5.3.5 Disable the Flow Control

To further optimize the latency of the data transmission, shown in 5.3.4 - Disable the Interrupt Moderation
Rate, it is possible to disable the so called Flow Control. The Flow Control is a feature to adapt the
transmission speed of the transmitter to the speed available at the receiver by sending PAUSE frames
in-between.
As deactivating this feature can cause in packet lost due to missing bandwidth, it is
Note
generally not recommended to be disabled!
On Microsoft Windows operating systems the Flow Control can be accessed on the following way:
1. Execute "ncpa.cpl", e.g. via the command box of the Windows Startmenu or after pressing
your keyboard
2. Right-click the target network interface card and choose Properties.
3. Press the Configure button below the name of the physical network interface, shown in Figure 109.
4. The settings of the driver can be accessed by choosing the Advanced tab of the opened window. As
shown in Figure 113 , set the value of the Interrupt Moderation Rate property to Disabled.
Figure 113: Network interface card - advanced driver settings - Flow Control
5 Image Transmission over Gigabit Ethernet
142
SMARTEK Vision Giganetix User Manual Version 2.1.4
+ R on
