Page 1 Xerox DocuColor 4 Administrator Guide 701P31413 August 1999 OCUMENT OMPANY XEROX...
Page 2 , the stylized X, and all ® Xerox product names and product numbers mentioned in this publication are trademarks of XEROX CORPORATION. Other company trademarks are also acknowledged. Changes are periodically made to this document. Technical up- dates will be included in subsequent editions.
Page 3: Table Of Contents
Table of Contents Table of Contents ....................i Preface ......................v Certifications ....................9 Types of Manuals ..................xi Network Administration Features ..............xiii Before You Begin..................xiv Printer/Copier Control Panels..............xvii 1. Connecting to the Network The printer/copier on the network .............. 2 Stages of installation on the network ............
Page 4 Setting up a DocuColor 4 LP/CP print queue for bindery ... 82 Setting up NetWare Windows clients for printing........86 Setting up DocuColor 4 LP/CP on a TCP/IP network with Windows NT 4.0 87 Tips for experts-Windows NT 4.0 with TCP/IP ........88 Configuring a Windows NT 4.0 server for the DocuColor 4 LP/CP ..
Page 5 Configuring Windows NT 4.0 clients ............94 Using AppleTalk with Windows NT 4.0 ........... 95 4.10 Token Ring Support for DocuColor 4 LP/CP ........... 96 5. About copy Configuration Displaying the Tools Screen..............98 5.1.1 Displaying the Tools screen ............99 5.1.2...
Page 6: Preface
DocuColor 4 LP/CP and client workstations are set up, as described in the User Guide and the Setup Guide, individual users can print to the DocuColor 4 LP/CP as a high- performance color PostScript printer. Additionally, the DocuColor 4 CP can be used as a copier.
Page 7: Certifications
Certifications Certifications . . . in Europe The CE marking that is applied to this product symbolizes Xerox Europe Declaration of Conformity with the following applicable Directives of the European Union as of the dates indicated: January 1, 1995: - Council Directive 73/23/EEC amended by Council Direc- tive 93/68/EEC, approximation of the laws of the member states related to low voltage equipment.
Page 8: Energy Star
Changes or modifications to this equipment, not specifically approved by the Xerox Cor- poration may void the user's authority to operate this equipment.
Page 9: Electrical Safety
If you notice unusual noises or odors, switch off the printer/copier power immediately. Disconnect the power cable from the electrical outlet. Call an authorized Xerox service representative to correct the problem.
Page 10: Laser Safety
• Do not perform any maintenance procedures unless you have been trained to do them by a Xerox representative or a procedure is specifically de- scribed in one of the printer/copier manuals.
Page 11: Operational Safety
Operational Safety Your Xerox printer/copier and supplies were designed and tested to meet strict safety requirements. These include safety agency examination, approval, and compliance with established environmental standards. Your attention to the following safety guidelines will help ensure the continued safe operation of your printer/copier.
Page 12: Ozone Safety
This product will produce ozone during normal operation. The ozone produced is heavier than air and is dependent on copy volume. Providing the correct environmental parameters as specified in the Xerox installation procedures will ensure that the concentration levels meet safe limits.
Page 13: Types Of Manuals
Types of Manuals This manual is part of the set of DocuColor 4 LP/CP documentation that includes the following manuals for users and system administrators: Setup Guide This guide contains procedures from unpacking the printer/copier, confirm- ing simple operations, troubleshooting and routine care of the printer/copier.
Page 14: About This Manual
About this Manual This manual includes guidelines on the following topics: • Basic configuration of the DocuColor 4 LP/CP to support printing over AppleTalk, TCP/IP, and IPX (Novell) networks • Setting up a parallel port connection • Configuring Novell and Windows NT servers to provide DocuColor 4 LP/CP printing services •...
Page 15: Network Administration Features
4.x servers in bindery emulation mode) can be connected to the DocuColor 4 LP/CP. • Fiery WebTools (Status, WebSpooler, WebDownloader, WebLink, and WebSetup) Fiery WebTools allow you to manage the DocuColor 4 LP/CP from the Internet or from your company’s intranet.
Page 16: Before You Begin
WebSpooler or printer/copier setup with WebSetup. Levels of access and control The DocuColor 4 LP/CP can be password protected, providing a level of con- trol for printer/copier administrators. The password determines whether a user can modify Setup options, and whether a user has control over print jobs in the WebSpooler queues, or copiy jobs from the scanner.
Page 17 WebSpooler, but they cannot be selected for reprinting, moving, or deletion, providing a measure of security for sensitive files. If you plan to download fonts to the DocuColor 4 LP/CP via the network, you must download them to the Direct connection.
Page 18: Fiery Webtools
Fiery WebTools, software that allows you to remotely manage your printer/ copier and print jobs via the Internet or your company’s intranet, come pre- installed on the DocuColor 4 LP/CP. Fiery WebTools are supported on Mac OS, Windows 95/98, and Windows NT 4.0 computers. To enable use of Fiery WebTools, you must do the following in Setup: •...
Page 19 Wordless Printer Control Panel This section describes the wordless control panel. Worded Printer Control Panel The printer worded control panel described throughout the documentation is displayed here. Activity Lights The activity lights indicate the status of the printer/copier. They are de- scribed in the table below.
Page 20: The Lcd Window On The Control Panel Displays Status Messages
Printer Display Window The LCD window on the control panel displays status messages. Printer Buttons The buttons and their functions are described here. W o r d l e s s W o r d e d I n d i c a t e s : C o n t r o l C o n t r o l P a n e l...
Page 21 Copier control panel Name Description Use the buttons to select a zoom ratio from the list, or use (1) [Reduce/Enlarge] buttons [Auto] for automatic selection. The selected zoom ratio indicator lights. Use the buttons to adjust the zoom ratio between 50% and (2) [Zoom] buttons 200% with 1% increments.
Page 22 Name Description Use this button to set (confirm) selection of a function. (10) [Select] button Use this button to cancel the selected function. Also, inthe Tools (11) [Exit] button screen where there are multiple levels of selections, pressing this button moves one level up the hierarchy. (12) [Copy] button Use this button to switch to the copy mode.
