Network Video Recorder
User's Manual
Version 1.0.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP-UNR-1xxQ1 Series and is the answer not in the manual?

Questions and answers

Related Manuals for CP Plus CP-UNR-1xxQ1 Series

Summary of Contents for CP Plus CP-UNR-1xxQ1 Series

  • Page 1 Network Video Recorder User’s Manual Version 1.0.1...

  • Page 2: Table Of Contents

    Table of Contents Features and Specifications ..................... 1 Overview ..........................1 Features ..........................1 Specifications ........................2 1.3.1 CP-UNR-1xxQ1/CP-UNR-1xxQ1P Series ..............2 1.3.2 CP-UNR-3xxQ2-XU/CP-UNR-3xxQ2P-XU Series ............. 4 1.3.3 CP-UNR-2xxQ2/CP-UNR-2xxQ2P Series ..............5 1.3.4 CP-UNR-2xxQ4/CP-UNR-2xxQ4P Series ..............7 1.3.5 CP-UNR-4xxQ8-XU Series ..................8 1.3.6 CP-UNR-3xxT2/CP-UNR-3xxT2P Series ..............
  • Page 3 Search & Playback ......................54 Information ........................57 5.5.2 HDD Information......................58 5.5.3 BPS ........................... 59 5.5.4 Log ..........................60 5.5.5 Version........................61 5.5.6 Online Users ......................62 5.5.7 Remote Device Information ..................62 5.5.8 Network Info ......................63 5.5.8.1 Network Test .....................
  • Page 4 5.7.4 Alarm Output ......................104 5.7.5 Manual Record ......................104 5.7.5.1 Manual record menu ..................104 5.7.5.2 Basic operation ....................104 5.7.5.3 Enable/disable record ..................105 5.7.5.4 Enable all channel recording ................105 5.7.5.5 Stop all channel recording ................106 5.7.6 Account........................
  • Page 5 7.4.4.3 Alarm I/O ......................150 7.4.4.4 Record ......................151 7.4.4.5 Account ......................151 7.4.4.6 Snapshot ......................153 7.4.4.7 Auto Maintenance ................... 153 7.4.4.8 Remote device ....................154 7.4.4.9 Preview Control ....................155 7.4.5 Additional Function ....................156 7.4.5.1 IPC Config ....................... 156 7.4.5.2 Auto register ....................
  • Page 6 Welcome Thank you for purchasing our network video recorder! This user’s manual is designed to be a reference tool for your system. Please open the accessory bag to check the items one by one in accordance with the list below. Contact your local retailer ASAP if something is missing or damaged in the bag.
  • Page 7 Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. 2．Transportation security Heavy stress, violent vibration or water splash are not allowed during transportation, storage and installation.

  • Page 8: Installation Environment

    Before your operation please read the following instructions carefully.  Installation environment  Keep away from extreme hot places and sources；  Avoid direct sunlight；  Keep away from extreme humid places；  Avoid violent vibration；  Do not put other devices on the top of the NVR； ...

  • Page 9: Features And Specifications

    1 Features and Specifications 1.1 Overview This series NVR is a high performance network video recorder. This series product support local preview, multiple-window display, recorded file local storage, remote control and mouse shortcut menu operation, and remote management and control function. This series product supports centre storage, front-end storage and client-end storage.

  • Page 10: Specifications

     Support IPC or NVS remote video preview and control. 1.3 Specifications 1.3.1 CP-UNR-1xxQ1_ CP-UNR-1xxQ1P Series Parameter Specifications CP-UNR-1xxQ1 Series CP-UNR-1xxQ1P Series System Max support 8-ch standard definition with the transmission rate of 2Mbps for Resources each channel; 4-channel 720P, with the transmission rate of 4Mbps for each channel;...
  • Page 11 1/4/9-window Window Split Multiple-channel Max 8-channel D1/4-channel 720P/2-channel 1080P playback. Playback Alarm Input Alarm Output 1 built-in SATA ports. Storage RS232 Port One RS232 port to debug transparent COM data. RS485 port USB2.0 Port 2 peripheral USB2.0 ports. One at the front panel and one at the rear panel. Network One RJ45 10/100Mbps self-adaptive Ethernet port.

  • Page 12: Cp-Unr-3Xxq2-Xu/Cp-Unr-3Xxq2P-Xu Series

    1.3.2 CP-UNR-3xxQ2-XU _ CP-UNR-3xxQ2P-XU Series Specifications Parameter CP-UNR-3xxQ2-XU Series CP-UNR-3xxQ2P-XU Series Max support 16-ch standard definition with the transmission rate of 2Mbps for each channel; System 8-channel 720P, with the transmission rate of 4Mbps for each channel; Resources 4-channel 1080P, with the transmission rate of 8Mbps for each channel; Support 20 online users at the same time, The image delay time of each channel is under 500ms.

  • Page 13: Cp-Unr-2Xxq2/Cp-Unr-2Xxq2P Series

    One power port, power adapter. Input DC 12V. Power Port No on/off button. Connect to the power cable to boot up. Power Button Power Button Remote Control Support IR remote control Receiver Built-in clock. Clock One power status indication light. Indication Light One network status indication light.
  • Page 14 Compression Video Output 1-channel VGA analog video output. Video Input 4/8/16-ch network compression video input HDMI 1-ch HDMI output. Audio Input 1-ch bidirectional audio input Audio Output 1-ch bidirectional talk output. Window Split 4/8/9/16-window Multiple-chann Max 16-channel D1/8-channel 720P/4-channel 1080P playback. el Playback Alarm Input 4/8/16-ch series product support 4/8/16-ch alarm input respectively.

  • Page 15: Cp-Unr-2Xxq4/Cp-Unr-2Xxq4P Series

    Humidity Air pressure 86kpa－106kpa Dimension 375mm×287mm×52mm Weight 1.5～2.5 KG（Exclude HDD） Installation Desk installation/Rack installation 1.3.4 CP-UNR-2xxQ4_ CP-UNR-2xxQ4P Series Parameter Specifications CP-UNR-2xxQ4 Series CP-UNR-2xxQ4P Series Max support 16-ch standard definition with the transmission rate of 2Mbps for each channel; System 8-channel 720P, with the transmission rate of 4Mbps for each channel; 4-channel 1080P, with the transmission rate of 8Mbps for each channel;...

  • Page 16: Cp-Unr-4Xxq8-Xu Series

    One RS485 port to control PTZ. Support various protocols. RS485 port USB2.0 Port 3 peripheral USB2.0 ports. Network One RJ45 10/100M/1000Mbps self-adaptive Ethernet port. Connection One power port, power adapter. Input DC Two power ports, power adapter. Input DC Power Port 12V.
  • Page 17 Encode For H.264, it max supports 16-channel D1, 8-channel 720, 4-channel 1080P. Capacity Audio G.711a Compression Video Output 1-channel VGA analog video output. 4/8/16-ch network compression video input Video Input HDMI 1-ch HDMI output. Audio Input 1-ch bidirectional audio input Audio Output 1-channel bidirectional talk output.

