When you first power-on the Netra ct server, some or all of the green Power LEDs
on the system status panel flash on and off for several seconds:
If the diag-switch variable is set to true and the diag-level variable is set to
max in the OpenBoot™ PROM, then all of the green Power LEDs on the system
status panel flash on and off for several seconds.
If the variables in the OpenBoot PROM are not set as described above, then the
green Power LEDs on the system status panel flash on and off for several seconds
only for the components that are installed in the server.
Note – Refer to the Solaris documentation that you received with your system for
instructions on setting variables in the OpenBoot PROM.
System power
LED
FIGURE 7-4
System power
button
System Power Button and System Power LED Locations (Netra ct 800 Server)
Chapter 7 Powering the Server On and Off 125
