Air Flow; Figure A-8 Air Flow In The System Enclosure - Silicon Graphics Total Performance 9300 User Manual

Air Flow

007-4644-001
Figure A-8 shows the air flow in the system enclosure. Make sure your installation site
will allow adequate ventilation during operation.
Important: Allow a minimum of two feet of clearance in front of and behind the
controller enclosure for proper ventilation and servicing.
Front
Figure A-8 Air Flow in the System Enclosure
Enclosure Specifications
Rear