  • Page 18: Cp-Unr-3Xxt2/Cp-Unr-3Xxt2P Series

    Air pressure 86kpa－106kpa Dimension 157.5mm×220mm×172mm Weight 1.5～2.5KG（Exclude HDD） Installation Desk installation 1.3.6 CP-UNR-3xxT2_ CP-UNR-3xxT2P Series Specifications Parameter CP-UNR-3xxT2 Series CP-UNR-3xxT2P Series Max support 32-ch standard definition with the transmission rate of 2Mbps for each channel; System 16-channel 720P, with the transmission rate of 4Mbps for each channel; Resources 8-channel 1080P, with the transmission rate of 8Mbps for each channel;...

  • Page 19: Cp-Unr-3Xxt8 Series

    USB2.0 Port 2 peripheral USB2.0 ports. Network One RJ45 10/100M/1000Mbps self-adaptive Ethernet port. Connection One power port, power adapter. Input DC Two power ports, power adapter. Input DC Power Port 12V. 12V or DC 48V. Power Button One power button in the rear panel. Power Button One power button in the front panel.
  • Page 20 Video H.264/MPEG4 Compression Encode For H.264, it max supports 32-channel D1,16-channel 720P,8-channel 1080P Capacity Audio G.711a Compression Video Output 1-channel VGA analog video output. Video Input 8/16/32-ch network compression video input 1-ch HDMI output. HDMI Audio Input 1-ch bidirectional audio input 1-ch bidirectional talk output.
  • Page 21 Power ＜40W(Exclude HDD) Consumption Working 0℃～+50℃ Temperature Working 10℅－90℅ Humidity Air pressure 86kpa－106kpa Dimension 440mm×460mm×89mm Weight 5.5～6.5 KG（Exclude HDD） Desk installation Installation...

  • Page 22: Front Panel And Rear Panel

    2. Front Panel and Rear Panel Front Panel 2.1.1 CP-UNR-1xxQ1_ CP-UNR-1xxQ1P Series The front panel is shown as in Figure 2-1. Figure 2-1 Please refer to the following sheet for detailed information. Icon Name Function The blue light becomes on when the power Power indicator light connection is OK.
  • Page 23   Shift In textbox, click this button to switch between numeral, English (Small/Capitalized), donation and etc.  Enable or disable tour.  Fast play Various fast speeds and normal playback. Slow play Multiple slow play speeds or normal playback. ...

  • Page 24: Cp-Unr-3Xxt2/Cp-Unr-3Xxt2P Series

    Record Manually stop/start recording, working with direction keys or numeral keys to select the recording channel. Window switch Mult Click it to switch one-window/multiple-window. USB2.0 port To connect USB2.0 storage device, USB2.0 mouse, burner and etc. Record light 1-16 For 4/8/16 channel device: indication light on means that the channel is in recording.
  • Page 25 Alarm indication The alarm indication light becomes on once an alarm light occurred. The alarm includes local alarm, no disk and etc. Network indication The network indication light is blue and it flashes light when you connect the device to the network. USB2.0 port Connect to USB2.0 storage device,mouse, burner and etc.
  • Page 26 2.1.4 CP-UNR-2xxQ2_ CP-UNR-2xxQ2P Series The front panel is shown as below. See Figure 2-5. Figure 2-5 Please refer to the following sheet for front panel button information. Name Icon Function Power button, press this button for three seconds to boot up Power button or shut down NVR.

  • Page 27: Cp-Unr-2Xxq2/Cp-Unr-2Xxq2P Series

     Confirm current operation.  Enter Enter Go to default button.  Go to menu.  One-window monitor mode, click this button to display assistant function: PTZ control and image color.  Backspace function: in numeral control or text control, press it for 1.5seconds to delete the previous character before the cursor.
  • Page 28 Please refer to the following sheet for front panel button information. Name Icon Function Power button Power button, press this button for three seconds to boot up or shut down NVR.  One-window monitor mode, click this button to display assistant function: PTZ control and image color.

  • Page 29: Cp-Unr-2Xxq4/Cp-Unr-2Xxq4P Series

    2.1.6 CP-UNR-2xxQ4_ CP-UNR-2xxQ4P Series The front panel is shown as in Figure 2-7. Figure 2-7 Please refer to the following sheet for front panel button information. Name Icon Function Power button, press this button for three seconds to boot up or Power button shut down NVR.
  • Page 30 etc. Power Power indication light. indication light HDD abnormal HDD error occurs or HDD capacity is below specified threshold indication light value, the light becomes red to alert you. Network Network error occurs or there is no network connection, the light abnormal becomes red to alert you.
  • Page 31 │ Play previous In playback mode, playback the previous video │ Play Next In playback mode, playback the next video  Activate current control, modify setup, and then move up and down. ,   Down Increase/decrease numeral.  Assistant function such as PTZ menu. ...

  • Page 32: Rear Panel

    For 4/8/16 channel device: indication light on means that the channel is in recording. For 32 channel device, channel 17-32 reuse the indication light 1 to 16. For example, the first indication light has the following four statuses:  The first indication light flashes slowly when the 1-channel is Record light 1-16 recording while the 17-channel does not record.

  • Page 33: Cp-Unr-3Xxq2-Xu Series

    2.2.2 CP-UNR-3xxQ2-XU Series The rear panel is shown as below. See Figure 2-11. Figure 2-11 Please refer to the following sheet for detailed information. Port Name Connection Function USB2.0 port. Connect to USB2.0 mouse. 10M/100M/1000Mbps self-adaptive Network port Ethernet port. Connect to the network cable.

  • Page 34: Cp-Unr-3Xxq2P-Xu Series

    Port Name Connection Function 2:port NO2～C2,Group 3:port C1 to C3 NO3～C3）).Output alarm signal to the alarm device. Please make sure there is power to the external alarm device. NO：Normal open alarm output port.  C：Alarm output public end.  RS485 (RS-485) RS485_A port.
  • Page 35 Port Name Connection Function  There are four groups. The first group is 1-16 Alarm input I/O port port. from port 1 to port 4, the second group is from port 5 to port 8, the third group is from 9 to 12, and the fourth group is from 13 to 16.

  • Page 36: Cp-Unr-2Xxq2/Cp-Unr-2Xxq2P Series

    Port Name Connection Function MIC OUT Audio output Audio output port. It is to output the analog port audio signal to the devices such as the sound box.  Bidirectional talk output.  Audio output on 1-window video monitor.  Audio output on 1-window video playback.
  • Page 37 The CP-UNR-2xxQ2P rear panel is shown as below. See Figure 2-14. Figure 2-14 Please refer to the following sheet for detailed information. Port Name Connection Function USB2.0 USB2.0 port. Connect to USB2.0 mouse. Network port 10M/100M/1000Mbps self-adaptive Ethernet port. Connect to the network cable. High Definition High definition audio and video signal output HDMI...
  • Page 38 Port Name Connection Function C2,Group 3:port NO3～C3）).Output alarm signal to the alarm device. Please make sure there is power to the external alarm device. NO：Normal open alarm output port.  C：Alarm output public end.  RS485 RS485_A port. It is the cable A. You can (RS-485) connect to the control devices such as speed communication...

