System Components
Figure 1-2 shows a rear view of both a controller enclosure and an expansion enclosure.
2882 RAID controllers
Fan Fan
Controller enclosure
Power supply
Power supply
Enviornmental status modules
Fan
Fan
Expansion enclosure
Power supply Power supply
Figure 1-2 TP9300 Controller and Expansion Enclosures (Rear View)
See Chapter 2, "Storage Enclosures" for more information about the controller and
expansion enclosures and their components.