Page 23: Connecting To The Network
Connecting to the Network This chapter summarizes the stages in setting up a Xerox DocuColor 4 LP/ CP and includes diagrams that refer you to other chapters or other manuals for completing your installation.
Page 24: The Printer/Copier On The Network
DocuColor 4 LP/CP parallel port. When you add a DocuColor 4 LP/CP to a network, it is assumed that a net- work administrator will have already installed a network cabling system and connected workstations and servers.
Page 25: Stages Of Installation On The Network
• Physically connecting the DocuColor 4 LP/CP to a functioning network Prepare a network node for the DocuColor 4 LP/CP- network cable and route it to the location where the DocuColor 4 LP/CP will be installed, and attach the cable to the network interface of the DocuColor 4 LP/CP.
Page 26 For computers that will use the WebTools, in- MacOS Windows stall an Internet browser. Verify the DocuColor 4 LP/CP in the list of print- ers and run a test print. DocuColor 4 LP/CP available on the network...
Page 27: Quick Path To Installation
Note that multiple protocols (shown in the diagrams as parallel lines) can run on the same cable. A solid connection from the DocuColor 4 LP/CP with an arrow indicates that other supported network types can be operational at the same time.
Page 28 1.3 Quick path to installation Mac OS environment with AppleTalk Key to setup: 1 Mac OS computer User Guide 2 DocuColor 4 LP/CP Setup Chapter 2 Another supported protocol DocuColor 4 LP/CP AppleTalk MacOS computer MacOS computer MacOS computer AppleTalk...
Page 29 1.3 Quick path to installation Windows computers in a Novell environment Key to setup: 1 NetWare server Chapter 4 Another 2 DocuColor 4 LP/CP Setup Chapter 2 supported 3 NetWare client Chapter 4 protocol 4 Windows computer User Guide DocuColor 4 LP/CP...
Page 30 1.3 Quick path to installation Windows NT Server environment Key to setup: 1 Windows NT server Chapter 4 Another 2 DocuColor 4 LP/CP Setup Chapter 2 supported 3 Windows NT client Chapter 4 protocol Windows NT DocuColor 4 LP/CP Workstation...
Page 31 1.3 Quick path to installation Windows computers using Windows (SMB) printing Key to setup: 1 Windows computer User Guide 2 DocuColor 4 LP/CP Setup Chapter 2 Another supported protocol DocuColor 4 LP/CP Widows computer Widows computer Widows computer TCP/IP protocol...
Page 32 DocuColor 4 LP/CP itself. This chapter describes the physical network con- nections and summarizes DocuColor 4 LP/CP Setup and other administra- tive functions available from the control panel. Parallel cable is an options with DocuColor 4 CP. The Cable can be pur- chased from Xerox. Request Part # 98 4330.
Page 33: Before You Proceed
4 LP/CP and the workstations that will print to the it. A service technician will have performed some initial installation. Print a test page to make sure the DocuColor 4 LP/CP printer/copier is functioning normally. “Printing information pages” on page 41.
Page 34: Ethernet Cable Connection
DocuColor 4 LP/CP. Unshielded Twisted Pair is also used for Token Ring. The 100BaseT type supported by the DocuColor 4 LP/CP is 100BaseTX, also known as Fast Ethernet. If an Ethernet hub is used, it must be a 100BaseTX hub. The term “100BaseT” is used in this manual to refer to 100BaseTX.
Page 35 Firewire between scanner and printer Shut down the printer/copier before attaching the DocuColor 4 LP to any network device. Do not attach cables to more than one Ethernet connector; only one Ethernet connection can be made at any one time.
Page 36: Token Ring Connection
To use thicknet cable: With the DocuColor 4 LP/CP turned off, connect the thicknet cable connector to the AUI connector on the back of the DocuColor 4 LP/CP. Press on the latch to lock the connector. Configure network servers for printing and then proceed to “Setting up the Print Functions”.
Page 37: Parallel Cable Connection
(see “Parallel Port Setup"). For information on setting up printing to the parallel port, see the User Guide. Parallel cable is an optional item for DocuColor 4 CP. It is a mini Centronics cable available from Xerox as part number 98S4330.
Page 39: Performing Setup From The Printer Control Panel
Performing Setup from the Printer Control Panel The control panel on the top of the printer enables you to set options and view the status of the printer and print jobs. This chapter provides information about: • Using the printer control panel •...
Page 40: Initial Setup
Initial Setup Initial printer setup for network printing must be performed at the printer control panel. When network communication settings have been established, additional Setup options can also be specified from a client computer using WebSetup. WebSetup provides remote access to the printer’s setup menu options ...
Page 41: Using The Printer Control Panel
Using the printer control panel This section describes the functions of the printer control panel, illustrated below: 2.2.1 Activity lights The activity lights indicate the status of the printer/copier. This light: Indicates: Online LED  On when the printer/copier is online Online (ready to accept and process new jobs), and off when the printer/copier is offline or the power is off.
Page 42: Display Window
2.2 Using the printer control panel 2.2.2 Display window The LCD window on the control panel displays status messages. For more information on the display window, see Chapter 2 of the User Guide.
Page 43: Buttons
2.2 Using the printer control panel 2.2.3 Buttons This button: Indicates: Down arrow  In a fixed-length list, takes you to the next item in the list.When entering numbers or text, decrements to the next number or character. Hold down the button to decrement rapidly. Up arrow ...
Page 44: Setting Up The Print Functions
Setting up the Print Functions This section describes how to set up the printer/copier using the printer con- trol panel. After you set up the printer/copier the first time, you may later need to change setup information. For example, your network may change, or you may decide not to print a start page when you turn on the printer/ copier.
Page 45: Main Printer Setup Menus
2.3 Setting up the printer/copier At this screen: Press Item/Enter: • With CLEAR LOG/QUEUES displayed, RESETS clears the Job Log and all print queues. • With FORMAT DISK displayed, formats the hard disk. • With RESET COLOR displayed, resets printer’s color calibration to factory settings. •...
