Sharpening in the GigEVisionSDK
In the GigEVisionSDK the ImageProcAPI provides the programming interface for configuring and executing
the sharpening algorithm. The bit depths and image types supported are shown in Table 92. For a detailed
description on how to use this feature please refer to the GigEVisionSDK API Help located in the doc folder
of the GigEVisionSDK installation directory.
Supported image input
Sharpening in the GigEVisionClient
In the GigEVisionClient the Image Sharpen options can be accessed in the Image Processing Properties
panel under Other, shown in Figure 158. If not visible, the panel can be enabled by the menu bar entry
Control ⇒ Image Processing Properties.
Enable: Activate / deactivate the image sharpening feature
Reset: Sets the sharpen factor to the default value
Monochrome
Raw Bayer
Color RGB
Table 92: Sharpening - supported bit depth and image type
Figure 158: Sharpening in the GigEVisionClient
7 Image Processing in GigEVisionSDK
Supported bit depth
8 bit per channel
193
16 bit per channel
