Hosiden HLD1201-0151XX 12.1" TFT

Item
Display mode
Viewing direction
Backlight
Display format
Screen area
Color arrangement
Driving method
Interface
Display outline
Weight
Contrast ratio
Response time
Contrast setting
Brightness (white image)
Surface reflectance
Power supply
Specification
Normally white mode with positive image (black image,
white background)
Optimum viewing lobe direction is 6 o'clock
CCFL edge-light system
800x600 dots
251mmx189.5mm
RGB vertical stripes
6 b its parallel (64 gray levels=262,144 colors)
3∼3.3V CMOS logic
278.5mm(w) x 200.5mm(h) x 8.5mm (t) max.
600 grams
70:1 minimum at 25°C θ=0°, φ=0°, backlight on
Tr:28 msec typical, Tf:28 msec typical
Maximum setting
2
70 cd/m Typ / If=TBD mA
5% max.
Minimum 4.75V
Typical 5V
Maximum 5.25V
85