Page 46: System Setup
2.3 Setting up the printer/copier Choose: To specify: See: PRINTER SETUP Printer settings page 26 PS SETUP page 27 PostScript settings for the printer/ copier. PCL settings for the printer/copier PCL SETUP page 28 Settings for the network and/or par- I/O PORT SETUP page 30 allel connections to the printer/...
Page 47 30 MIN/60 MIN/120 MIN/180 MIN[30 MIN] Use this option to select the length of time during which there is no printer/ copier activity before the DocuColor 4 LP/CP/CP/CP switches to Power Saver mode. Full power mode is automatically restored when the printer/copier receives a network print job or any button on the printer or printer or copier control panel is pressed.
Page 48: Printer Setup
2.3 Setting up the printer/copier VERIFY PASSWORD To verify a new or existing password, you must enter the password again. If you make a mistake, you will be prompted to enter the password again. Note that the scanner has its own Administrator password independent of the printer.
Page 49: Postscript Setup
2.3 Setting up the printer/copier 2.3.5 PostScript Setup The PostScript setup menus enable you to set PostScript printing options. PS SETUP To proceed, press Item/Enter. PRINT TO PS ERR YES/NO [NO] Use this option to specify whether to print the portion of a print job pro- cessed before a PostScript error is encountered.
Page 50: Pcl Setup
2.3 Setting up the printer/copier 2.3.6 PCL Setup The PCL Setup menus enable you to set PCL printing options on PCL jobs sent to the printer without formatting instructions. PCL is available only when printing from Windows computers. PCL SETUP To proceed, press Item/Enter.
Page 51 2.3 Setting up the printer/copier The next setting and the remaining settings in this section apply to ASCII text files on a per job basis. FONT NUMBER 0-45 [0] Use this option to specify which PCL font to print. For a complete list of available PCL fonts and their corresponding font numbers see Appendix B of the User Guide.
Page 52: Specifying Network Information
Specifying network information 2.4.1 I/O Port Setup The I/O Port Setup menus allow you to specify and set up the printer port type, including Ethernet or parallel port. I/O PORT SETUP To advance to the next screen, press Item/Enter. 2.4.2 Ethernet ETHERNET OFF/ON [ON]...
Page 53 IGNORE EOF YES/NO [YES] If PARALLEL PORT is set to ON, use this option to specify that the printer/ copier should ignore end-of-file (EOF) messages in a file. To print PostScript files in binary format (not ASCII), this option must be set to YES. When this option is set to YES, the printer uses the value you entered for the parallel port timeout to determine when it has reached the end of the file.
Page 54: Specifying Network Protocol Options
Ethernet, AppleTalk, and IPX (Novell) network protocols. NETWORK PROTOCOL SETUP Press Item/Enter to proceed. TCP/IP Ethernet (DocuColor 4 CP only function) Enable Auto IP - Yes/No - AUTOIP is the module that handles automatic TCP/IP configuration for the system Enable DHCP - Yes/No...
Page 55 2.5 Specifying network protocol options DHCP DHCP, or dynamic host configuration protocol (specified in RFC 2131), is an extension to BOOTP that allows dynamic allocation of IP addresses . Unlike BOOTP or RARP where cleints get the IP address once and for all, DHCP assigns "leases"...
Page 56 IPX protocols; Novell has created and trademarked this network operating system. For more information on setting up Novell printing see “Setting up the DocuColor 4 LP/CP on an IPX network". Novell Frame Types The next screens enable you to select the Ethernet frame type used for com- munication between your NetWare file server (or NetWare file servers if you connect to more than one) and the printer.
Page 57: Network Services Setup
Pserver allows you to enter the names of the Novell objects that are concerned with printing to the DocuColor 4 LP/ Pserver is a program on the printer that services all the Novell print queues that are assigned to this printer.
Page 58 2.6 Network Services Setup NEW TREE DELETES BINDERY SETUP This alert message warns you that your previous Bindery settings if any will be deleted. DEL BIND SETUP? YES/NO [NO] Select YES if you wish to delete Bindery settings. LOGIN TO BROWSE? YES/NO [NO] Select YES if a login is required to browse the NDS tree.
Page 59 2.6 Network Services Setup BROWSE TREE TO PRINT SERVER To begin navigating to the Print Server, press Item/Enter. [NDS TREE NAME] The NDS tree name appears in the top line of the LCD display. The first item at a level below the tree name appears in the second line. Use the arrow but- tons to browse the NDS objects listed in the display.
Page 60: Bindery Setup
2.6 Network Services Setup BROWSE TO PRINT Q SUBTREE ROOT This message is displayed if you selected SUBTREE in the previous screen. To advance to the NDS browse screens, and browse to the print queue root, press Item/Enter. Navigate the NDS objects as before. Press Item/Enter to display objects be- low the level of the selected object in the previous screen’s second line.
Page 61 2.6 Network Services Setup BINDERY SETTINGS VIEW/CHANGE/SKIP/REMOVE FSERVER [VIEW] Use the up and down arrow buttons to scroll through menu options. Select VIEW to display a list of Novell file servers already connected to the printer. Select CHANGE to display a list of all available servers in order to add one or change the print server setting.
Page 62: Smb Setup
2.6 Network Services Setup PRINT SERVER [LIST] Use the up and down arrow buttons to scroll through the list of print servers defined for the selected file server. After selecting a print server, press Item/ Enter. If a password is required to log in, the PSERVER PASSWORD screen is displayed.
Page 63 Details section of the Server information window. DOMAIN NAME Enter the workgroup or domain you want the DocuColor 4 LP/CP to appear in. Lowercase letters are not allowed. Use the arrow buttons to enter the domain name or workgroup of the printer...
Page 64: Printing Information Pages
You can print an information page before you set up the DocuColor 4 LP/CP or at other times from the READY or the POWER SAVE ON screen.
