Altronix HubSat4DV Passive UTP Transceiver Hub with Integral Camera Power transmits UTP video, RS422/RS485 data
and power over a single CAT-5 or higher structured cable. Unit provides 4 camera channels in a wall mount enclosure.
Video transmission range is up to 750 ft. max. per channel. Units are compatible with AC and/or DC fixed or PTZ cameras
when utilizing Altronix HubWayAv or HubWayDv Video Balun/Combiners. In addition, the unit features individually
selectable 24VAC or 28VAC PTC protected outputs with surge suppression. Optionally, the HubSat4DV can be used as
an accessory module to transmit video from up to 4 cameras over a single CAT-5 or higher structured cable back to the
HubWayV, HubWayLDV or HubWayLDHV Passive and Active UTP Transceiver Hubs. In addition, the HubSat4DV
provides power to these cameras locally to eliminate the possibility of voltage drop associated with long cable runs.
Input:
• 220VAC 50/60Hz, 0.5 amp.
• Primary in-line fuse is rated @ 3.5A/250V.
Video:
• Four (4) channels of quality video over twisted pair
up to a distance of 750 ft. per channel.
• Four (4) 75 ohm video outputs.
Data:
• RS422/RS485 data input.
Power:
• Individually selectable 24VAC or 28VAC power
outputs with OFF position.
• PTC protected outputs.
• PTCs are rated @ 1 amp per channel.
HubSat42DV
• HubSat4DV w/four (4) HubWayAv Video Balun/
Combiners for 24VAC Cameras.
HubSat4DV Passive UTP Transceiver Hub with Integral Camera Power.
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure's
upper keyholes over the two upper screws, level and secure. Mark the position of the lower two holes. Remove the
enclosure. Drill the lower holes and install two fasteners. Place the enclosure's upper keyholes over the two upper
screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 8).
Secure green wire lead to earth ground.
2. Set illuminated master power disconnect circuit breaker to the (OFF) position (Fig. 4a, pg. 6).
3. Connect 220VAC 50/60Hz to the black and red flying leads of open frame transformer. Secure ground
wire (Green) to earth ground (Fig. 5, pg. 7). The power LEDs (Green) for Channels 1-4 of the HubSat4DV
will illuminate when AC power is present (Fig. 1e, pg. 4)
4. Select 24VAC or 28VAC power output for Channels 1-4 with the corresponding voltage adjustment switches
(Fig. 1d, pg. 4).
5. Connect the BNC video outputs for HubSat4DV Channels 1 - 4 to the corresponding video inputs
on the head end equipment (DVR) (Fig. 1a, pg. 4).
6. Connect the RS422/RS485 output of the head end equipment (DVR) to the data terminals marked [+ Data - - - ]
of the HubSat4DV unit (polarity must be observed) (Fig. 1f, pg. 4).
Note: The Data input terminals of the HubSat4DV must be wired in parallel for proper operation.
When using fixed cameras disregard this step.
7. Connect Video Balun/Combiner at camera 1 to the HubSat4DV unit utilizing CAT-5 or higher structured cable.
Plug the RJ45 connector at one end of a structured cable into the RJ45 jack marked [PVD1] of the
HubSat4DV (Fig. 1i, pg. 4). Plug the RJ45 connector at the opposite end of the structured cable into the
RJ45 jack of the Video Balun/Combiner located at camera 1.
• For 24VAC cameras use Altronix model HubWayAv/HubWayAv2 Video Balun/Combiner (Figs. 2a, 2b, 2e, pg. 5).
• For 12VDC cameras use Altronix model HubWayDv Video Balun/Combiner (Figs. 2c, 2d, pg. 5).
• For non-isolated 12VDC cameras use Altronix model HubWayDvi Video Balun/Combiner (Figs. 2c, 2d, pg. 5).
AC LED (Green) of the HubWayAv or DC LED (Red) of the HubWayDv Video Balun/Combiners will illuminate
indicating power is present at the cameras (Fig. 2b, 2d, pg. 5).
- 2 -
Overview:
Specifica tions:
Power (cont.):
• Unit provides up to 1 amp max. per channel not to
exceed a total of 4 amp maximum current.
• Surge suppression.
Visual Indicators:
• Four (4) power LED indicators.
Enclosure Dimensions (H x W x D approx.):
8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm).
Optional Accessories:
• Video Balun/Combiners:
- HubWayAv - for use with 24VAC cameras.
- HubWayAv2 - for use with 24VAC cameras.
- HubWayDv - for use with 12VDC cameras.
- HubWayDvi - for use with non-isolated 12VDC cameras.
Additional Models:
HubSat43DV
• HubSat4DV w/four (4) HubWayDv Video Balun/
Combiners for 12VDC Cameras.

Installation Instructions:

HubSat4DV
