3. Remove the Rewind Hub and the Outer Bearing from the Rewind Housing.
4. Remove the Rewind Hub Clutch from the Housing (and to remove the Spur Gear, remove the
Screw that secures the Idler Post to the Rewind Housing).
Replacement:
1. Reinstall the Outer Bearing in the Rewind Housing.
2. Position the Rewind Hub Clutch in the Rewind Housing.
3. Slide the Rewind Hub shaft through the Rewind Hub Clutch and Rewind Housing.
4. Reinstall the Inner Bearing and clip the E-Ring onto the Rewind Hub shaft (also, if removed,
position the Spur Gear onto the Idler Post and secure the post the Rewind Housing with the
Screw).
5. Reinstall the Rewind Assembly; see Section 4.6.

4.7 Media Sensor

Removal:
1. Turn OFF and unplug the printer.
2. Remove the Cover Assembly; see Section 4.1.
3. Disconnect the Media Sensor cable and, while holding the Media Idler, remove the Screw that
secures the Media Sensor Guide to the Post.