Page 65 To print an information page: Turn on the machine and allow it to warm up. Messages appear on the control panel as the DocuColor 4 LP/CP runs through its power-up tests. From the READY screen, press the Menu button on the printer control panel until the message PRINT PAGES is displayed.
Page 66: If You Have Difficulty Printing
Either the printer driver Check the settings on a copy job is sent from is not installed, or the the host computer. For a DocuColor 4 CP. computer has not been more information, see correctly set up. the Setup Guide.
Page 67: Performing Setup From Websetup
Performing Setup from WebSetup Fiery WebSetup provides remote access to the printer’s Setup menu options. You can use Fiery WebSetup to remotely view and modify the current con- figuration of your printer/copier. Almost all of the options in System Setup, Network Setup, and Printer Setup can be set using WebSetup.
Page 68: Setup From Websetup
To access Fiery WebSetup: Start your Internet browser application. Enter the IP address or the DNS name of the DocuColor 4 LP/CP in the URL line of your browser. Get the IP address or DNS name of the printer/copier from your network administrator.
Page 69 3.1 Setup from WebSetup Click WebSetup. If a password has been set, you are prompted to enter it before you can access WebSetup. The options that you can specify from Fiery WebSetup are grouped into three categories: System Setup, Network Setup, and Printer Setup. These are described in the following sections.
Page 70: System Setup
3.1 Setup from WebSetup 3.1.1 System Setup In System Setup, you specify settings from two tabs: the System Setup tab and the Password tab. To set System Setup options: • Click the System Setup button. System Setup tab The options that you can set from the System Setup tab are described below.
Page 71 3.1 Setup from WebSetup Enable Printed Queue  Using a DocuColor 4 CP or, if your DocuColor 4LP has a hard disk drive installed, select this option to create a storage location on the hard disk for the most recent print jobs. Users with Administrator privileges can use the WebSpooler to reprint jobs in the printed queue without sending those jobs again.
Page 72 3.1 Setup from WebSetup To set or change the Administrator password: • Click the Password tab. Enter New Password  To set a new password, enter a password in the Enter New Password text field.
Page 73: Network Setup
You can also enter or change the Administrator password in the System Setup menus on the printer’s control panel. By default no password is set on the DocuColor 4 LP/CP. It is recommended that a password be set to protect the printer/copier from accidental or incorrect changes to printer/copier Setup settings.
Page 74 Port Setup tab The options that you can set from the Port Setup tab are described below. Enable Ethernet  Enable this option if the DocuColor 4 LP/CP is to be connected to an Ethernet network. Transmission Speed  Select Auto Detect if your network environment is mixed, or select the speed (10 Mbps or 100 Mbps) of the network to which the DocuColor 4 LP/CP is attached.
Page 75 Ethernet. IP Address  Enter the DocuColor 4 LP/CP IP address for Ethernet. The DocuColor 4 LP/CP is shipped with the IP address set to the loopback address (127.000.000.001), which is an internal address used for network checking. If you plan to print with TCP/IP, you must first assign the DocuColor 4 LP/CP a unique network IP address.
Page 76 Gateway  If your TCP/IP network has a gateway, and users outside the gateway plan to print to the DocuColor 4 LP/CP using TCP/IP, enter the gateway address here. By default, the loopback address, 127.000.000.001, is set. Obtain the correct gateway address from your network administrator.
Page 77 If your network uses both NDS and Bindery, set up NDS first. Setting up NDS after Bindery will overwrite Bindery Setup. If your network uses both NDS and Bindery, including using NetWare 4.x servers in bindery emulation, the DocuColor 4 LP/CP cannot service NDS and bindery emulation servers on the same NDS tree.
Page 78 This option is located in the Protocol Setup tab. PServer Setup (NDS Configuration) In initial setup, the DocuColor 4 LP/CP was connected to the network and an NDS directory tree, with a Printer, a Print Server, and one or more Print Queue objects.
Page 79 3.1 Setup from WebSetup Your new NDS tree selection automatically overwrites any previous tree selection. If you change the NDS tree selection and there are also current Bindery settings, you are alerted that they will be deleted. If you continue with NDS Setup, you can replace Bindery settings afterwards.
Page 80 Use Bindery Setup if you have already configured one or more bindery servers (file servers running NetWare 3.x or NetWare 4.x in bindery emulation) with a Print Server and a Print Queue for DocuColor 4 LP/CP jobs. Before entering bindery settings, be sure the DocuColor 4 LP/CP is connected to the network and the NetWare file server is running.
Page 81 3.1 Setup from WebSetup Click OK. The Add Server window shows a list of print servers you can add. • Add Server Select a print server from the list on the left. Enter a password if a password is required. Click Finish.
Page 82 Enable Windows Printing Service  Enable this option to enable SMB (Server Message Block), the file and printer sharing protocol built into Windows. Enabling SMB allows the DocuColor 4 LP/CP to be listed on the network so that Windows clients can print to a particular print connection without any other networking software.
Page 83 3.1 Setup from WebSetup Printer Setup tab The Printer setup tab is used to specify the printer’s default page description language (PDL), paper size, and the ability to print under low Dry Ink condition. Page Desc. Language  Specify a default page description language for your printer.
Page 84 PS Setup tab The PS Setup tab is used to specify PostScript printing options. Print to PS Error  Specify whether the DocuColor 4 LP/CP should print the available portion of a print job when it encounters a PostScript error. Select Yes to print the portion of the job that was processed before the error occurred;...
Page 85 3.1 Setup from WebSetup PCL Setup tab The options that you can set from the PCL Setup tab are described below. The PCL Setup options in this section apply to unformatted ASCII text files. PCL is available only when printing from Windows computers. Form Length (Lines) ...
Page 86: Restarting The Printer/Copier
3.1 Setup from WebSetup Pitch (char/inch)  Specify the pitch, or number of fixed-space, PCL characters per horizontal inch to print. Font Size  Specify the point size of the font to print. Default Orientation  Specify the default orientation of the print job on the paper.
