Figure 135 shows the same purpose by a complex function and illustrates that the implemented algorithms
can be arbitrarily complex. However, the calculation for generating look-up tables will be executed only once.
255
240
225
210
195
180
165
150
135
120
105
90
75
60
45
30
15
0
0
Figure 135: Example 2 of enhancing contrast of an image using look-up table
Look-up table in GigEVisionSDK
In the GigEVisionSDK the ImageProcAPI provides the programming interface for generating and modifying
look-up tables. The bit depth and image type supported are shown in Table 82. For a detailed description on
how to use the look-up table feature please refer to the GigEVisionSDK API Help located in the doc folder
of the GigEVisionSDK installation directory.
Supported image input
15 30 45 60 75 90 105 120 135 150 165 180 195 210 225 240 255
index
Monochrome
Raw Bayer
Color RGB
Table 82: Look-up table - supported bit depth and image types
7 Image Processing in GigEVisionSDK
index value
0 0
1 0
2 0
... ...
126 126
127 127
128 128
... ...
253 255
254 255
255 255
Supported bit depth
8 bit per channel
169
Input Image
Output Image
16 bit per channel