  • Page 39: Cp-Unr-2Xxq4/Cp-Unr-2Xxq4P Series

    2.2.5 CP-UNR-2xxQ4_ CP-UNR-2xxQ4P Series The CP-UNR-2xxQ4 series rear panel is shown as below. See Figure 2-13. Figure 2-15 The CP-UNR-2xxQ4 rear panel is shown as below. See Figure 2-14. Figure 2-16...
  • Page 40 Please refer to the following sheet for detailed information. Port Name Connection Function USB2.0 USB2.0 port. Connect to USB2.0 mouse. 10M/100M/1000Mbps self-adaptive Ethernet Network port port. Connect to the network cable. HDMI High Definition High definition audio and video signal output Media port.

  • Page 41: Cp-Unr-4Xxq8-Xu Series

    Port Name Connection Function MIC OUT Audio output Audio output port. It is to output the analog port audio signal to the devices such as the sound box.  Bidirectional talk output.  Audio output on 1-window video monitor.  Audio output on 1-window video playback.
  • Page 42 Port Name Connection Function  1-16 Alarm input I/O port There are four groups. The first group is port 1-16. from port 1 to port 4, the second group is from port 5 to port 8, the third group is from 9 to 12, and the fourth group is from 13 to 16.

  • Page 43: Cp-Unr-3Xxt2 Series

    Port Name Connection Function HDMI High Definition High definition audio and video signal output Media port. It transmits uncompressed high Interface definition video and multiple-channel data to the HDMI port of the display device. VGA video VGA video output port. Output analog video output port signal.
  • Page 44 Port Name Connector Function 3:port NO3～C3, Group 4：port NO4～C4, Group 5: port NO5, C5, NC5).Output alarm signal to the alarm device. Please make sure there is power to the external alarm device.  NO: Normal open alarm output port.  C: Alarm output public end.

  • Page 45: Cp-Unr-3Xxt2P Series

    2.2.8 CP-UNR-3xxT2P Series The CP-UNR-3xxT2P series rear panel is shown as below. See Figure 2-19. Figure 2-19 Please refer to the following sheet for detailed information. Port Name Connection Function USB2.0 USB2.0 port. Connect to USB2.0 mouse. 10M/100M/1000Mbps self-adaptive Ethernet Network port port.

  • Page 46: Cp-Unr-3Xxt2P Series

    Port Name Connection Function alarm device.  NO：Normal open alarm output port.  C：Alarm output public end. RS485 RS485_A port. It is the cable A. You can (RS-485) connect to the control devices such as speed communication dome PTZ. port RS485_B.It is the cable B.
  • Page 47 Port Name Connection Function HDMI High Definition High definition audio and video signal output Media port. It transmits uncompressed high Interface definition video and multiple-channel data to the HDMI port of the display device. VGA video VGA video output port. Output analog video output port signal.

  • Page 48: Cp-Unr-3Xxt8 Series

    Port Name Connection Function VIDEO OUT Video input CVBS output port Audio input Bidirectional talk input port. It is to receive the MIC IN port analog audio signal output from the devices such as mike phone, pickup. MIC OUT Audio output Audio output port.
  • Page 49 Port Name Connection Function  1-16 Alarm input I/O port There are four groups. The first group is port 1-16. from port 1 to port 4, the second group is from port 5 to port 8, the third group is from 9 to 12, and the fourth group is from 13 to 16.

  • Page 50: Alarm Connection

    Port Name Connection Function RS232(RS-422) RS232 debug It is for general COM debug to configure IP COM. address or transfer transparent COM data. HDMI High Definition High definition audio and video signal output Media port. It transmits uncompressed high Interface definition video and multiple-channel data to the HDMI port of the display device.

  • Page 51: Pc-End To The Device-End

    Figure 2-22 Listening Operation At the device end, speak via the speaker or the pickup, and then you can get the audio from the earphone or sound box at the pc-end. See Figure 2-23. Figure 2-23 2.2.3 PC-end to the device-end Device Connection Connect the speaker or the pickup to the audio output port in the PC and then connect the earphone or the sound box to the first audio input port in the device rear panel.

  • Page 52: Mouse Operation

    2.3 Mouse Operation Please refer to the following sheet for mouse operation instruction. Left click When you have selected one menu item, left click mouse to view menu mouse content. Modify checkbox or motion detection status. Click combo box to pop up dropdown list In input box, you can select input methods.

  • Page 53: Hdd Installation

    3 HDD Installation Important： Please turn off the power before you replace the HDD. The pictures listed below for reference only. For the first time install, please be aware that whether the HDDs have been installed. You can refer to the Appendix for recommended HDD brand. Please use HDD of 7200rpm or higher.

  • Page 54: Cp-Unr-3Xxq2-Xu/Cp-Unr-3Xxq2P-Xu/Cp-Unr-3Xxt2/Cp-Unr-3Xxt2P Series

    CP-UNR-3xxQ2-XU /CP-UNR-3xxQ2P-XU/ CP-UNR-3xxT2_ Series CP-UNR-3xxT2P 1. Loosen the screws of the 2. Fix four screws in the HDD 3. Place the HDD in accordance with upper cover and side panel. (Turn just three rounds). the four holes in the bottom. 4.

  • Page 55: Cp-Unr-2Xxq2/Cp-Unr-2Xxq2P/Cp-Unr-2Xxq4/Cp-Unr-2Xxq4P Series

    CP-UNR-2xxQ2/CP-UNR-2xxQ2P/CP-UNR-2xxQ4/CP-UNR-2xxQ4P Series ① Use 4 screws to secure the HDD ② Put the HDD to the HDD box at the front. ③ Pull the HDD knob up when you put the HDD ④ Put the knob back after you insert the HDD into the box in case the knob buckle may strike to the SATA board.
  • Page 56 ② Put the HDD to the HDD bracket in the chassis and then line up the four screws to the four holes in the HDD. Use the screwdriver to fix the screws firmly to secure HDD on the HDD bracket ③...

  • Page 57: Network Connection

    4 Network Connection Please refer to Figure 4-1 for connection sample. The following figure is based on the CP-UNR-4xxQ8-XU series product. Figure 4-1...

  • Page 58: Gui Operation

    5 GUI Operation Connect the device to the monitor and then connect a mouse and power cable. Click the power button at the rear panel and then boot up the device to view the analog video output. You can use the mouse to implement some GUI operation.
  • Page 59 You can overlay the corresponding date, time and channel name on each screen. You can refer to the following sheet for channel record or alarm status information. Recording status Video loss Motion detection Camera lock Preview Control The preview control function has the following features. ...