Page 87: Setting Up Network Servers
Windows NT 4.0 workstations, where a network server is op- tional. The chapter also outlines the requirements for network clients to print to the DocuColor 4 LP/CP and to run the Fiery WebTools. If your network is based on Windows NT 4.0, skip to page 89.
Page 88: Setting Up The Docucolor 4 Lp/Cp On An Ipx Network
Ethernet network topologies. During DocuColor 4 LP/CP setup, you se- lect the frame type that will be used for communication between the DocuColor 4 LP/CP and network servers. Frame type refers to the format of a communications packet; frame types are specified in a startup file when the...
Page 89: Tips For Experts-Ipx Networks
• The DocuColor 4 LP/CP looks for print jobs on one NetWare print server per bindery server. • Each print server can store jobs for any queue on the DocuColor 4 LP/CP. 4.2.1 Overview of IPX printing to the DocuColor 4 LP/CP NetWare file servers support the creation of print queues, which are storage areas for print jobs.
Page 90 When the DocuColor 4 LP/CP is configured to connect to a NetWare server, it polls the NetWare server for jobs in each of its queues. If jobs are found, they are transferred over the network to the matching connection: Print to Print, Hold to Hold, Direct to Direct.
Page 91: Configuring A Netware Server For Printing
75). • For NetWare 3.x and for NetWare 4.x in bindery emulation, set up a file server, a print server, and a print queue for the DocuColor 4 LP/CP (see page 82). With bindery services, you can route all DocuColor 4 LP/CP print jobs through the same NetWare file server, or you can configure more than one file server to handle DocuColor 4 LP/CP jobs.
Page 92 4.3 Configuring a NetWare server for printing On NDS FS: On DocuColor 4 LP/CP On client workstation: printer control panel: I/O PORT SETUP In NETADMIN: Install user software Ethernet Setup For printing: Create NDS PQs NETWORK PROTOCOL SETUP Create NDS printer/...
Page 93: Setting Up An Nds Connection
Objects have a name, properties, and a context which defines the location of the object in the directory tree. For the DocuColor 4 LP/CP you are mainly concerned with defining a printer, a print server object and one or more print queue objects.
Page 94 4.3 Configuring a NetWare server for printing To create an NDS print queue: Browse to the NDS container where the print queue will be located. Select a container object. This is the NDS container you will select later in Network Setup>Pserver>...
Page 95 If your printer does not have a hard disk drive, you can define a Direct connection only. If your printer/copier has a hard disk drive installed (All DocuColor 4 CPs have hard disks), repeat this step to create two additional queues (Print and Hold), to print to.
Page 96 4.3 Configuring a NetWare server for printing To create an NDS printer/copier and assign a queue to the printer/ copier: Choose the NDS container that contains the print queue. Choose Create from the Object menu. In the New Object dialog box that appears, choose Printer and click Enter a name for the printer/copier, check the Define additional properties check box and click Create.
Page 97 4.3 Configuring a NetWare server for printing This is the NDS print server name you will select later in Network Setup> PServer>NDS setup. Choose assignments and click Add. In the next step you will assign a print connection and/or print queues to the printer object you have created.
Page 98 4.3 Configuring a NetWare server for printing If you have defined additional queues for this printer, select the print queue name from the Print queues list, and click Add. Repeat this step for each connection. When you have finished, click OK. To create an NDS Print server: Choose the NDS container that contains the printer and print queue objects.
Page 99 4.3 Configuring a NetWare server for printing Select Print Server and click OK. Enter a name for the print server, check the Define additional properties check box and click Create. Click assignments and click Add.
Page 100 Users list, and click Add. Repeat this step for each user. When you have finished adding users, click OK. The remaining Setup can be performed on the DocuColor 4 LP/CP, or can be performed using the WebSetup WebTool.
Page 101: Setting The Netware 4.X Bindery Context
4.3.3 Setting the NetWare 4.x bindery context You can connect only one directory tree to the DocuColor 4 LP/CP. If you need to connect additional NetWare 4.x servers, you can do so by using bind- ery emulation, which causes the 4.x server to behave like and be accepted as a NetWare 3.x server.
Page 102 Up to eight bindery servers, whether in native 3.x mode or in 4.x emulation, can connect to the DocuColor 4 LP/CP. If your server is using NetWare 3.x, proceed to “Setting up a DocuColor 4 LP/CP print queue for bindery” on page 82.
Page 103 4.3 Configuring a NetWare server for printing Select NCF Files Options. From the menu of available NCF files, choose Edit AUTOEXEC.NCF file. Type a new line anywhere in the file as follows: set Bindery Context = enter your bindery context here Press Esc to close the window, and save changes.
Page 104: Setting Up A Docucolor 4 Lp/Cp Print Queue For Bindery
If you can reboot the NetWare server, the set command is loaded automatically. You are ready to set up the DocuColor 4 LP/CP print server and print queue. See the next section for details. 4.3.4 Setting up a DocuColor 4 LP/CP print queue for bindery For NetWare 3.x and for 4.x in emulation, the NetWare print server and print...
Page 105 Using the arrow keys, select the name of the file server you’ll use for sharing DocuColor 4 LP/CP printing and press Enter. This is the file server you select later in DocuColor 4 LP/CP Network > PServer > Bindery Setup.
Page 106 4.3 Configuring a NetWare server for printing Press Insert and type a name for a new DocuColor 4 LP/CP print queue. Press Enter. Page 93 for queue naming conventions. Make sure the print queue name you created is selected in the list of Print Queues, and press Enter.
Page 107 You have associated the selected DocuColor 4 LP/CP queue with the print server you created in step 6. The DocuColor 4 LP/CP obtains jobs from all queues defined for a print server, and all jobs from one file server go to the same queue on the DocuColor 4 LP/CP.
Page 108: Setting Up Netware Windows Clients For Printing
These operations can also be performed using Novell Client for Windows 95/98, and Windows NT. • Setting up the DocuColor 4 LP/CP as a PostScript or PCL printer by in- stalling a PostScript or PCL printer driver and the DocuColor 4 LP/CP PPD or PDD (PostScript or PCL printer description file).
