5 Image Transmission over Gigabit Ethernet
Setting Frame Transfer Delay
For setting FrameTransferDelay property, camera provides GevSCFTD register which is represented in
ticks. To calculate the value for GevSCFTD, FrameTransferDelay needs to be converted from time unit to
ticks. Before calculating, FrameTransferDelay need to be converted to seconds so correct value can be
calculated. Formula to calculate number of ticks for given time value is shown below:
GevSCFTD = FrameTransferDelay × GevTimestampTickFrequency
GevTimestampTickFrequency - indicates the number of timestamp ticks during 1 second
