Figure 137 shows the look-up table feature located in the LUT tab within the Image Processing Properties
panel. If not visible, the Image Processing Properties panel can be activated by the menu bar entry Control
⇒ Image Processing Properties.
Enable LUT: Enable application of look-up table
Reset: Reset look-up table to default values
Load Values: Load an user-defined XML file with look-up table parameters into the client
Save Values: Save the user-defined look-up table to a file
Inverse: Generate a predefined look-up table which inverts the image
Figure 137: Look-up table feature in GigEVisionClient
