System Status LCD Bar

The Notebook Computer features a LCD panel bar to display the system's operation status.
AC Power in Use
Battery Low
CD-ROM in Use
FDD in Use
HDD in Use
Suspend to Memory
Turbo Speed
Scroll Lock
Caps Lock
The system is using AC power for
(Flash) The battery power is reaching a critically
low level.
This indicator displays that the CD-ROM
drive is being accessed.
This indicator displays that the floppy
disk drive is being accessed.
This indicator displays that the hard disk
drive is being accessed.
This indicator displays that the system
has entered the Suspend to DRAM Mode.
This indicator displays that the system is
running in the maximum speed of the
CPU.
This indicator displays that the scroll lock
function is activated.
This indicator displays that the caps lock
function is activated.
4
operation.
