2.3.2 Power and I/O-Interface

Beside the Ethernet interface for communication and data transmission, all cameras are equipped with a
Power and I/O-Interface. Via this interface the cameras provide access to two digital input and two digital
output lines, as well as their main power supply input. Depending on the type of camera there are two
different kind of connector types used, shown in Table 33.
Model
GC (standard housing)
◦
GC-S90 (angled 90
GCP (standard housing)
GC-BL (board level)
2.3.2.1 12-pin Circular Hirose Connector
The housed Giganetix standard and 90
to provide access to the power interface as well as the input and output lines. Figure 55 shows the pin and
connector orientation on the back of the camera housing, Table 34 shows the corresponding pin assignment.
Figure 55: 12-pin circular Hirose receptacle - Pin and connector orientation
12-pin Circular Hirose
housing) 12-pin Circular Hirose
12-pin Circular Hirose
10-pin Molex Picoblade
Table 33: Power and I/O-interface connector type per model
◦ angled cameras are equipped with a 12-pin circular Hirose receptacle
2 SMARTEK Vision Giganetix Camera Models
Connector Type
64
Receptable
HR10A-10P-12S
HR10A-10P-12S
HR10A-10P-12S
53398-1071, 10-pins