Page 109: Setting Up Docucolor 4 Lp/Cp On A Tcp/Ip Network With Windows
When a Windows NT 4.0 computer is configured to connect to the DocuColor 4 LP/CP using TCP/IP, it can print directly to the DocuColor 4 LP/CP. If the computer shares the printer over the network, it is acting as a print server to Windows NT 4.0 and Windows 95/98 clients.
Page 110: Tips For Experts-Windows Nt 4.0 With Tcp/Ip
When TCP/IP network connections are made from Windows NT 4.0 work- stations, note the following: • Make sure you have a valid IP address for the DocuColor 4 LP/CP and for any workstations that will print to it or run Fiery WebTools.
Page 111: Configuring A Windows Nt 4.0 Server For The Docucolor 4 Lp/Cp
• Load the Microsoft TCP/IP Printing service (see the next section). • Enter the host name of the DocuColor 4 LP/CP in the host database used by your system (see page 91). • On the DocuColor 4 LP/CP, perform Server Setup, Network Setup, Printer Setup, PS Setup, and PCL Setup.
Page 112: Adding The Docucolor 4 Lp/Cp To The Tcp/Ip Network
For installations that don’t have a network administrator or a central host name database, add the DocuColor 4 LP/CP to the hosts file on the Windows NT 4.0 server. Also add it to the hosts file on any workstations that have TCP/IP loaded and will use the Fiery WebTools.
Page 113 4.7 Configuring a Windows NT 4.0 server to support the DocuColor 4 LP/CP If there is no system-wide host name database, use the following procedure to create a local hosts file. If there is a system-wide host database, skip the following procedure.
Page 114: Installing The Docucolor 4 Lp/Cp As A Shared Postscript Printer/Copier
4.7 Configuring a Windows NT 4.0 server to support the DocuColor 4 LP/CP 4.7.2 Installing the DocuColor 4 LP/CP as a shared PostScript printer/copier The first step in creating a printer is installing the Windows NT PostScript printer driver and the DocuColor 4 LP/CP PostScript printer description file (PPD), which gives your applications access to some printer features.
Page 115: Setting Up An Another Printer/Copier
4.7 Configuring a Windows NT 4.0 server to support the DocuColor 4 LP/CP 4.7.3 Setting up another printer/copier If more than one DocuColor 4 LP/CP printing connection is published (for example, if both the Print queue and the Hold queue are published), you may wish to create a printer for each printing connection so that you and other users can print to each queue directly.
Page 116: Configuring Windows Nt 4.0 Clients
Windows NT 4.0 print server, and from there to the selected queue on the DocuColor 4 LP/CP. The job is listed in the Print Manager on the client work- station, and the administrator can track it in the DocuColor 4 LP/CP window...
Page 117: Using Appletalk With Windows Nt 4.0
If your network uses AppleTalk only, you do not need to install the TCP/IP. This protocol is not required to print documents over an AppleTalk network. Mac OS users can print directly to the DocuColor 4 LP/CP and should install the AdobePS printer driver and the DocuColor 4 LP/CP PPD. These installa- tions are described in the User Guide.
Page 118: Token Ring Support For Docucolor 4 Lp/Cp
Token Ring Support with DocuColor 4 LP/CP Token Ring Support with DocuColor 4 LP/CP The DocuColor 4 LP/CP supports Token Ring networks with the optional token ring adapter card; Token Ring PCI PCBA Part# 45000052 Token Ring supports: AppleTalk, TCP/IP, and IPX networks simultaneously.
Page 119 About the Copier Configuration This chapter contains information about configuring your copier. 5.1 Displaying or closing the Tools screen 5.2 Configuration settings list 5.3 Changing the configuration 5.4 Setting up, changing, or removing the user’s pass code 5.5 Changing the pass code of the system administrator 5.6 Adjusting the color balance...
Page 120: Displaying The Tools Screen
Displaying the Tools screen 5.1 Displaying or closing the Tools screen The Tools screen lets you change the default values of the various settings and enable/disable some functions. In order to access this screen, the pass code of the system administrator is required. The pass code of the system administrator is set to “9999”...
Page 121: 5.1 Displaying The Tools Screen
5.1 Displaying the Tools screen 5.1.1 Displaying the Tools screen The following is the procedure for displaying the Tools screen. Operation procedure Press the [Tools] button. The pass code input screen appears on the display. 2) Enter the pass code of the system administrator, using the numeric buttons.
Page 122: 5.1.2 Closing The Tools Screen
5.1 Displaying the Tools screen 5.1.2 Closing the Tools screen The following is the procedure for closing the Tools screen. Operation procedure (1) Press the [Tools] button. The display returns to the state before the Tools screen.
Page 123: 5.2 Configuration Settings List
Configuration Settings List 5.2 Configuration settings list From the Tools screen, you can set the default value of each setting. The settings will take on their default values when the power is turned on and the machine enters the copy mode, when the save energy mode is returned, or when the [Reset] button is pressed.
Page 124 5.2 Configuration Settings List Setting Description Possible value mm, inch 5. Doc. Size Sensing Use this setting to specify the default unit of measurement for use in automatic detection of document size. This setitng affects the document size that can be detected automatically. For detailed information, see the "4.1 About documents"...
Page 125 5.2 Configuration Settings List Setting Description Possible value 1 to 99 copies (99 Use this setting to specify the maximum number of copies allowed 13. Max. Counts sheets) in one copy operation. Top (Face Down 14. Output Tray Use this setting to specify the delivery tray to use. Note, however, Tray) that even if [Top (face Down Tray)] is selected, transparency sheets, Left (Face Up Tray)
Page 126: Changing The Configuration
Changing the Configuration This section explains the basic method for changing the configuration set- tings. However, the following settings use different methods and are described in the subsequent sections. *User’s pass code..See the “5.4 Setting up, changing, or removing the user’s pass code”...
