Outback® 2 Burner, Outback® 3 Burner, and Outback® 4 Burner Gas Barbecues
Photographs are not to scale.
Specifications subject to change
without prior notice.
•
•
•
•
•
•
•
•
WARNING
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Gas Barbecues
Assembly and Operating Instructions for
For outdoor use only.
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young children away.
Do not move the appliance during use.
Turn off the gas supply at the gas bottle after use.
Any modification of the appliance, misuse, or failure to follow the instructions may be
dangerous and will invalidate your warranty. This does not affect your statutory rights.
Retain these instructions for future reference.
Leak test your barbecue annually. Check the hose connections are tight and leak test
each time you reconnect the gas bottle.
FOR YOUR SAFETY
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2 Burner and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Outback 2 Burner

Summary of Contents for Outback 2 Burner

  • Page 1 Gas Barbecues Assembly and Operating Instructions for Outback® 2 Burner, Outback® 3 Burner, and Outback® 4 Burner Gas Barbecues Photographs are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.

  • Page 2: Parts List

    Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram’. Outback® Outback® Outback® CODE PART 2 Burner 3 Burner 4 Burner Lid Handle Flat Lid (Pre-Assembled to Body) Burner Hose and Hose Clip...

  • Page 3: Parts Diagrams

    B. Parts Diagrams Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram.’...
  • Page 4 C. Hardware Reference Diagram Specifications subject to change without prior notice.

  • Page 5: Tools Needed For Assembly

    D. Assembly TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/crosspoint screwdriver, adjustable spanner or metric spanner set. The assembly of this barbecue requires 2 people. Whilst every care is taken in the manufacture of this product, care must be taken during assembly in case sharp edges are present.
  • Page 6 Turn the trolley over so that it stands on its side shelves. Slide the axle (C10) through the corresponding holes in the short legs. Place a washer (D7) on each end of the axle. Slide the wheels (C8) over each end of the axle. Secure the wheels into place with the locknuts (D6).
  • Page 7 Lay the assembled trolley on its side. Lay the body (B3) on its back and slide into position between the trolley legs. Warning: Care must be taken to ensure lid does not fall open unexpectedly. With the barbecue laid on the ground, insert a body support bolt (D3) through the short leg, through a spacer (D4), through the sidewall of the body, and secure the bolt with a wing nut (D5).
  • Page 8 Replace the drip tray (B5) by sliding it underneath the barbecue body (B3). Attach the lid handle (A1) to the lid (A2) using the handle bolts (D1).
  • Page 9 Remove the plastic wrap from the lava rock basket(s) (B9) and lay them carefully into the body ensuring that they lie level within the body. Lay the cooking grill(s) (B7) and griddle (B8) into place. 2/4 burner model configuration: Left half—Cooking Grill, Rock Basket; Right half—Griddle Plate 3 burner model configuration: Left third—Cooking Grill, Rock Basket;...
  • Page 10 Leak Test Diagram 11a. Connect the gas hose (B2) to the barbecue (Before the Leak Test). Ensure the mating faces of the connection are clean and not damaged. Do not use any sealing tape, paste, or liquid on the joint. The nut must be tightened with the use of a spanner. Do not use force which may damage the assembly.
  • Page 11 Bottle Size Bottle Size when lit. Outback® Parts of this barbecue become very hot – 15kg 2 Burner care must be taken when children, elderly Outback® people, and animals are present. 13kg 3 Burner Always turn off the gas bottle when the Outback®...

  • Page 12: Installation

    connections regulator connections. G. Installation NEVER USE AN OPEN FLAME to test for leaks at anytime. If bubbles form over any of G1. Selecting a Location the joints, there is a leak. Turn off the gas This barbecue is for outdoor use only and supply and retighten all joints.
  • Page 13 position. Close the gas valve on the gas H6. Griddle Plate Cooking bottle. Wait five minutes. Reattempt all of The cast iron burners heat the griddle plate the above steps. If the barbecue still fails directly, which then cooks the food on contact. to light, please refer to the manual ignition Plates allow for the cooking of smaller items, instructions below.

  • Page 14: Care And Maintenance

    To clean a burner, remove it from the Outback® stockist. barbecue. It is quite normal for a cast iron burner to rust. The outside of the burner can Even when your barbecue is covered for its be cleaned with a wire brush.
  • Page 15 Wrap residue. Replacement lava rock is available the burners in aluminium foil to help prevent from your local Outback® stockist. insects or other debris from obstructing the burners. I4. Drip Tray...

  • Page 16: Technical Specifications

    J. Technical Specifications Note: Heat Injector Gas / Burners Approval Input Size Pressure Outback® 2 0359 9.5kW Burner 359AS128 Butane/ 28-30mbar Outback® 3 0359 1.12 14.5kW Burner 359AS128 (#44) Propane/ 37mbar Outback® 4 0359 19.0kW Burner 359AS128 Countries of Use:...

  • Page 17: Troubleshooting

    K. Troubleshooting Problem Possible Cause Solution Burners will not light using the LP gas cylinder is empty Replace with full cylinder ignition system Faulty regulator Have regulator checked or replace Obstructions in burners Clean burners Obstructions in gas jets or gas hose Clean jets and gas hose Electrode wire is loose or disconnected on Reconnect wire...
  • Page 18 OUTBACK barbecues are warranted to the original purchaser against defects in materials and workmanship for a period of one (1) year from the date of purchase. OUTBACK UK will, within this period, supply replacements for defective parts free of charge provided that: ♦...
