation of the freewheel from/on the flywheel - Heat the freewheel to about 120°C.
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Starter motor idle gear removal/installation Remove the washer (1) and bushing (2). Remove the dual gearbox (4). Remove the idle gear (3). H11539 Remove the freewheel gear (5) Reassemble all parts, in the reverse order compared to disassembly.
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 CHAIN SPROCKET REMOVAL/INSTALLATION Removal: Remove the screw (1). Remove the bushing (2) and the tapered washer (3). Remove the sprocket (4), using a puller if necessary, being careful not to ruin the shaft threading.
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 REMOVING THE NEUTRAL POSITION SENSOR Remove the screw (2). Remove the connection cable. Unscrew the sensor (1) and replace it. Screw on a new sensor with Loctite 243.
Page 74
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Remove the washer (12) and the "OR" gasket (13). Disassemble the clutch housing (14), paying attention to the needle roller bearings (15) and to the washer (16). H11554 Installation: Lubricate the needle roller bearings (15) with engine oil.
Page 75
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Fit the thrust washer (8) and the Belleville washer (7) so that the greater diameter faces outwards. Lubricate the lined plates (6) with engine oil. - Insert first a lined plate (5) then a steel disc (6) and alternate layers until ending with a lined plate.
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Clutch pressure plate disassembly Disassemble the pressure plate (1) as described in the paragraph "Clutch disassembly". Remove the circlip (2). Remove the actuator pin (3), the rounded washer (4) and the Belleville washer (5).
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 PUMPS Oil pump removal/installation Remove the clutch as described in the relevant paragraph. A) Supply pump B) Intake oil pump Removal: Remove the retaining ring (2). Disassemble the gear (3).
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 REPLACEMENT OF THE OIL PRESSURE VALVE AND UNIDIRECTIONAL VALVE - Position a container under the oil filter cover in order to collect the oil in the filter seat and oil filter. Loosen the two screws (1) and remove the oil pump cover (2). - Remove the oil filter (3). - Clean the filter box of residual oil.
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 COOLANT FLUID PUMP REMOVAL/INSTALLATION Remove the pump cover and left cover as described in the relevant paragraph. Removal: Remove the transmission sprocket (1) of the pump shaft. Remove the pin (2) paying attention to the washer (3).
GENERAL ENGINE PROCEDURES TR 650 TERRA 2013 - TR 650 STRADA 2013 REMOVAL/INSTALLATION OR REPLACEMENT OF THE TIMING CHAIN Remove the head cover and the camshafts as described in the relevant paragraphs. Fix the timing chain with metal wire so that it does not slip into the engine.
CYLINDER HEAD REMOVAL/DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Section Refer to chapter F4 for all engine tightening torques. Workshop Manual Ed.09-2012 F2.1...
Page 82
CYLINDER HEAD REMOVAL/DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Sommario Removal of the ignition coils ...............F2.3 Cylinder head cover removal/installation ............F2.3 Chain tensioner removal/installation............F2.4 Locking the crankshaft................F2.4 Crankshaft locking screw removal ..............F2.5 Camshaft removal/replacement..............F2.5 Checking the decompression lever ............F2.6 Removing the decompression lever ............F2.6...
CYLINDER HEAD REMOVAL/DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Removal of the ignition coils Using an appropriate tool remove the coil (1) of the main spark plug, and the coil (2) of the secondary spark plug. Do not mount coils in inverse positions.
CYLINDER HEAD REMOVAL/DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Chain tensioner removal/installation Removal: Remove the screw (1) with the sealing ring (2). Remove the chain tensioner (3) from the hole. Installation: Insert the chain tensioner (3) into the hole.
CYLINDER HEAD REMOVAL/DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Crankshaft locking screw removal Remove the locking screw (1) and re-tighten the screw (2) to torque, replac- ing the gasket. H11499 H11654 Camshaft removal/replacement Remove the head cover and lock the engine at the top dead centre, as de- scribed in the relevant paragraphs.
CYLINDER HEAD REMOVAL/DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Checking the decompression lever - With the spring fully extended, the minimum projection of the weight is equal to A: 0.7 mm (0.03 in). - When activated, the projection of the centrifugal weight on the base circum- ference of the cam must not be less than the measurement (A). Replace the decompression lever if the distance is lower.
CYLINDER HEAD REMOVAL/DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Camshaft assembly Lubricate all contact surfaces with engine oil. - Fit the camshaft exhaust (1a), then the cam shaft intake (1b) with the timing chain and positioning them in phase. Mount the top part of the support (2). Tighten the screws (3) with the washers.(4).
CYLINDER HEAD REMOVAL/DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Cylinder head removal/installation - replacement of cylinder head gasket Remove the camshafts, timing chain sliders as described in the relevant paragraphs. Removal: Undo screws (1) and (2) H11581...
Page 89
CYLINDER HEAD REMOVAL/DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Remove the gasket (8). Installation: Clean the sealing surfaces and eliminate all traces of oil and grease. Replace the gasket (8) and position it on the cylinder. Pull the timing chain (9) through the well.