Page 127: Basic Method For Changing The Configuration
5.3 Changing the Configuration (4) At the displayed screen, use the down arrow or button (or for numbers use the numeric buttons) to select a default value for the setting. To cancel this setting and return to the initial Tools screen, press the [Exit] button.
Page 128: Setting Up, Changing Or Removing The User's Pass Code
Setting up, changing or removing the user's pass code By setting a user’s pass code, you can restrict user access to the machine. This section explains how to set up, change, or remove a user’s pass code. Operation procedure (1) Display the Tools screen. For detailed information on how to display or close the Tools screen, see the “5.1 Displaying or closing the Tools screen”...
Page 129 5.4 Setting up, changing or removing the user's pass code (4) At the displayed screen, press the down arrow or button to select [ON]. You can now enter a pass code using the numeric buttons. Use the numeric keypad to enter the user PIN. To remove the pass code registered, select OFF.
Page 130: Changing The Pass Code Of The System Administrator
Changing the pass code of the system administrator This section explains how to change the pass code of the system administra- tor. You cannot check the pass code after it has been changed. Therefore, make sure you do not forget the pass code. The administrator password is factory set to 9999.
Page 131 5.5 Changing the pass code of the system administrator (5) At [Confirm] enter the pass code again to verify. You cannot check the pass code after it has been changed. Therefore, make sure you do not forget the pass code. If the pass code entered at [Confirmation] is identical to the one entered earlier, the pass code change is confirmed and the initial Tools screen re- turns.
Page 132: Adjusting The Color Balance
Adjusting the Color Balance This section explains how to adjust the color balance by changing the mix of yellow, magenta, cyan, and black. For the [Low Density]/[Med Density]/[High Density] settings, they can be adjusted in seven increments. The following is the procedure.
Page 133 5.6 Adjusting the Color Balance (6) Press the button to select a color. (In this example [Magenta] is selected.) (7) Press the [Select] button. (8) Press the button to select a density. (In this example [HighDensity] is selected.) (9) Press the [Select] button. The color of the selected density appears as a vertical bar.
Page 134 5.6 Adjusting the Color Balance (11) Press the Select button. When the change is confirmed, the screen in step (8) returns. If you want to change the other densities, repeat steps (8) to (11). (12) When a color is set, press the Exit button. The previous level (the screen in step (6)) returns.
Page 135: Administering The Printer/Copier
Administering the printer/ copier This chapter gives tips on managing DocuColor 4 CP printing and copying, and includes some troubleshooting hints.
Page 136: Administrator Functions
Administrator functions Administration features are provided in the user software package and are built into the DocuColor 4 LP/CP itself. The following table tells you where to find information on these features. Page references may be found in this manual.
Page 137 See: Job accounting Viewing, printing, and exporting and delet- User Guide ing the Job Log. Calibration and color man- Calibrating the DocuColor 4 LP/CP. This manual, and the agement Printing color reference pages. User Guide Installing the monitor settings file.
Page 138: Maintaining Optimal Docucolor 4 Lp/Cp Performance
DocuColor 4 LP/CP performance. • Make sure you have adequate disk space on the DocuColor 4 LP/CP If your printer/copier has a hard disk drive, periodically review the list of jobs in the Hold queue, and the number of jobs being retained in the Printed queue.
Page 139: Troubleshooting The Printer/Copier
Troubleshooting the printer/copier Contact your authorized service/support center if you see any startup error messages on the DocuColor 4 LP/CP Control Panel, or if the DocuColor 4 LP/CP does not reach Ready status. 6.3.1 Troubleshooting during Setup from the Control Panel The following section explains some error and alert messages that you may see during DocuColor 4 LP/CP Setup that might not be self-explanatory.
Page 140 Warning Selecting a new Select NDS Tree You have previously connected the (Network Service Setup > NDS tree deletes Bindery DocuColor 4 LP/CP to a different NDS PServer Setup > NDS setup. tree. NetWise supports only a single Setup) NDS tree connection. To avoid a poten-...
Page 141 You must configure a print server and PServer Setup > Bindery a print queue for every NetWare file Setup) server that will handle DocuColor 4 LP/ CP print jobs (see page 78). Novell NetWare has reported an error. Any Bindery Setup screen...
Page 142 DocuColor 4 LP/CP queries the network for Novell file servers and trees, and attaches to them temporarily. If a guest login is enabled, it will be used. If not, you’ll be prompted to log in from the DocuColor 4 LP/CP printer Con- trol Panel.
Page 143 Indicates other network errors when Error # usually indicates a hard failure. Notify IPX the DocuColor 4 LP/CP is already Notify the Novell administrator and re- (Novell) connected to a file server. Something port the error number.
Page 144: When An Error Message Appears
6.3 Troubleshooting the printer/copier 6.3.2 When an error message appears When an error appears, the printer/copier will notify the user that an error has occurred using the display, error LED, and alarm. To solve the problem, refer to the Setup Guide “3.2 Error Messages” When the number of characters in an error message exceeds the number of characters on the display, the screen will change in 3 second intervals in order to display the entire message.
Page 145 Appendices...
Page 146: A Menu Help
Menu Help Graphic Printer Control Panel Overview This Appendix provides a graphic overview of the Xerox DocuColor 4 LP/CP printer control panel. The first figure illustrates the Menu Help page that can be printed from the control panel. For instructions on how to print this page, see Chapter 2.
Page 147: B Available Options
Guide “A.1 Introduction to Options”. Accessing the video controller board You must access the video controller board in the DocuColor 4 LP/CP in order to install or replace the hard disk or add or replace DIMMs. To access the video controller board: Turn the printer/copier OFF, unplug the power cord and disconnect any cables connected to the connectors on the back of the printer/copier.
Page 148 Carefully slide the side panel off the printer/copier. Be careful not to damage the clips on the panel that attach to the connector plate on the back of the DocuColor 4 LP/CP. The the video controller board is now accessible.
Page 149: Installing A Hard Disk Drive
Installing a hard disk drive The following section explains how to install the hard disk drive for the DocuColor 4 LP/CP video controller board. It also describes how to initial- ize the new hard disk drive for use from the printer’s front panel.
