Smartek Vision Giganetix GC Series User Manual page 194

Matrix Multiplication 3x3 in the GigEVisionClient
In the GigEVisionClient the demosaicing options can be accessed in the Image Processing Properties panel
under Matrix, shown in Figure 154. If not visible, the panel can be enabled by the menu bar entry Control
⇒ Image Processing Properties.
Enable: Activate / deactivate the matrix multiplication feature
Reset: Sets matrix coefficients to default values
Load Values: Load a file with user-defined matrix coefficients
Save Values: Save the current matrix coefficients to a file
Figure 154: Matrix Multiplication RGB in the GigEVisionClient
7 Image Processing in GigEVisionSDK
188
SMARTEK Vision Giganetix User Manual Version 2.1.4
