2.1.2 Giganetix with 90
The 90 ◦ angled version of the Giganetix camera series is identical to the standard GC camera, fitted into a
different form factor to enhance its flexibility. It aims on very build-up applications and all such with limited
space in sensor axis. Due to its non-symmetrical housing the GC-S90 series supports image mirroring to
reverse the image about its X- and Y-Axis to allow a most possible flexibility in positioning.
External dimensions
(H x W x L)
Housing
Weight
Storage temperature
Operating temperature
Operating humidity
Storage humidity
Power requirement
Lens mount
Connectors
Digital input
Digital output
Conformity
◦
Angled Housing (GC-S90 Series)
Figure 3: Giganetix Camera with 90
35 x 35 x 75 [mm]
Black anodized aluminum case with 90
Approx. 120g
1
-30 ◦ C to +60
1
◦
0 C to +50
10V to 24V DC via Power and I/O-interface
Screw mount Ethernet RJ45 (Communication and Data),
Circular Hirose 12 pin (Power and I/O-Interface)
Table 5: Mechanical and electrical specifications
2 SMARTEK Vision Giganetix Camera Models
◦
angled housing
◦ C
◦
C
20% to 80%, relative, non-condesing
20% to 80%, relative, non-condesing
C-Mount
2 input channels, opto-isolated
2 output channels, opto-isolated
CE, FCC, RoHS, GigE Vision, GenICam
10
1.38 x 1.38 x 2.95 [in]
◦
angled sensor and lens mount
approx. 4.2oz
-22 ◦ F to +140 ◦ F
+32 ◦ F to +122 ◦ F
1
measured at camera housing