Page 150 B Available Options Caution notes • Do not drop or bend the hard disk drive. • Do not touch the hard disk drive connector. • Protect the hard disk drive from static electricity by keeping it in its anti- static package until you are ready to install it. •...
Page 151: Installing Additional Memory
Connect the ribbon cable to the connector J15 (3) on the video controller board. Reassemble the DocuColor 4 LP/CP as described on page 127. Initializing the hard disk After you install the hard disk and power on the printer/copier, you may be prompted to initialize the new hard disk.
Page 152 Additional RAM DIMMs may be purchased for your printer/copier in 32 or 64MB configurations, allowing your printer/copier a maximum memory con- figuration of 192MB. The DocuColor 4 CP slots are empty and any of them can be used to install additional memory...
Page 153 B Available Options To install A RAM DIMM: Open the DocuColor 4 LP/CP to access the video controller board as described on page 125. DIMM sockets Video controller board Unpack the RAM DIMM(s). Do not touch the connector edge on the RAM DIMM.
Page 154 B Available Options Slide the RAM DIMM into the empty socket and push the DIMM into the socket until the levers snap into place. Reassemble the DocuColor 4 LP/CP.
Page 155: Installing A Token Ring Card
Installing a Token Ring Network Card The following section explains how to install a Token Ring network card on the DocuColor 4 VP video controller board. To install the Token Ring board you will need to: • Access the video controller board.
Page 156 To Install the Token Ring board: Access the video controller board. Remove the two screws (1 and 2) that secure the slot cover (3) to the faceplate of the printer. Remove the plastic connector cover from connector J20.
Page 157 (2). The Token Ring board connector is keyed to fit only one way when properly oriented. Insert the screws (1 and 2) you removed from the slot cover to secure the Token Ring board (3) to the faceplate. Reassemble the DocuColor 4 CP as described on page 127.
Page 158: Token Ring Installation From Control Panel
Performing Setup for Token Ring from the Control Panel TOKEN RING ON/OFF [ON] Select ON to enable Token Ring network communication. Token Ring op- tions only appear if an optional Token Ring card is installed. TOKEN RING SPEED AUTO DETECT/4 M BPS/16 M BPS [AUTO DETECT] Select AUTO DETECT to automatically detect the speed at which data can be transferred over the Token Ring network, or optionally specify the speed of your Token Ring network.
Page 159: Index
Index Numerics 100BaseT connector ---------------------------------- 12 caution notes 10Base2 -------------------------------------------------- 12 installing hard disk drive ---------------------- 128 10Base5 -------------------------------------------------- 12 installing RAM DIMM -------------------------- 130 10BaseT-------------------------------------------------- 12 changing Administrator password ------------------------ xvi Copier Configuration settings ---------------- 104 Changing NDS file server settings ---------------- 35 access level scenarios ------------------------------- xiv Check and Print print option ------------------------- 22 administrator...
Page 160 Index Up arrow button ----------------------------------- 21 Ethernet SNAP ----------------------------------- 34 controller Ethernet frame type, option ------------------------- 34 10/100 Base T connector ---------------------- 12 Ethernet setup ------------------------------------------ 30 AUI connector for Thinnet or Thicknet Ethernet Ethernet Speed option -------------------------------- 30 ------------------------------------------------------- 12 Ethernet-IP Address option ------------------------- 33 back view showing connectors --------------- 12 Ethernet-Subnet Mask option ----------------------- 33...
Page 161 Index main printer setup menus ---------------------------- 23 maintaining server performance ------------------- 116 I/O Timeout option ------------------------------------- 30 maximum Frame Size option ---------------------- 133 Ignore EOF (End of File) option -------------------- 31 memory improving server performance --------------------- 116 installing additional ----------------------- 129-132 information pages (printing) ------------------------- 42 Menu Help page, printing a -------------------------- 42 installation, summary of tasks -------------------- 2-4...
Page 162 Index maximum number supported ------------------ xiii passwords setting up more than one ---------------------- 58 changing ------------------------------------------- xvi NetWare Print Console ------------------------------- 82 copier admin ------------------------------------- 108 NetWare Print Server, Bindery copier user ---------------------------------------- 106 creating in PCONSOLE ------------------------ 82 Print Server ---------------------------------------- 56 NetWare Queue ---------------------------------------- 82 PC compatibles network...
Page 163 Index Printer RAM DIMM --------------------------------------------- 129 control panel status messages and warnings RARP ----------------------------------------------------- 32 remote Printer Setup ------------------------------ 45-64 printer Removing NDS file server --------------------------- 38 enabling AppleTalk option --------------------- 54 reprinting jobs ------------------------------------------- xv specifying Resets option ------------------------------------------- 23 AppleTalk zone ------------------------------ 54 RJ-45 connector ---------------------------------------- 12 Novell option --------------------------------- 34...
Page 164 Index setting up printing from Windows NT --- 89-95 SMB printing with -------------------------------- 40 TCP/IP-Ethernet, option ------------------------------ 32 TCP/IP-Token Ring, option ------------------------- 133 Test Page, printing a ---------------------------------- 42 Test Pattern page, printing a ------------------------ 42 thicknet cable ------------------------------------------- 14 Token Ring Frame Type ---------------------------- 133 Token Ring setup ------------------------------------- 133 Token Ring Support ----------------------------------- 96...
Page 166 Prepared by: Xerox Corporation Global Knowledge and Language Services 800 Phillips Rd. - Bldg. 845-17S Webster, New York 14580-9791 701P31413...

Xerox DocuColor 4 Administrator's Manual

1 Connecting to the Network

2 Performing Setup from the Printer Control Panel

3 Performing Setup from Websetup

4 Setting up Network Servers

5 About Copy Configuration

6 Administering the Printer/Copier

Appendix A Menu Help

Quick Links

Related Manuals for Xerox DocuColor 4

Summary of Contents for Xerox DocuColor 4

Table of Contents