  • Page 60: Right Click Menu

    It is to backup the video of current channel to the USB2.0 device. System cannot backup the video of multiple-channel at the same time. Current selected backup channel has an icon as Real-time backup and the free channel is shown as an icon function Once the backup started, you can see the free channel is shown as an icon as...

  • Page 61: Main Menu

    Figure 5-4 5.3 Main Menu After you logged in, the system main menu is shown as below. See Figure 5-5. There are total seven icons: search, Information, setting, remote device, backup, advanced and shutdown. Move the cursor to highlight the icon, then double click mouse to enter the sub-menu. Figure 5-5...

  • Page 62: Search & Playback

    5.4 Search & Playback Click search button in the main menu, search interface is shown as below. See Figure 5-6. Figure 5-6 Please refer to the following sheet for more information. Name Function  Display Here is to display the searched picture or file. ...
  • Page 63  In 4-window playback mode: you can select 4 channels according to your channel requirement.  selection In 9-window playback mode, you can switch between 1-8 and 9-16 channels.  pane. In 16-window playback mode, you can switch between1-16 and 17-32 channels.
  • Page 64 In normal play mode, when you pause current play, you can click │ and │ to begin frame by frame playback. In frame by frame playback mode, click ►/ to restore normal playback. ► Slow play In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc.

  • Page 65: Information

    Record In any play mode, the time bar will change once you modify the search type. type  When system is playing, you can select a zone in the window to begin motion detect. Click the motion detect button to begin play. ...

  • Page 66: Hdd Information

    5.5.2 HDD Information Here is to list hard disk type, total space, free space, and status. See Figure 5-8. For CP-UNR-3xxQ2-XU product there are max 2 HDDs. For CP-UNR-404Q8-XUseries product there are max 8 HDDs. ○ means current HDD is normal.. - means there is no HDD. If disk is damaged, system shows as “?”.

  • Page 67: Bps

    Figure 5-9 Parameter Function SATA 1-4 here means there are 4 HDDS. For CP-UNR-304Q2-XU series product there are max 2 HDDs. For CP-UNR-404Q8-XU series product there are max 8 HDDs. When HDD is working properly, system is shown as O. . “_” means there is no HDD.

  • Page 68: Log

    Figure 5-10 For the 32-channel series product, the interface is shown as below. See Figure 5-11. Figure 5-11 5.5.4 Here is for you to view system log file. System lists the following information. See Figure 5-12. Log types include system operation, configuration operation, data management, alarm event, record operation, log clear and etc.

  • Page 69: Version

    Figure 5-12 Figure 5-13 5.5.5 Version Here is for you to view some version information. See Figure 5-14.  Channel  Alarm in  Alarm out  System version:  Build Date   Serial number Figure 5-14...

  • Page 70: Online Users

    5.5.6 Online Users Here is for you manage online users connected to the local device. See Figure 5-15. You can disconnect one user or block one user if you have proper system right. Figure 5-15 5.5.7 Remote Device Information Here you can view the channel status of the remote device, connection log and etc. Channel status: Here you can view the IPC status of the corresponding channel such as motion detect, video loss, camera masking, alarm and etc.

  • Page 71: Network Info

    channel. It includes IPC online, offline and etc. See Figure 5-17. Figure 5-17 5.5.8 Network Info In this interface, you can see network test and network load information. 5.5.8.1 Network Test Network test interface is shown as in Figure 5-18. Destination IP: Please input valid IPV4 address and domain name.

  • Page 72: Network Load

    Figure 5-18 5.5.8.2 Network Load Network load is shown as in Figure 5-19. Here you can view the follow statistics of the device network adapter. Here you can view information of all connected network adapters. The connection status is shown as offline if connection is disconnected.

  • Page 73: Setting

    5.6 Setting In main menu, highlight setting icon and double click mouse. System setting interface is shown as below. See Figure 5-20. Figure 5-20 Important Please note you need to have the proper right to implement the following operation. 5.6.2 General General setting includes the following items.
  • Page 74  Realtime play: It is to set playback time you can view in the preview interface. The value ranges from 5 to 60 minutes.  Device ID: Please input a corresponding device name here.  Holiday setting: Click it you can see an interface shown as in Figure 5-24. Here you can set holiday date.

  • Page 75: Encode

    Figure 5-22 Figure 5-23 Figure 5-24 Figure 5-25 5.6.3 Encode Encode setting includes the following items. See Figure 5-26. Please note some series do not support extra stream.  Channel: Select the channel you want.  Type: Please select from the dropdown list. There are three options: regular/motion detect/alarm.
  • Page 76  Bit rate type: System supports two types: CBR and VBR. In VBR mode, you can set video quality.  Quality: There are six levels ranging from 1 to 6. The sixth level has the highest image quality.  Video/audio: You can enable or disable the video/audio. ...

  • Page 77: Schedule

    Figure 5-27 Figure 5-28 Figure 5-29 5.6.4 Schedule In the main menu, from setting to schedule, you can go to schedule menu. See Figure 5-30.  Channel: Please select the channel number first. You can select “all” if you want to set for the whole channels.

  • Page 78: Quick Setup

    menu->Advanced->HDD Management). Please note this function is null if there is only one HDD.  Snapshot: You can enable this function to snapshoot image when an alarm occurs.  Record types: There are four types: regular, motion detection (MD), Alarm, MD & alarm. ...

  • Page 79: Rs232

    Figure 5-31 5.6.5 RS232 RS232 interface is shown as below. There are five items. See Figure 5-32.  Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program. The control keyboard is for you to control the device via the special keyboard.

  • Page 80: Network

    5.6.6 Network Here is for you to input network information. See Figure 5-33.  IP Version: There are two options: IPv4 and IPv6. Right now, system supports these two IP address format and you can access via them.  MAC address: The host in the LAN can get a unique MAC address. It is for you to access in the LAN.

  • Page 81: Network Setting

    Important For the IP address of IPv6 version, default gateway, preferred DNS and alternate DNS, the input value shall be 128-digit. It shall not be left in blank. After completing all the setups please click save button, system goes back to the previous menu. Figure 5-33 5.6.6.1 Network Setting Network setting interface is shown as in Figure 5-34.

  • Page 82: Ip Filter

    Figure 5-34 5.6.6.2 IP Filter IP filter interface is shown as in Figure 5-35. You can add IP in the following list. The list supports max 64 IP addresses. System supports valid address of IPv4 and IPv6. Please note system needs to check the validity of all IPv6 addresses.

  • Page 83: Ntp Setup

     Delete: Click it to remove specified item.  Edit: Click it to edit start address and end address. System can check the IP address validity after the edit operation and implement IPv6 optimization. Figure 5-35 5.6.6.3 NTP Setup You need to install SNTP server (Such as Absolute Time Server) in your PC first. In Windows XP OS, you can use command “net start w32time”...

