SCSI (VHDC)
The SCSI port on the CPU FTC for the Netra ct 400 server is a 68-pin CHAMP very
high-density connector (VHDC). Note that a VHDC-to-SCSI 3 cable is included with
the Netra ct server (part number 530-2454-01).
TABLE 6-9
Pin No. Signal
1 GND
2 PRES_L
3 GND
4 GND
5 GND
6 GND
7 GND
8 GND
9 GND
10 GND
11 GND
12 GND
13 GND
14 GND
15 GND
16 GND
17 TERM PWR
18 TERM PWR
19 GND
20 GND
21 GND
22 GND
23 GND
SCSI Port Pinouts, CPU FTC for the Netra ct 400 Server
Pin No. Signal
24 GND
25 GND
26 GND
27 GND
28 GND
29 GND
30 GND
31 GND
32 GND
33 GND
34 GND
35 DATA 12
36 DATA 13
37 DATA 14
38 DATA 15
39 PH_L
40 DATA 0
41 DATA 1
42 DATA 2
43 DATA 3
44 DATA 4
45 DATA 5
46 DATA 6
Pin No. Signal
47 DATA 7
48 PL_L
49 PRES_L
50 GND
51 TERM PWR
52 TERM PWR
53 GND
54 GND
55 ATN_L
56 GND
57 BSY_L
58 ACK_L
59 RST_L
60 MSG_L
61 DEL_L
62 CD_L
63 REQ_L
64 IO_L
65 DATA 8
66 DATA 9
67 DATA 10
68 DATA 11
Chapter 6 Cabling the System 73
