2 SMARTEK Vision Giganetix Camera Models

The Giganetix camera family consists of a line-up of GigE Vision compliant cameras equipped with a
selection of CCD and CMOS sensors, fitted into several different camera designs. The following chapter
contains the hardware specification of the single camera series and their different models, including technical
drawings. Table 3 gives a brief overview about the unique characteristics of each series.
Type
GC (standard housing)
◦
GC-S90 (angled 90
GC-BL (board level)
GCP (standard housing)
Short Description
Standard Giganetix Camera
Standard Giganetix Camera with 90
housing)
with very limited space in optical axis and other mechanical
restrictions, making the standard housing unsuitable.
◦
90 Board level version of the standard Giganetix Camera with a
single mainboard and detached sensor head. Suitable for OEM and
special solutions where a camera needs to be integrated into a closed
device and/or a housed camera does not fit into the design.
Enhanced version of the Giganetix Camera in an adapted mechanical
design providing a set of high-end sensors and increased hardware
capabilities, as well as Power over Ethernet by default.
Table 3: Giganetix Family Camera Lines
2 SMARTEK Vision Giganetix Camera Models
◦ angled housing. For applications
7