  • Page 84: Multicast

    Brazil GMT-3 Middle Atlantic Time GMT-2 Figure 5-36 5.6.6.4 Multicast Multiple-cast setup interface is shown as in Figure 5-37. Figure 5-37 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D”...

  • Page 85: Pppoe

     Like the single broadcast address of RFC1918  Cannot be used in Internet transmission  Used for multiple cast broadcast in limited space. Except the above mentioned addresses of special meaning, you can use other addresses. For example: Multiple cast IP: 235.8.8.36 Multiple cast PORT: 3666.
  • Page 86 2) Function Introduction The CP Plus DDNS client has the same function as other DDNS client end. It realizes the bonding of the domain name and the IP address. Right now, current DDNS server is for our own devices only.

  • Page 87: Upnp

    Important  Do not register frequently. The interval between two registrations shall be more than 60 seconds. Too many registration requests may result in server attack.  System may take back the domain name that is idle for one year. You can get a notification email before the cancel operation if your email address setup is OK.

  • Page 88: Wifi Setting

    Figure 5-40 Figure 5-41 5.6.6.8 WIFI Setting You can view the WIFI connection status in the Network Setting interface. See Figure 5-42. You can view current connection status and IP address if there is a connection. Figure 5-42...

  • Page 89: Ftp

    Please note system will not send out the email immediately when the alarm occurs. When the alarm, motion detection or the abnormity event activates the email, system sends out the email according to the interval you specified here. This function is very useful when there are too many emails activated by the abnormity events, which may result in heavy load for the email server.
  • Page 90 Figure 5-45 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify or delete H140H 140H140HT U folder or not. See Figure 5-46. Figure 5-46 System also supports upload multiple NVRs to one FTP server.

  • Page 91: Alarm Center

    Figure 5-47 Figure 5-48 5.6.6.10 Alarm center Interface is pre-reserved for the users to develop this function. 5.6.6.11 SNMP SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management frame of the network management system. The SNMP widely used in many environments.

  • Page 92: Auto Register

    Figure 5-49 Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, NVR-SNMP-MIB) to connect to the device. You can get the device corresponding configuration information after successfully connection.

  • Page 93: Alarm

    mapping port number. The device ID here shall be the same with the ID you input in Figure 5-50. Click Add button to complete the setup. 4) Now you can boot up the proxy server. When you see the network status is Y, it means your registration is OK.
  • Page 94  Alarm output: The number here is the device alarm output port. You can select the corresponding ports(s) so that system can activate the corresponding alarm device(s) when an alarm occurred.  Latch: When the anti-dither time ended, the channel alarm you select in the alarm output may last the specified period.
  • Page 95 Figure 5-51 Figure 5-52 Figure 5-53 For the 32-channel series product, the alarm interface and PTZ setup is shown as below. See Figure 5-54 and Figure 5-55.

  • Page 96: Detect

    Figure 5-54 Figure 5-55 5.6.8 Detect Go to Detect Menu In the main menu, from Setting to Detect, you can see motion detect interface. See Figure 5-56.There is three detection types: motion detection, video loss, camera masking.  The video loss has no detection region and sensitivity setup and camera masking has no detection region setup.
  • Page 97  Channel: Select a channel from the dropdown list to set motion detect function.  Enable: Check the box here to enable motion detect function.  Region: Click select button, the interface is shown as in Figure 5-57. Here you can set motion detection zone.
  • Page 98 Figure 5-56 Figure 5-57 Figure 5-58...

  • Page 99: Video Loss

    Figure 5-59 Figure 5-60 5.6.8.2 Video Loss In Figure 5-56, select video loss from the type list. You can see the interface is shown as in Figure 5-61.This function allows you to be informed when video loss phenomenon occurred. You can enable alarm output channel and then enable show message function. You can refer to chapter 5.6.8.1Motion detect for detailed information.

  • Page 100: Camera Masking

    Figure 5-61 5.6.8.3 Camera Masking When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Camera masking interface is shown as in Figure 5-62. You can enable alarm output channel and then enable show message function.

  • Page 101: Ptz

    5.6.9 Note: All the operations here are based on PELCOD protocol. For other protocols, there might be a little difference. Cable Connection Please follow the procedures below to go on cable connection  Connect the dome RS485 port to NVR 485 port. ...
  • Page 102 Figure 5-64 After completing all the setting please click save button. In one window display mode, right click mouse (click “Fn” Button in the front panel or click “Fn” key in the remote control). Click Pan/Tilt/Zoom, the interface is shown as below. See Figure 5-65. Here you can set the following items: ...

  • Page 103: Display

    Here is a sheet for you reference. Name Function function Shortcut Function function Shortcut  Zoom Wide  ► │ │ Focus Near   Iris Close Open 5.6.10 Display Display setup interface is shown as below. See Figure 5-67. ...

  • Page 104: Default

    Figure 5-68 5.6.11 Default Click default icon, system pops up a dialogue box. You can highlight to restore default factory setup.  Select all  General  Encode  Schedule  RS232  Network  Alarm  Detect  Pan/tilt/zoom ...

  • Page 105: Remote Device

    The built-in switch function is for product of PoE port. From Network->Network Server->Switch, you can set switch IP address, subnet mask, gateway and etc. See Figure 5-70. Figure 5-70 5.6.12.3 Remote Device In the main menu, click the Remote Device icon to go to the corresponding interface. See Figure 5-71.
  • Page 106 enhance the video brightness under the low illumination, but the video noise may become high.  BLC: Check the box here to enable backlight compensation function. System can automatically expose according to environment so that you can view the darkest section of the video.

  • Page 107: Short-Cut Menu

    Click the Manual Add button; you can go to the following interface. See Figure 5-73. This series product max supports 32-channel standard definition video/high definition non-real-time video and the transmission rate is 1Mbps per channel. It can also max supports 4-channel high definition video and the transmission rate is 8Mbps.

  • Page 108: Advanced

    Figure 5-74 Figure 5-75 5.7 Advanced Double click advanced icon in the main window, the interface is shown as below. See Figure 5-76.There are total eight function keys: HDD management, alarm output, abnormity, manual record, account, auto maintenance, TV adjust and video matrix.

  • Page 109: Hdd Management

    Figure 5-76 5.7.2 HDD Management Here is for you to view and implement hard disk management. See Figure 5-77. You can see current HDD type, status, capacity and record time. When HDD is working properly, system is shown as O. When HDD error occurred, system is shown as X. ...
  • Page 110  Each channel is only corresponding with one HDD Group, while one HDD Group can store records from several channels.  HDD Group is only available for read-write HDD and self-defined disks, other types of hard disks cannot be set as HDD Group. Important: ...

  • Page 111: Abnormality

    Important  Please make sure you have set HDD group for each channel, otherwise you cannot save current setup!  Once you change the HDD Group settings, system will pack the records and then reboot! Tips There is an easy way for you to test whether the records from the corresponding channel is saved in the specified HDD.