CYLINDER HEAD REMOVAL/DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Valve removal - Mark the valve buckets (1) so that they can be refit in the same positions, use a suitable tool to remove them. Remove the pads (2) and position on their respective valve buckets. H11590 Place the cylinder head on the support plate (3) so that the valves do not come into contact with the work bench.
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Section Refer to chapter F4 for all engine tightening torques. Workshop Manual Ed.09-2012 F3.1...
Page 92
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Sommario Cylinder disassembly/installation..............F3.3 Piston removal/ installation .................F3.4 Measurement of a piston and cylinder............F3.5 CRANKCASE DISASSEMBLY ..............F3.6 Crankshaft disassembly ................F3.8 Crankshaft and countershaft installation ..........F3.10 Crankshaft axial clearance check .............F3.10 Removal/refitting the countershaft and checking axial clearance.....
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Cylinder disassembly/installation Removal: Remove the head cover as described in the relevant paragraph. Remove the complete head as described in the relevant paragraph. Remove the screws (1). Press the chain tensioner forward and extract the cylinder with care, making sure that the piston does not strike the engine casing.
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Piston removal/ installation Remove the cylinder as described in the relevant paragraph. Removal: Cover the engine crankcase with paper. Mark the exhaust side of the piston crown with a marker.
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Measurement of a piston and cylinder Inspecting the cylinder: Check that the cylinder liner and sealing surfaces are not damaged. Using a bore gauge for internal areas, measure the cylinder diameter in three points (1), (2) and (3).
Page 96
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 CRANKCASE DISASSEMBLY Crankcase disassembly: Remove the starter motor. Remove the flywheel. Remove the starter motor idle gear. Remove the chain sprocket. Remove the coolant pump cover. Remove the complete clutch.
Page 97
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Assembly: Check that the washers (1) are installed correctly (also see the relevant paragraph on checking the axial clearance). Clean the sealing faces and fit a new gasket (2).
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Crankshaft disassembly Disassemble the crankcase as described in the relevant paragraph. Removal: Match the marking (1) of the countershaft and marking (2) of the crankshaft with the crankcase marking (3).
Page 99
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Check the wear of the crankshaft in correspondence of the "Z" contact area of the bushings: wear limit ø 45.96 mm (1.81 in.). Replace the crankshaft and bearings if this value is exceeded.
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Crankshaft and countershaft installation Place the right crankcase half with the flywheel side facing down. Oil the crankcase bearing seats. Position the crankshaft washer on the right casing. Insert the countershaft (1) and the crankshaft (2) in the crankcase and phase them;...
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Removal/refitting the countershaft and checking axial clearance Disassemble the crankcase as described in the relevant paragraph. Removal: Match the marking (1) of the countershaft and marking (2) of the crankshaft with the crankcase marking (3).
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Countershaft clearance check On the right crankcase half of the engine with an appropriate tool measure the distance from countershaft bearing seat to the outer surface of the crankcase (B).
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Crankshaft gear removal Place the crankshaft in a vice with protection clamps. Use a puller to extract the gear. H11624 Gear installation Heat the gear to approx. 140°C. Fit a pin (1) into the gear (2) and mount onto the crankshaft until it stops by using a suitable tool, centring the pin (1) with the hole in the crankshaft.
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Installation: Heat the left crankcase half to approx. 100°C. Use an appropriate tool to install the bearing (1) into the crankcase half with the closed side towards the outside.
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Gearbox shafts installation Oil the gearbox shaft main bearing seats. Install the input shaft (3) and output shaft (4) of the gearbox. Use a plastic mallet to tap the shafts until they are fully mated with their seats.
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Disassembly/assembly of the gearbox input shaft (shaft removed) Disassembly: Secure the gearbox input shaft (1) in a vice with protective clamps. Remove the cogwheels (2) and (3). Be careful not to damage the needle roller bearings during disas- sembly.
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Disassembly/assembly of the gearbox output shaft (shaft removed) H11634 Disassembly: Secure the gearbox output shaft (1) in a vice with protective clamps. Remove the ring (2). Extract the gear (3) and (4) with the needle roller bearing (5) and washer (6).
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Replacement of the gearbox control shaft (engine disassembled) Removal: Move the lever (1) outwards and extract the gearbox shaft (2) complete with lever (1). Extract the ratchet (3) and spring...
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Replacement of the selector drum (engine disassembled) Lift the pins (1) slightly until extracting them from the crankcase. Move the pins and forks to free the drum (2). Extract the selector drum (2).
CRANKCASE DISASSEMBLY TR 650 TERRA 2013 - TR 650 STRADA 2013 Replacement of the gearbox shaft bearings (shafts removed) Removal: Heat the crankcase to about 80-100°C. Extract the bearing (1) of the input shaft and the bearing (2) of the output shaft with a puller.
ENGINE TORQUE FIGURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Section Tighten all nuts and screws to the specified torque using a torque wrench. An insufficiently tightened screw or nut could get damaged or come completely loose, damaging the motorcycle and/or injuring the rider. A screw or nut tightened beyond the permitted max.
