Parameter
TbpVerticalStep
TbpFramesToAvg
TbpPixelDiffTreshold
TbpTapDiffTreshold
TbpTapDiffTresholdPercent
TbpTapDiffTresholdBLoAvg
By lowering the TbpVerticalStep parameter, the algorithm uses more pixels in
calculation and consequently provides more precise results. On the other hand,
Note
using more pixels in calculation causes the algorithm to be slower and can lead to
a decreased frame rate.
Increasing the TbpFramesToAvg parameter increases the amount of frames used in
averaging, localized single frame tap differences thus have smaller impact on the final
Note
result when tap difference is compared to the threshold. On the other hand, increasing
the number of frames used for averaging increases the delay or reaction time between
detecting the difference between taps and adjusting it.
The operation of the automatic tab balancing algorithm can be controlled via the property GainAutoBalance,
adjusting the gain, and BlackLevelAutoBalance, adjusting the Black Level of the camera. Both have three
operation modes, listed it Table 50.
Value
Off
Once
Continuous
Table 50: Parameters for GainAutoBalance and BlackLevelAutoBalance
Type
Integer
Number of frames averaged and used in Tap Balance
Integer
Float
Float
Maximum allowed difference between taps in percent
Float
Maximum allowed black level difference between taps.
Float
Table 49: Auto Tap Balancing - Parameters
Tap balancing is disabled; taps can be balanced manually via the gain and
black level properties after choosing the target tap
Balancing of taps is done once until both taps are matched, the algorithm is
Tap balancing algorithm is running continuously (default)
114
Description
Vertical step used in Tap Balance algorithm
algorithm
Maximum difference between adjacent pixels on
different taps to include them in calculation
Maximum allowed difference between taps
Description
then set to Off
4 Image Acquisition
