NEC NL8060AC26-04 10.4" TFT

Item
Display area
Drive system
Display colors
Number of pixel
Pixel arrangement
Pixel pitch
Module size
Weight
Contrast ratio
Viewing angle
Viewing direction
Color gamut
Response time
Luminance
Signal system
Supply voltage
Backlight
211.2mm(H)x158.4mm(V) (10.4" diagonal)
a-Si TFT active matrix
262,144 colors
800x600
RGB vertical stripe
0.264mm(H)x0.264mm(V)
243.0mm(H)x179.0mm(V)x8.0mm(D)
Typical 410g
Typical 150:1
Horizontal-left 45°
Horizontal-right 45°
Vertical-up 25°
Vertical-down 25°
12 o'clock (upper direction)
55% (typical center to NTSC)
Maximum 40ms white to black
Typical 70cd/m
6-bit digital signals for each of RGB primary colors
Synchronous signals (Hsync, Vs ync)
Dot clock (CLK)
3.3V or 5.0V (logic, LCD driving)
Edge light type
one fluorescent lamp (cold cathode type) inverter-less
84
Specification
2
