To Connect Cables to the CompactPCI Front-
Access I/O Cards
1. Locate the I/O card.
on page 44 shows the possible locations for the I/O cards in the Netra ct
FIGURE 5-2
800 server and
FIGURE 5-4
in the Netra ct 400 server.
2. Make the necessary cable connections to the CompactPCI I/O cards.
Tighten the screws on the cable to a torque of 0.23 N.m (2 in.-lb).
Refer to the documentation that you received with the CompactPCI I/O cards for
more information.
Cabling for the Rear-Access Model
"To Connect Cables to the CPU Rear Transition Card" on page 87
"To Connect Cables to the Alarm Rear Transition Card (Rear-Access Models
Only)" on page 97
"To Connect Cables to the Rear-Access I/O Cards" on page 103
To Connect Cables to the CPU Rear Transition
Card
1. Go to the rear of the chassis and locate the CPU rear transition card.
shows the location of the CPU rear transition card in the Netra ct 800
FIGURE 6-29
server, and
FIGURE 6-30
Netra ct 400 server.
on page 46 shows the possible locations for the I/O cards
shows the location of the CPU rear transition card in the
Chapter 6
Cabling the System
87
