Outback Spectrum 2 Burner Assembly And Operating Instructions Manual

Gas barbecues
Hide thumbs Also See for Spectrum 2 Burner:

Advertisement

Quick Links

Download this manual
Outback® Spectrum 2 Burner, Spectrum 3 Burner Gas Barbecues
Photograph is not to scale.
Specifications subject to change
without prior notice.
•
•
•
•
•
•
WARNING
•
•

FOR YOUR SAFETY

If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Gas Barbecues
Assembly and Operating Instructions for
For outdoor use only.
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young children away.
Do not move the appliance during use.
Turn off the gas supply at the gas bottle after use.
Any modification of the appliance, misuse, or failure to follow the instructions may be
dangerous and will invalidate your warranty. This does not affect your statutory rights.
Retain these instructions for future reference.
Leak test your barbecue annually. Check the hose connections are tight and leak test
each time you reconnect the gas bottle.
FOR YOUR SAFETY
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

loading
Need help?

Need help?

Do you have a question about the Spectrum 2 Burner and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Outback Spectrum 2 Burner

Summary of Contents for Outback Spectrum 2 Burner

  • Page 1: For Your Safety

    Gas Barbecues Assembly and Operating Instructions for Outback® Spectrum 2 Burner, Spectrum 3 Burner Gas Barbecues Photograph is not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.
  • Page 2 A. Parts List Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see Hardware Reference Diagram. Outback® Outback® CODE Spectrum 2 Spectrum 3 Lid Handle Flat Lid (Pre-Assembled to Body)
  • Page 3 B. Parts Diagrams Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram.’...

  • Page 4: Burner 2

    C. Hardware Reference Diagram Specifications subject to change without prior notice. D2,D3,D4 D6,D7...

  • Page 5: Wheel

    D. Assembly TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/crosspoint screwdriver, adjustable spanner or metric spanner set. The assembly of this barbecue requires 2 people. Whilst every care is taken in the manufacture of this product, care must be taken during assembly in case sharp edges are present.

  • Page 6: M6X25 Bolt

    Attach the side shelves (C1) to the front/rear left legs (C2,C3) and front/rear right legs (C4,C5) using the M6x25 bolts (D5). Remove all cast iron cooking components, flame tamer, drip tray, and any internal packaging from the barbecue body.

  • Page 7: M6X145 Bolt

    Lay the assembled trolley on its side. Lay the body (B1) on its back and slide into position between the trolley legs. Warning: Care must be taken to ensure lid does not fall open unexpectedly. With the barbecue laid on the ground, insert a M6x145 bolt (D6) through the short leg, through a spacer (D7), and secure the bolt into the sidewall of the body.
  • Page 8 Remove the plastic wrap from the flame tamer (B12) and lay them carefully into the body ensuring they lie level within the body. Lay the cooking grill(s) (B9, B10)and griddle (B11) into place. 2 burner model configuration: Left — Large Cooking Grill, flame tamer, Right — Small Cooking Grill, flame tamer;...
  • Page 9 Attach the drip tray handle (B6) to the drip tray (B5) using the M5x10 bolts (D1). Put the drip tray underneath the body (B1) from back side. Attach the warming rack (B14) to the flat lid as shown.
  • Page 10 (Rear view of the barbecue trolley.) Attach the screen (C6) to the front left/right legs as shown. Connect the gas hose and regulator (B13) to the BBQ. Ensure the mating faces of the connection are clean and not damaged. Do not use any sealing tape, paste or liquid on the joint.
  • Page 11 Butane Minimum Propane Minimum Bottle Size Bottle Size Parts of this barbecue become very hot – care must be taken when children, Outback® elderly people, and animals are present. Spectrum 15kg Always turn off the gas bottle when the 2 Burner barbecue is not in use.
  • Page 12 screws. Open the gas control valve on the G. Installation bottle or regulator. Check for leaks by brushing a solution of ½ water and ½ soap G1. Selecting a Location over all gas system joints, including all This barbecue is for outdoor use only and valve connections, hose connections and should be placed in a well-ventilated area.
  • Page 13 holding in the control knob in at the Do not attempt to cook with the lid closed. This will result in severe damage to your barbecue. “High” position and turning to “Off”. The Ensure all burners are turned off and the lighting sequence can then be repeated barbecue has cooled down before closing the lid.
  • Page 14 Bringing the barbecue out of storage. left outside for any length of time, especially • One or more of the burners do not during the winter months. Heavy-duty ignite. Outback® barbecue covers and other • burner flame pattern accessories are available from your local significantly yellow.
  • Page 15 • I5. Barbecue Body The gas ignites behind the control Regularly remove excess grease or fat from panel. the barbecue body with a soft plastic or wooden scraper. It is not necessary to To clean a burner, remove it from the remove all the grease from the body.
  • Page 16 Burners that is found that does not come into Approval Input Size Pressure contact with the food should be treated with Outback® a rust inhibitor and painted with barbecue 0359 Spectrum 8.8kW Butane/28 359AS128 paint or a heat resistant paint. Wooden...
  • Page 17 K. Troubleshooting Problem Possible Cause Solution Burners will not light us- LP gas bottle is empty Replace with full bottle ing the ignition system Faulty regulator Have regulator checked or replace Obstructions in burners Clean burners Obstructions in gas jets or gas hose Clean jets and gas hose Electrode wire is loose or disconnected Reconnect wire...
  • Page 18 (10) years from the date of pur- chase. Stainless steel burners are warranted for a period of two (2) years from the date of pur- chase. OUTBACK UK will, within this period, supply replacements for defective parts free of charge provided that: ♦...

This manual is also suitable for:

Spectrum 3 burner
