Component Indicator Light
ID conflict indicator Amber
Fan canister Fan fault indicator
Power supply Power supply fault
canister indicator
Power supply power
indicator
a. Always use the storage management software (TPSSM) to precisely identify a failure.
b. If nothing is connected to the corresponding connector, this fault light is on. If a cable is connected and it is functioning properly, this light is
off.
c. This indicates a problem only if an SFP is plugged into the corresponding connector (see footnote a). Also, more than one bypass indicator
will be on if the connection fails. Usually, if an SFP fails, its bypass indicator will come on, as will the bypass indicator of the module to which
it is connected.
d. The overtemp indicator comes on if the internal drive enclosure temperature reaches 40
Condition" in this chapter for more information.
007-4644-001
Storage Enclosure Rear Indicator Lights (continued)
Table 3-2
Color Normal Operation
Off
Amber Off
Amber Off
Green On, steady
Problem
Indicator Condition Indicated
On, Enclosure number is set incorrectly;
steady enclosure number is in use by another
subsystem on the loop.
On, Fan canister failure; overtemp condition.
steady
On, Power supply failure; overtemp condition.
steady
Off Power supply off; power supply
disconnected; power supply is seated
incorrectly; no power to drive enclosure; no
power to storage array.
º º
C (104 F). See "Troubleshooting an Overtemp
Checking the Indicator Lights
a
