7
B9
Insert the Drip Tray (B9) by sliding it underneath the barbecue body. Insert the Drip Pan(B12)
in position.
8
B3
B4
Remove the plastic wrap from the Lava Rock (B3) and then place a uniform layer into Lava
Rock Basket (B4). Lay the lava rock carefully into the body ensuring it lies level within the
body. Lay the cooking grill (B1) and griddle (B2) into place.
2/3 burner model configuration: Left — Cooking Grill, Right — Cooking Griddle
NOTE: Ensure that the lava rock lies directly underneath the grills.
B1 B2
8
B12
