Outback Spectrum 2 Burner Assembly And Operating Instructions Manual

Hide thumbs Also See for Spectrum 2 Burner:

Advertisement

Quick Links

Download this manual See also: Assembly and Operating Instructions Manual
Outback® Spectrum 2 Burner, Spectrum 3 Burner Gas Barbecues
Photograph is not to scale.
Specifications subject to change
without prior notice.
•
For outdoor use only.
•
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
•
Warning: accessible parts may be very hot. Keep young children away.
•
Do not move the appliance during use.
•
Turn off the gas supply at the gas bottle after use.
•
Any modification of the appliance, misuse, or failure to follow the instructions may be
dangerous and will invalidate your warranty. This does not affect your statutory rights.
WARNING
•
Retain these instructions for future reference.
•
Leak test your barbecue annually. Check the hose connections are tight and leak test
each time you reconnect the gas bottle.
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Gas Barbecues
Assembly and Operating Instructions for
1.
2.
FOR YOUR SAFETY
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

loading
Need help?

Need help?

Do you have a question about the Spectrum 2 Burner and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Outback Spectrum 2 Burner

Summary of Contents for Outback Spectrum 2 Burner

  • Page 1 Gas Barbecues Assembly and Operating Instructions for Outback® Spectrum 2 Burner, Spectrum 3 Burner Gas Barbecues Photograph is not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.
  • Page 2 A. Parts List Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see Hardware Reference Diagram. Outback® Outback® CODE Spectrum 2 Spectrum 3 Lid Handle Flat Lid (Pre-Assembled to Body)
  • Page 3 B. Parts Diagrams Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram.’...
  • Page 4 C. Hardware Reference Diagram Specifications subject to change without prior notice. D2, D3...
  • Page 5 D. Assembly TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/crosspoint screwdriver, adjustable spanner or metric spanner set. The assembly of this barbecue requires 2 people. Whilst every care is taken in the manufacture of this product, care must be taken during assembly in case sharp edges are present.

  • Page 6: Drip Tray

    Attach the side shelves (C1) to the front/rear left legs (C2,C3) and front/rear right legs (C4,C5) using the trolley bolts (D1). Remove all cast iron cooking components, briquettes, drip tray, and any internal packaging from the barbecue body. Note: Loosen off the bolts and move the brackets down to their lowest position. Retighten the bolts.
  • Page 7 Lay the assembled trolley on its side. Lay the body (B1) on its back and slide into position between the trolley legs. Warning: Care must be taken to ensure lid does not fall open unexpectedly. With the barbecue laid on the ground, insert a body support bolt (D2) through the short leg, through a spacer (D3), and secure the bolt into the sidewall of the body.

  • Page 8: Drip Tray Handle

    Attach the drip tray handle (B6) to the drip tray (B5) using the handle bolts (D6). Put the drip tray underneath the body (B1) from back side or front side. Remove the plastic wrap from the briquettes (B10,B11) and lay them carefully into the body ensuring...

  • Page 9: Warming Rack

    (Rear view of the barbecue Attach the warming rack (B13) to the flat Attach the screen (C6) to the front left/right lid as shown. legs as shown. Connect the gas hose (B12) to the BBQ. Ensure the mating faces of the connection are clean and not damaged.
  • Page 10 Butane Minimum Propane Minimum Open the barbecue lid before lighting. The Bottle Size Bottle Size barbecue should never be lit or used while Outback® the lid is closed. Spectrum 15kg Do not move the barbecue while alight. 2 Burner This barbecue must not be left unattended Outback®...
  • Page 11 should NEVER be closer than 1 metre from any H. Operation combustible surface. Keep this barbecue away from any flammable materials! Warnings Before proceeding, make certain that you G2. Precautions understand the IMPORTANT INFORMATION Do not obstruct any ventilation openings in the section of this manual.
  • Page 12 panel and place near leftmost burner H8. Flare-Up Control porthole. Flare-ups occur when meat is barbecued, and its • fat and juices fall upon the hot briquettes. Smoke Push and turn the leftmost control knob anti- helps give food its barbecued flavour, but avoid clockwise to the high position.

  • Page 13: Washer

    Take care not to enlarge the portholes. available from your local Outback® stockist. Clean the insect screen on the end of the venturi tube with a bristle brush (i.e. an old toothbrush).
  • Page 14 Gas / Burners Approval Input Size Pressure I6. Trolley Your trolley is manufactured using a hardwood Outback® 0359 suited to outdoor use, provided it is treated with Spectrum 7.87kW Butane/28 359AS128 2 Burner Teak oil or similar after assembly and on a -30mbar 1.02...
  • Page 15 K. Troubleshooting Problem Possible Cause Solution Burners will not light LP gas bottle is empty Replace with full bottle using the ignition system Faulty regulator Have regulator checked or replace Obstructions in burners Clean burners Obstructions in gas jets or gas hose Clean jets and gas hose Electrode wire is loose or disconnected Reconnect wire...
  • Page 16 OUTBACK UK LTD LIMITED 10 YEAR WARRANTY OUTBACK barbecues are warranted to the original purchaser against defects in materials and workmanship. Porcelain coated barbecue bodies, porcelain coated roasting hoods and stainless steel roasting hoods are warranted for a period of ten (10) years from the date of purchase.

This manual is also suitable for:

Spectrum 3 burner
