In each setup, the camera and its heat conductor are exposed to the environment temperature of 22.5
until all match (1). As soon as the camera is powered (2) it starts to heat immediately (3) and reaches
its maximum after around one hour (4). The difference in temperature between the sample setups is
significantly; the camera which is not mounted to any heat conductor after one hour in an environmental
◦
temperature of 22.5 C have camera temperature at 50.4
camera temperature drops about 12 to 15
55
50
45
40
35
(3)
30
25
(1) (2)
20
0
Figure 60: Example of heat up behavior of a camera with different thermal connections
◦
C.
Heat-UpAGraphsA(GC1921C)
500 1000
2 SMARTEK Vision Giganetix Camera Models
◦
C. With a small aluminum heat conductor the
1500 2000
TimeA(inAs)