  • Page 112: Alarm Output

    Figure 5-81 5.7.4 Alarm Output Here is for you to set proper alarm output. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 5-82.

  • Page 113: Enable/Disable Record

     Schedule: Channel records as you have set in recording setup (Main Menu->Setting->Schedule)  Stop: All channels stop recording. Figure 5-83 5.7.5.3 Enable/disable record Please check current channel status: “○” means it is not in recording status, “●” means it is in recording status.

  • Page 114: Stop All Channel Recording

    Figure 5-85  All channel manual record Please highlight “ALL” after “Manual.” See Figure 5-86. When system is in manual recording, all scheduled set up you have set in will be null ((Main menu->Setting->Schedule)). You can see indication light in front panel turns on, system begins manual record now. Figure 5-86 5.7.5.5 Stop all channel recording Please highlight “ALL”...

  • Page 115: Modify Password

    middle. The string includes the valid character, letter, number, underline, subtraction sign, and dot.  System account adopts two-level management: group and user. No limit to group or user amount.  For group or user management, there are two levels: admin and user. ...

  • Page 116: Add/Modify Group

    Figure 5-89 5.7.6.2 Add/Modify Group Click add group button, the interface is shown as below. See Figure 5-90. Here you can input group name and then input some memo information if necessary. There are total 60 rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.

  • Page 117: Auto Maintenance

    Figure 5-91 5.7.7 Auto Maintenance Here you can set auto-reboot time and auto-delete old files setup. You can set to delete the files for the specified days. See Figure 5-92. You can select proper setup from dropdown list. After all the setups please click save button, system goes back to the previous menu. Figure 5-92 5.7.8 Config Backup...

  • Page 118: Shutdown

    Figure 5-93 5.8 Shutdown Double click shutdown button, system pops up a dialogue box for you to select. See Figure 5-94.  Logout menu user: log out menu. You need to input password when you login the next time.  Restart application: reboot device.

  • Page 119: Quick Configuration Tool

    6 Quick Configuration Tool 6.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 6.2 Operation Double click the “ConfigTools.exe”...
  • Page 120 Figure 6-3 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set. In the configuration tool search interface (Figure 6-1), please select a device IP address and then double click it to open the login interface.
  • Page 121 Figure 6-5 For detailed information and operation instruction of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD.

  • Page 122: Web Operation

    7 Web Operation 7.1 General Introduction The device web provides channel monitor menu tree, search, alarm setup, system setup, PTZ control and monitor window. Important The following operation is based on 16-channel series device. For the 32-channel series product, there is 32-channel option. 7.1.2 Preparation Before log in, please make sure:...

  • Page 123: Log In

    If it is your second time to insert the PoE, system can check the saved MAC address according to <Channel>---<IPC mac> map to make sure current IPC has connected or not. If system finds the previous information and the channel is idle, system can map it to the previously used channel.

  • Page 124: Lan Mode

    Figure 7-2 Login interface Please input your user name and password. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. 7.2 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 7-3. ②...

  • Page 125: Monitor Channel Menu Tree

     Section 2: System menu  Section 3: PTZ control  Section 4: Video setup and other setup  Section 5: Preview window  Section 6: Monitor window switch 7.2.2 Monitor Channel Menu Tree The monitor channel menu tree is shown as in Figure 7-4. Please note the following figure is for reference only.
  • Page 126 You can click this button to enable audio talk. Click 【▼】 to Start Dialogue select bidirectional talk mode. There are four options: DEFAULT， G711a，G711u and PCM. Please note, the audio input port from the device to the client-end is using the first channel audio input port. During the bidirectional talk process, system will not encode the audio data from the 1-channel.

  • Page 127: System Menu

    Parameter Function  1: NVR IP address. Display device  information 2: Channel number.  3: Bit stream.  4: Bit stream decode type.  S1: Overlay.  S2: Off stream.  S3:GD1  H1: Overlay  H2: off stream decoding from the display card. Click this button and then left drag the mouse in the zone Digital zoom to zoom in.

  • Page 128: Ptz Control

    7.2.5 PTZ Control Before PTZ operation, please make sure you have properly set PTZ protocol. (Please refer to chapter 0 PTZ). Here you can view direction keys, speed, zoom, focus, iris, preset, tour, pan, scan, pattern, aux close, and PTZ setup button. Please note: open menu/close menu/up/down/left/right/confirm/cancel buttons are for speed dome only.

  • Page 129: Color And More Setup

    Please refer to the following sheet for PTZ setup information. Parameter Function  Move the camera to you desired location and then click left limit Scan button.  Then move the camera again and then click right limit button to set a right limit.
  • Page 130 Please refer to the following sheet for detailed information. Parameter Function Video It is to adjust monitor video Note: setup brightness. operation here applies to WEB end only. It is to adjust monitor video contrast ness. It is to adjust monitor video saturation.

  • Page 131: Wan Login

    7.3 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 7-13. Figure 7-13 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default. The open/close button on the left pane is null.
  • Page 132 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor. You can view there are two icon at the left top corner of the channel number for you reference. M stands for main stream.

  • Page 133: Configuration

    7.4 Configuration 7.4.2 System Information 7.4.2.1 Version Information Here you can view device hardware feature and software version information. See Figure 7-16. Figure 7-16 Version Information 7.4.2.2 HDD information Here you can view local storage status such as free capacity and total capacity. See Figure 7-17. Figure 7-17 HDD Information...

  • Page 134: Log

    7.4.2.3 Here you can view system log. See Figure 7-18 Figure 7-18 Log Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type management, alarm event, record operation, user management, log clear and file operation.

  • Page 135: System Configuration

    7.4.3 System Configuration Please click save button to save your current setup. Please click refresh button to view the latest setup. 7.4.3.1 General Setup Here you can set system time, record length, video format and etc. See Figure 7-19. Figure 7-19 General Setup Figure 7-20 DST Figure 7-21 DST Please refer to the following sheet for detailed information.

  • Page 136: Encode

    Parameter Function Here is for you to modify system time. Please click Save button after System Time your completed modification Sync PC You can click this button to save the system time as your PC current time. Here you can select data format from the dropdown list. Data Format Please select separator such as –...
  • Page 137 Please refer to the following sheet for detailed information. Parameter Function Channel Select the corresponding channel. Channel Display the current channel ID. You can also modify the channel ID here. Name Encoding The device does not support it. mode For the main stream, recorded file only contains video by default. You need to draw a circle here to enable audio function.

  • Page 138: Schedule

    7.4.3.3 Schedule Here you can set different periods for various days. There are max six periods in one day. See Figure 7-23. Figure 7-23 Schedule Figure 7-24 Schedule Time...
  • Page 139 Figure 7-25 Copy Figure 7-26 Please refer to the following sheet for detailed information. Parameter Function Please select a channel first. Channel Pre-record Please input pre-record value here. When alarm record or motion detection record occurs, system can record the several seconds video before activating the record operation into the file.