ENGINE PARTS WEAR LIMITS TR 650 TERRA 2013 - TR 650 STRADA 2013 Section Workshop Manual Ed.09-2012 F5.1...
Page 132
ENGINE PARTS WEAR LIMITS TR 650 TERRA 2013 - TR 650 STRADA 2013 Table of Contents Engine block ....................F5.3 Cylinder head and cover................F5.3 Crankshaft and bearings ................F5.3 Connecting rods and bearings ..............F5.3 Piston with rings and bearings ..............F5.3 Countershaft ....................F5.4 Camshaft ....................F5.4...
Page 133
ENGINE PARTS WEAR LIMITS TR 650 TERRA 2013 - TR 650 STRADA 2013 WEAR VALUE TABLE FOR ENGINE Description Condition Engine block 100.00 + 0.025 mm New, from top edge 60 mm (2.3622 in.) 3.937 + 0.001 in. Cylinder bore diameter 100.05 mm...
Page 134
ENGINE PARTS WEAR LIMITS TR 650 TERRA 2013 - TR 650 STRADA 2013 WEAR VALUE TABLE FOR ENGINE Description Condition 0.015 ... 0.029 mm 0.0006 ... 0.0011 in. Radial clearance of the pin in the connecting rod max 0.050 mm Wear limit max 0.002 in.
TIGHTENING TORQUE FIGURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Section Tighten all nuts and screws to the specified torque using a torque wrench. If not tightened securely, a nut or a screw might become damaged or work itself loose, causing damage to motorcycle and injury to rider. An overtightened nut or screw might become damaged, its thread might strip, or the nut/screw might fail and work itself loose.
Page 136
TIGHTENING TORQUE FIGURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Description of tasks Safety Assembly cycle Comment torque Fastening of tank assembly screw on LH side Fastening of mesh oil filter on chassis 10,0 Fastening of oil pipe clamps...
Page 137
TIGHTENING TORQUE FIGURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Description of tasks Safety Assembly cycle Comment torque Insert piston pin in swinging arm seat GREASE Insert piston pins in seats of rear suspension kinematic mechanisms GREASE Fastening of top of shock absorber...
Page 138
TIGHTENING TORQUE FIGURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Description of tasks Safety Assembly cycle Comment torque Fastening of BLOW-BY pipe from filter box to engine ignition cover Fastening of BLOW-BY pipe to filter box Fastening of horn...
Page 139
TIGHTENING TORQUE FIGURES TR 650 TERRA 2013 - TR 650 STRADA 2013 Description of tasks Safety Assembly cycle Comment torque Fastening of turning indicators Fastening of licence plate light to number plate holder seat Fastening of tail light to number plate holder seat...
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 Section Workshop Manual Ed. 09-2012...
Page 142
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 Sommario Chassis ......................Y.3 Lubrication points (lubricant) ................ Y.3 Front wheel ....................Y.6 Front wheel ....................Y.7 Removing the front wheel ................Y.8 Reassembling the front wheel ..............Y.9 Rear wheel ....................
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 Chassis The chassis is a tubular steel trellis type with stainless steel removable rear small chassis. In case of violent shocks or accidents, if you think that the chassis might be bent or damaged, proceed with an im- mediate inspection and, if necessary, replace it.
Page 144
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 H11746 H11723 Workshop Manual Ed. 09-2012...
Page 145
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 Check the assemblies shown in the figure for cracks or damage. If any are found, replace the part. A ENGINE MOUNTING SCREWS B REAR CHASSIS MOUNTING SCREWS C FOOTREST-PINS-SPRINGS...
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 Removing the front wheel Set a stand or a block under the engine and see that the front wheel is lifted from the ground. H11726 Loosen the bolts (1) holding the wheel axle (2) to the front fork mounts.
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 Reassembling the front wheel Fit the L.H. spacer (1) on the wheel hub. Fit the wheel between the fork legs so as to set the brake disc into the calliper.
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 Rear wheel STRADA H11734 Tyre Internal spacer Ball bearing Retaining circlip Sealing ring Spacer Tone wheel Spacer 10) Anti-vibration buffer rubber ring 11) Sprocket carrier 12) Spacer 13) Chain sprocket...
Page 151
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 Rear wheel TERRA H11735 Tyre Air chamber Spacer Ball bearing Retaining circlip Sealing ring Spacer Spacer 10) Tone wheel 11) Anti-vibration buffer rubber ring 12) Sprocket carrier 13) Spacer...
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 Removing the rear wheel (procedure valid for all models) Set a stand or a block under the engine and see that the rear wheel is lifted from the ground.
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 Wheel axle warpage Use a feeler gauge to check the pint out-of-round; if the value of the warpage REAR exceeds the max allowed limit, replace it. Axle runout over 100 mm...
CHASSIS AND WHEELS TR 650 TERRA 2013 - TR 650 STRADA 2013 Rear chain sprocket, secondary drive sprocket and chain The figure at the side shows the profiles of a normally worn and an exceedingly worn sprocket. 1 Normal wear...