  • Page 140: Rs232

    Parameter Function Holiday Click Set button, system pops up a dialogue box shown as in Figure 7-26. Here you can set holiday date. Check the box, it means current channel shall record as your holiday setup. Please go to the Period interface to set the holiday date record setup.

  • Page 141: Network

    Parameter Function Transparent COM: Network user can communicate with RS232 COM device. PTZ matrix: PTZ matrix protocol. You can use the device to control the PTZ matrix. The value ranges from 5 to 8. Data Bit There are three options: 1/2. Stop Bit Baud Bit You can select corresponding baud bit here.
  • Page 142 Parameter Function IP Address Here you can use up/down button () or input the corresponding number to input IP address. Then you can set the corresponding subnet mask the default gateway. Subnet Prefix The input value ranges from 0 to 128. It is to mark a specified network MAC address.
  • Page 143 Parameter Function Remote PPPOE  Input the user name and password which ISP(Internet service supplier) host provided and chose enable.  Reboot system after configuration is saved and the device will auto connect to Internet. The IP address is the WAN IP. There are two conditions for reboot, ...
  • Page 144 Please refer to the following sheet for detailed information. Parameter Function Input server address and then enable this function. SMTP Server You can also input the corresponding server domain name here, but you need to go to DNS interface (chapter 7.3.4.1) to set the server IP that can parse the domain.
  • Page 145 Please refer to the following sheet for detailed information. Parameter Function Server Type You can select DDNS protocol from the dropdown list and then enable DDNS function. Server IP DDNS server IP address Server Port DDNS server port. Domain Name Your self-defined domain name.
  • Page 146 Figure 7-32 NAS Figure 7-33 NAS Setup Please refer to the following sheet for detailed information. Parameter Function Please select network storage protocol and then enable NAS enable NAS function. The network storage protocol includes FTP. Server IP Input remote storage server IP address. Input Remote storage server port number.
  • Page 147 Parameter Function Channel Select a monitor channel . Period In NAS interface, click set button, you can go to the  info. corresponding setup interface. See Figure 7-33. Setup .Please set schedule period and then select  corresponding record type: schedule/alarm. Please note device does not support motion detect record function now.
  • Page 148 Parameter Function Time Zone Device current time zone. Update Interval Time update interval value. Alarm Centre Alarm centre interface is shown as below. See Figure 7-35. Please input alarm centre server IP, port number. Once there is an alarm occurred, system cannotify the alarm centre as you specified here.

  • Page 149: Alarm

    Figure 7-36 UNPN SNMP The SNMP interface is shown as in Figure 7-37. SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management frame of the network management system. The SNMP widely used in many environments.
  • Page 150 Figure 7-38 Alarm Setup Figure 7-39 PTZ Setup...
  • Page 151 Figure 7-40 Please refer to the following sheet for detailed information. Parameter Function Event type: There are four types. Local input/network input/IPC Event Type external/IPC offline alarm.  Local input alarm: The alarm signal system detects from the alarm input port. ...

  • Page 152: Detect

    Parameter Function Relay Out Enable alarm activation function. You need to select alarm output port so that system can activate corresponding alarm device when an alarm occurs. For 6-ch alarm output port device, the 6 channel is the controllable +12V output. System can delay the alarm output for specified time after alarm ended.
  • Page 153 Figure 7-41 Detect Please refer to the following sheet for detailed information. Parameter Function Event type Motion detect, video loss and video masking Select a channel from the dropdown list to set motion detect, video loss and video Channel masking function. Sensitivity System supports 6 levels.

  • Page 154: Ptz

    7.4.3.7 PTZ interface is shown as in Figure 7-42 Please note, before operation please make sure you have set speed dome address and the NVR and speed dome connection is OK. Figure 7-42 PTZ Please refer to the following sheet for detailed information. Parameter Function You can select monitor channel from the dropdown list.

  • Page 155: Advanced

    Figure 7-43 Default and Backup Please refer to the following sheet for detailed information. Parameter Function Select All Restore factory default setup. Export Export system configuration to local PC. Configuration Import Import configuration from PC to the system. Configuration 7.4.4 Advanced 7.4.4.1 HDD Management...

  • Page 156: Abnormity

    Figure 7-44 HDD Management Please refer to the following sheet for detailed information. Parameter Function Format Clear data in the HDD. Read/write Set current HDD as read/write Read only Set current HDD as read. Redundant Set current HDD as redundant HHD. Recover Fix the HDD error.
  • Page 157 Figure 7-45 Abnormity -1 Figure 7-46 Abnormity -2 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: no disk, no space, disk error, offline, IP Type conflict. You need to draw a circle to enable this function. Threshold: It refers to the HDD free space threshold.

  • Page 158: Alarm I/O

    Parameter Function Record System can delay the record for specified time after alarm ended. The latch value ranges from 10s to 300s. If you check the box here, system can send out a message to the specified mobile phone when an alarm occurred. Send If you enable this function, system can send out email to alarm the email...

  • Page 159: Record

    7.4.4.4 Record Record control interface is shown as in Figure 7-48. The bit stream type includes main stream and extra stream. Figure 7-48 Record Please refer to the following sheet for detailed information. Parameter Function System enables auto record function as you set in schedule setup Schedule (chapter 7.3.2.2).
  • Page 160 Figure 7-49 Account Figure 7-50 Add user Please refer to the following sheet for detailed information. Parameter Function User Input the user name of the new established account.

  • Page 161: Snapshot

    Reusable The reusable account means that this account can be used in more than one PC at the same time. Password Input the password of the new established account. Confirm Input the password of the new established account again. Group Select the group which the new account belongs to.

  • Page 162: Remote Device

    Figure 7-52 Auto Maintenance 7.4.4.8 Remote device Remote device interface is shown as in Figure 7-53. Figure 7-53 Remote device...

  • Page 163: Preview Control

    Figure 7-54 Manual Add Please refer to the following sheet for detailed information. Parameter Function Remote device Here you can see searched remote device name, IP address, TCP port information and manufacturer name. Channel Please select the local device channel number to connect to the remote device.

  • Page 164: Additional Function

    Figure 7-55 Preview Control 7.4.5 Additional Function 7.4.5.1 IPC Config IPC configuration interface is shown as in Figure 7-56. Here you can set gain, iris, brightness, contrastness, hue, saturation BLC and etc of the network camera. Figure 7-56 IPC Config...
  • Page 165 Please refer to the following sheet for detailed information. Parameter Function Brightness It is to adjust monitor window bright. The value ranges from 0 to 100. The default value is 50. The larger the number, the bright the video is. When you input the value here, the bright section and the dark section of the video will be adjusted accordingly.

  • Page 166: Auto Register

    Mirror It is to switch video left and right limit. This function is disabled by default. Flip It is to switch video up and bottom limit. This function is disabled by default. Please note the video resolution shall be 720P or lower when it is to flip 90°.

  • Page 167: Wifi Config

    Figure 7-58 Mobile Setup 7.4.5.4 WIFI Config The WIFI interface is shown as in Figure 7-59. Here you can view WIFI connection status. System displays as no connection if there is no connection. You can view connection status and IP address if there is a connection. See Figure 7-60.

  • Page 168: Search

    Figure 7-60 Please refer to the following sheet for detailed information. Parameter Function Refresh Search hotspot again and system can automatically add the information such as password (If there is any record of the hotspot.) WIFI working Here you can view current connection status. information You can view connection status and IP address if there is a connection.
  • Page 169 Figure 7-61 Then please click search button, you can see the corresponding files in the list. See Figure 7-61. Figure 7-62 Select the file(s) you want to download and then click download button, system pops up a dialogue box shown as in Figure 7-62, then you can specify file name and path to download the X480H480H480H file(s) to your local pc.
  • Page 170 Figure 7-63 Load more It is for you to search record or picture. You can select record channel, record type and record time to download. See Figure 7-64. Figure 7-64 In Figure 7-64, there is a remote back pane at the left bottom of the pane. It allows you to backup the record or picture to your local USB2.0 storage media via the Web remotely.

  • Page 171: Alarm

    Figure 7-65 Now you can see system begins download and the download button becomes stop button. You can click it to terminate current operation. At the bottom of the interface, there is a process bar for your reference. 7.6 Alarm Click alarm function, you can see an interface is shown as in Figure 7-66.

  • Page 172: About

    Figure 7-66 Alarm Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs, Disk full System alarms when disk is full. Disk error System alarms when disk error occurs.

  • Page 173: Log Out

    7.8 Log out Click log out button, you can go back to log in interface. See Figure 7-68. Figure 7-68 Logout...

  • Page 174: Faq

    8 FAQ 1. Device cannot boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
  • Page 175  Device color or brightness setup is not correct. 6. Cannot search local records. There are following possibilities:  HDD ribbon is damaged.  HDD is broken.  Upgraded program is not compatible.  The recorded file has been overwritten. ...
  • Page 176  PTZ decoder and device address is not compatible.  When there are several decoders, please add 120 Ohm between the PTZ decoder A/B cables furthest end to delete the reverberation or impedance matching. Otherwise the PTZ control is not stable. ...
  • Page 177  System uses too much CPU resources. Please stop record first and then begin backup.  Data amount exceeds backup device capacity. It may result in burner error.  Backup device is not compatible.  Backup device is damaged. 17. Keyboard cannot control device. There are following possibilities: ...
  • Page 178  There is no DivX503Bundle.exe control when you play the file transformed to AVI via media player.  No DivX503Bundle.exe or ffdshow-2004 1012 .exe in Windows XP OS. 23. I forgot local menu operation password or network password Please contact your local service engineer or our sales engineer for help. We can guide you to solve this problem.

  • Page 179: Appendix A Hdd Capacity Calculation

    Appendix A HDD Capacity Calculation Calculate total capacity needed by each device according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.

  • Page 180: Appendix B Compatible Sata Hdd

    10 Appendix B Compatible SATA HDD Manufacturer Series Model Capacity Port Mode Seagate Seagate SV35.1 ST3250824SV 250G SATA Seagate Seagate SV35.1 ST3500641SV 500G SATA Seagate Seagate SV35.2 ST3250820SV 250G SATA Seagate Seagate SV35.2 ST3320620SV 320G SATA Seagate Seagate SV35.2 ST3500630SV 500G SATA Seagate...
  • Page 181 Seagate Seagate Pipeline ST3500414CS 500G SATA Seagate Seagate Pipeline ST3500312CS 500G SATA Seagate Seagate Pipeline ST31000424CS SATA Seagate Seagate Pipeline ST31000322CS SATA Seagate Seagate Pipeline ST1000VM002 SATA Seagate Seagate Pipeline ST1500VM002 Seagate Seagate Pipeline ST2000VM002 SATA Seagate Seagate Pipeline ST2000VM003 SATA Seagate Seagate...
  • Page 182 Constellation ES Seagate Seagate ST500NM0051 500G SATA Constellation ES Seagate Seagate ST33000650NS SATA Constellation ES.2 Seagate Seagate ST32000645NS SATA Constellation ES.2 Seagate Seagate ST33000651NS SATA Constellation ES.2 Seagate Seagate ST32000646NS SATA Constellation ES.2 Seagate Seagate ST33000652NS SATA Constellation ES.2 Seagate Seagate ST32000647NS SATA...
  • Page 183 Digital Westem WD AV—AVJS WD3200AVJS-63WDA0 320G SATA Digital Westem WD AV—AVJS WD5000AVJS-63YJA0 500G SATA Digital Westem WDAV-GP—AVCS WD5000AVCS-63H1B1 500G SATA Digital Westem WDAV-GP—AVCS WD7500AVCS-63ZLB0 750G SATA Digital Westem WDAV-GP—AVCS WD3200AVCS 320G SATA Digital Westem WDAV-GP—AVCS WD2500AVCS 250G SATA Digital Westem WDAV-GP—EVCS WD10EVCS-63ZLB0 SATA...
  • Page 184 Digital Westem WD AV-GP WD20EURS SATA Digital Westem WD AV-GP WD15EURS 1.5T SATA Digital Westem WD AV-GP WD10EURS SATA Digital Westem WD AV-GP WD10EURX SATA Digital Westem WD AV-GP WD7500AURS 750G SATA Digital Westem WD AV-GP WD7500AVDS 500G SATA Digital Westem WD AV-GP WD500AVDS...

  • Page 185: Appendix C Compatible Usb2.0 List

    11 Appendix C Compatible USB2.0 List Manufacturer Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Fredom Sandisk Cruzer Freedom Kingston Data Traveler II Kingston Data Traveler II Kingston Data Traveler Kingston...
  • Page 186 Teclast Ti Cool 512M Teclast Ti Cool Teclast Ti Cool...

  • Page 187: Appendix D Compatible Displayer List

    12 Appendix D Compatible Displayer List Brand Model Dimension (Unit: inch) ET-0007-TA 19-inch (wide screen) BENQ（LCD） DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch LENOVO（LCD） LXB-L17C 17-inch SANGSUNG（LCD） 225BW 22-inch (wide screen) LENOVO(CRT) LXB-FD17069HB 17-inch LENOVO(CRT) LXB-HF769A 17-inch LENOVO(CRT) LX-GJ556D 17-inch Samsung (LCD)

  • Page 188: Appendix H Toxic Or Hazardous Materials Or Elements

    Appendix H Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ （Panel） ○ ○ ○ ○ ○...
  • Page 189 Website: - www.cpplusworld.com Email id: - sales@cpplusworld.com; support@cpplusworld.com...

This manual is also suitable for:

Cp-unr-1xxq1p seriesCp-unr-2xxq2p seriesCp-unr-2xxq4 seriesCp-unr-2xxq4p seriesCp-unr-3xxq2-xu seriesCp-unr-4xxq8-xu series ... Show all

Table of Contents
